- Designed to break current upon electrical leak detection
- Periodic self-test diagnostic for ground fault detection
- Compatible with type CH load centers
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
Magic Apron Assistant is an AI virtual assistant. By proceeding, you consent to the recording and use of your information by The Home Depot (and authorized third parties). More information
Product Details
About This Product
Eaton's BR Ground Fault Current Interrupters (GFCIs) provide superior safety over a standard electrical outlet in areas where electricity may come into contact with water. GFCIs are required in any application near water such as kitchen countertops, bathrooms, swimming pools, hot tubs, and outdoor receptacles. They immediately break the circuit when electrical current leakage is detected, reducing the risk of shock and electrocution. This circuit breaker periodically runs a self-test diagnostic and complies UL 943.
Highlights
- 1 pole, 20 Amp, 120/240 Volt
- Compatible for use in Type BR load centers and meter breaker panels
- Interrupt rating-10 kAIC
- 5mA ground fault protection
- Provides a single point of reset
- Self-test GFCI
- GFCI breaker is provided with an auto-monitoring function that will allow for periodic automatic testing of the ability of the device to respond to a ground fault
- GFCI devices perform a routine self-test of their capability to detect and prevent ground faults, the device must disable itself if the self-test is failed
- The automatic test shall be initiated with 5 seconds of power availability to the line or load terminals
- The automatic test shall be repeated at least every 3 hours
- Pressing a breaker's test button will yield the expected result: the breaker will trip if it is functioning properly
- GFCI breakers are required in any application near water such as kitchen countertops, bathrooms, swimming pools, hot tubs, and outdoor receptacles
- Provides protection from hazards of electrical shock in areas where electricity may come into contact with water
- Learn More About Circuit Breakers Here in our Buying Guide.
- Return Policy
Product Information
Specifications
Dimensions
Product Depth (in.) | .6 in |
|---|---|
Product Width (in.) | 7.3 in |
Details
AIC Rating | 10000 |
|---|---|
Breaker Type | Standard |
Connection Type | Pigtail |
Interruption Type | GFCI |
Maximum Amperage (A) | 20 A |
Mounting Type | Plug-On |
Number of Poles | Single |
Number of Spaces | 1 |
Pack Size | 1 |
Product Weight (lb.) | 1 lb |
Returnable | 90-Day |
Series Type | BR |
Trip Unit | Electronic |
Voltage (V) | 120/240 V |
Warranty / Certifications
Certifications and Listings | ANSI Certified, CSA Listed, UL Listed |
|---|---|
Manufacturer Warranty | 5 Year Per the Warranty Statement |
Questions & Answers
Is this breaker (SWD) switch rated for fluorescent lights?
Hi, this breaker is switching duty rated. If you have further questions, please contact our technical support team at 877-386-2273 opt 2 opt 3 opt 1.
Will this breaker fit on a BR Eaton load center that have the BR 120 breakers?
Hello, Yes, a GFTCB120CS ground fault breaker will fit into an Eaton BR load center.
I am trying to locate the correct gfci breaker that replaces my current BR115 breaker. I believed my replacement would be Eaton GFTCB115CS but all of the retailers seem to no longer stock them in their stores.
Hello. The BR115 is still available for purchase. If you have any further questions, please contact our Technical Resource Center by phone at 1-877-386-2273 option 2 option 3 option 1 or by email at TRC@Eaton.com. Regards, Eaton.
Is this the breaker I should be using to run a direct line to my pool pump ?
Hello Steve. Please refer to your electrician or local authority having jurisdiction for assistance with breaker recommendations for your application. If you have any further questions, please contact our Technical Resource Center by phone at 1-877-386-2273 option 2 option 3 option 1 or by email at TRC@Eaton.com. Regards, Eaton.
Can this fit a murray panel with square d breakers? Does this use a load neutral connection?
David, Eaton's GFTCB115CS is only UL listed for use in Eaton BR loadcenters. Our CL style classified breakers are UL listed for use in Murray panels. To discuss product selection please contact our Technical Resource Center at 877-386-2273 opt 2, opt 3, opt 1. Regards, Eaton
Will this breaker work with a Cutler Hammer BR Loadcenter BR1362B200GK
Hello, The GFTCB120CS is for use in the BR loadcenters and will work. Regards, Eaton
Will this breaker work in a Eaton Type 3R enclosure, Cat. No. BR816B200RF?
Worked great in my Eaton breaker box. Installed in 15 min
Short answer is yes it will work. I am also attaching a link to the specs on your enclosure. http://pe.eaton.com/print/BR816B200RF
Yes, this BR GFCI breaker will work in a BR loadcenter regardless of it being a NEMA 3R or NEMA 1 enclosure.
I currently have a defective Cutler Hammer GFCB115GFI circuit breaker. Is the Easton BR 15 single pole self test ground fault circuit breaker compatible?
Yes, this GFCI breaker will replace the one you have.
Hey George, yes the BR ground fault breaker and the GFTCB115 is compatible in the same loadcenter. Regards, Eaton
