All Purpose 1-Stage Whole House Water Filtration System With 4.5 x 20 in. Reusable and Washable Pleated Sediment Filter

$ 130 68

Overview

This 20 in. Big Blue (BB) whole house sediment water filtration system features a pleated sediment filter that is reusable and washable, designed to reduce dirt, sand, silt, and scale and rust particles. Rated at 30 microns, this polyester sediment cartridge can treat water with high flow rates and low pressure drops. In addition, their unique design offers exceptional dirt holding capacity for all types of applications. The filter media is pleated to maximize dirt-holding capacity and to extend the time period between changes or cleaning. This sediment cartridge is resistant to both bacteria and chemical attack making it highly suitable for a variety of residential, commercial and industrial applications. The 20 in. Big Blue filter housing is constructed of durable reinforced polypropylene and can operate effectively under a wide range of water conditions for different applications. The certified filter and housing is equipped with 1 in. FPT inlet and outlet ports for large volume and fast water flow. Housing wrench and bracket is also included for a complete whole house carbon filter system that provides chemical-free water delivered throughout all your faucets.
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

This 20 in. Big Blue (BB) whole house sediment water filtration system features a pleated sediment filter that is reusable and washable, designed to reduce dirt, sand, silt, and scale and rust particles. Rated at 30 microns, this polyester sediment cartridge can treat water with high flow rates and low pressure drops. In addition, their unique design offers exceptional dirt holding capacity for all types of applications. The filter media is pleated to maximize dirt-holding capacity and to extend the time period between changes or cleaning. This sediment cartridge is resistant to both bacteria and chemical attack making it highly suitable for a variety of residential, commercial and industrial applications. The 20 in. Big Blue filter housing is constructed of durable reinforced polypropylene and can operate effectively under a wide range of water conditions for different applications. The certified filter and housing is equipped with 1 in. FPT inlet and outlet ports for large volume and fast water flow. Housing wrench and bracket is also included for a complete whole house carbon filter system that provides chemical-free water delivered throughout all your faucets.
  • Strong, durable 20 in. housing tolerates broad range of chemicals and pressure variations
  • 1 in. FPT inlet and outlet ports for fast water flow perfect for whole house use, restaurants or cafes
  • 30 micron sediment filter effectively reduces sediment, sand, silt, scale and rust particles
  • Pleated filter cartridge design vastly expands media surface area and is reusable and washable
  • Easy installation and low maintenance system uses industry standard sized 20 in. filter
  • System comes with wall mounting bracket and housing wrench for easy install and service



Product Overview

Model #: CB1-SED20-BB
Internet #: 206496795

This 20 in. Big Blue (BB) whole house sediment water filtration system features a pleated sediment filter that is reusable and washable, designed to reduce dirt, sand, silt, and scale and rust particles. Rated at 30 microns, this polyester sediment cartridge can treat water with high flow rates and low pressure drops. In addition, their unique design offers exceptional dirt holding capacity for all types of applications. The filter media is pleated to maximize dirt-holding capacity and to extend the time period between changes or cleaning. This sediment cartridge is resistant to both bacteria and chemical attack making it highly suitable for a variety of residential, commercial and industrial applications. The 20 in. Big Blue filter housing is constructed of durable reinforced polypropylene and can operate effectively under a wide range of water conditions for different applications. The certified filter and housing is equipped with 1 in. FPT inlet and outlet ports for large volume and fast water flow. Housing wrench and bracket is also included for a complete whole house carbon filter system that provides chemical-free water delivered throughout all your faucets.

  • Strong, durable 20 in. housing tolerates broad range of chemicals and pressure variations
  • 1 in. FPT inlet and outlet ports for fast water flow perfect for whole house use, restaurants or cafes
  • 30 micron sediment filter effectively reduces sediment, sand, silt, scale and rust particles
  • Pleated filter cartridge design vastly expands media surface area and is reusable and washable
  • Easy installation and low maintenance system uses industry standard sized 20 in. filter
  • System comes with wall mounting bracket and housing wrench for easy install and service



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
This 20 in. Big Blue (BB) whole house sediment water filtration system features a pleated sediment filter that is reusable and washable, designed to reduce dirt, sand, silt, and scale and rust particles. Rated at 30 microns, this polyester sediment cartridge can treat water with high flow rates and low pressure drops. In addition, their unique design offers exceptional dirt holding capacity for all types of applications. The filter media is pleated to maximize dirt-holding capacity and to extend the time period between changes or cleaning. This sediment cartridge is resistant to both bacteria and chemical attack making it highly suitable for a variety of residential, commercial and industrial applications. The 20 in. Big Blue filter housing is constructed of durable reinforced polypropylene and can operate effectively under a wide range of water conditions for different applications. The certified filter and housing is equipped with 1 in. FPT inlet and outlet ports for large volume and fast water flow. Housing wrench and bracket is also included for a complete whole house carbon filter system that provides chemical-free water delivered throughout all your faucets.
  • Strong, durable 20 in. housing tolerates broad range of chemicals and pressure variations
  • 1 in. FPT inlet and outlet ports for fast water flow perfect for whole house use, restaurants or cafes
  • 30 micron sediment filter effectively reduces sediment, sand, silt, scale and rust particles
  • Pleated filter cartridge design vastly expands media surface area and is reusable and washable
  • Easy installation and low maintenance system uses industry standard sized 20 in. filter
  • System comes with wall mounting bracket and housing wrench for easy install and service



Product Overview

Model #: CB1-SED20-BB
Internet #: 206496795

This 20 in. Big Blue (BB) whole house sediment water filtration system features a pleated sediment filter that is reusable and washable, designed to reduce dirt, sand, silt, and scale and rust particles. Rated at 30 microns, this polyester sediment cartridge can treat water with high flow rates and low pressure drops. In addition, their unique design offers exceptional dirt holding capacity for all types of applications. The filter media is pleated to maximize dirt-holding capacity and to extend the time period between changes or cleaning. This sediment cartridge is resistant to both bacteria and chemical attack making it highly suitable for a variety of residential, commercial and industrial applications. The 20 in. Big Blue filter housing is constructed of durable reinforced polypropylene and can operate effectively under a wide range of water conditions for different applications. The certified filter and housing is equipped with 1 in. FPT inlet and outlet ports for large volume and fast water flow. Housing wrench and bracket is also included for a complete whole house carbon filter system that provides chemical-free water delivered throughout all your faucets.

  • Strong, durable 20 in. housing tolerates broad range of chemicals and pressure variations
  • 1 in. FPT inlet and outlet ports for fast water flow perfect for whole house use, restaurants or cafes
  • 30 micron sediment filter effectively reduces sediment, sand, silt, scale and rust particles
  • Pleated filter cartridge design vastly expands media surface area and is reusable and washable
  • Easy installation and low maintenance system uses industry standard sized 20 in. filter
  • System comes with wall mounting bracket and housing wrench for easy install and service



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand APEC Water Systems APEC Water Systems Pelican Water Pelican Water
Name All Purpose 1-Stage Whole House Water Filtration System With 4.5 x 20 in. Reusable and Washable Pleated Sediment Filter Whole House 1-Stage Water Filtration System High Capacity Carbon For All Purpose 10 in. Whole House Hot Water Sediment Post Filter System 20 in. Whole House Hot Water Sediment Post Filter System
Price
$130.68
$139.99
$182.58
$286.62
Ratings (3) (5) (1) (0)
View Product View Product View Product View Product

Specifications

Dimensions

Fitting size (in.)
1
Product Depth (in.)
9
Product Height (in.)
9
Product Width (in.)
26

Details

Bacteria Reduction (%)
0
Chlorine reduction (%)
0
Color/Finish
Blue
Copper Reduction (%)
0
Features
No additional features
Filtration Method
Sand or Sediment
Fitting style
Threaded
Fluoride Reduction (%)
0
Includes
Filter,Hardware
Indoor/Outdoor
Indoor
Iron Reduction (%)
0
Lead reduction (%)
0
Maximum feed water pressure (psi)
90
Maximum feed water temperature (F)
100
Maximum filtered water flow (gallons per min.)
1.67
Minimum feed water pressure (psi)
20
Minimum feed water temperature (F)
40
Number of filters included
1
Number of stages
1
Product Type
Filter System
Product Weight (lb.)
11lb
Returnable
90-Day
Water Filtration System Type
Whole House

Warranty / Certifications

Certifications and Listings
No Certifications or Listings
Manufacturer Warranty
1 Year

Specifications

Dimensions

Fitting size (in.)
1
Product Depth (in.)
9
Product Height (in.)
9
Product Width (in.)
26

Details

Bacteria Reduction (%)
0
Chlorine reduction (%)
0
Color/Finish
Blue
Copper Reduction (%)
0
Features
No additional features
Filtration Method
Sand or Sediment
Fitting style
Threaded
Fluoride Reduction (%)
0
Includes
Filter,Hardware
Indoor/Outdoor
Indoor
Iron Reduction (%)
0
Lead reduction (%)
0
Maximum feed water pressure (psi)
90
Maximum feed water temperature (F)
100
Maximum filtered water flow (gallons per min.)
1.67
Minimum feed water pressure (psi)
20
Minimum feed water temperature (F)
40
Number of filters included
1
Number of stages
1
Product Type
Filter System
Product Weight (lb.)
11lb
Returnable
90-Day
Water Filtration System Type
Whole House

Warranty / Certifications

Certifications and Listings
No Certifications or Listings
Manufacturer Warranty
1 Year

Questions & Answers

what is the lifespan of the filter? reusable and washable for x time? it gives the impression t...

what is the lifespan of the filter? reusable and washable for x time? it gives the impression that you need a new filter every 6 months and can wash in between?
Asked by: tomatolord
Hello, the average life span of this filter is about up to a year. It can be reusable/washable about up to three times before the core becomes clogged. If you need any help or assistance, feel free to give us a call we are happy to help! Best Regards, APEC Support Team 800-880-4808.
Answered by: APEC WATER SYSTEMS
Date published: 2017-08-16

does this system come in 20" and 10"?

does this system come in 20" and 10"?
Asked by: ralph
Hello, no, this 1-stage system only comes in the 20" size. If you need any help or assistance, feel free to give us a call we are happy to help! Best Regards, APEC Support Team 800-880-4808.
Answered by: APEC WATER SYSTEMS
Date published: 2017-05-08

How hard is it to install this system?

How hard is it to install this system?
Asked by: gumby8
Hello, since whole house filters are installed on the main water line, some pipe cutting will be required. Unless you are comfortable doing this yourself, we recommend most people to hire a professional plumbing service to install a whole house system. You may do an internet search or look up contractors/plumbers who have whole house water filtration installation experience in your local city phone book. If you need any help or assistance, feel free to give us a call we are happy to help! Best Regards, APEC Support Team 800-880-4808.
Answered by: APEC WATER SYSTEMS
Date published: 2016-10-28

Does this system filter our chlorine?

Does this system filter our chlorine?
Asked by: gumby8
This item reduce dirt, sand, silt, and scale and rust particles.
Answered by: CommunityAnswer
Date published: 2016-10-28
  • y_2019, m_11, d_10, h_13CST
  • bvseo_bulk, prod_bvqa, vn_bulk_3.0.0
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_5
  • loc_, sid_206496795, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 19ms
  • QUESTIONS, PRODUCT

Customer Reviews

APEC Water Systems All Purpose 1-Stage Whole House Water Filtration System With 4.5 x 20 in. Reusable and Washable Pleated Sediment Filter, Blue is rated 3.7 out of 5 by 3.
Rated 5 out of 5 by from Original reivew: Didn't really solve our problem, we still have lots of iron coming through the w... Original reivew: Didn't really solve our problem, we still have lots of iron coming through the water supply in our house. Updated review: I reviewed this right after purchase and to be fair the product works as described, it's just that our water situation required way more than this filter could do. We ended up having to install a really larger iron removal filter system that costs $$$$$. We tried to avoid that expenditure by starting with a less expensive filter but sadly it didn't work for us.
Date published: 2019-06-04
Rated 5 out of 5 by from Great Filter I needed a filter that could be installed down stream of my provectr system that would filter out particulate that may pass from the media filter. I also needed it to be of sufficient size to filter all water flowing to the house. In addition, I wanted a filter that could be cleaned and reused. The Apec 20 inch filter met all of my needs.
Date published: 2016-06-14
Rated 1 out of 5 by from Didn't really solve our problem, we still have lots of... Didn't really solve our problem, we still have lots of iron coming through the water supply in our house.
Date published: 2019-05-09
