Model # ASF-14-C2-BL

Internet #202321542

Active Ventilation 1007 CFM Black Powder Coated 15 Watt Solar Powered 14 in. Dia. Roof Mounted Attic Exhaust Fan
0843951006192

Active Ventilation

1007 CFM Black Powder Coated 15 Watt Solar Powered 14 in. Dia. Roof Mounted Attic Exhaust Fan

$28545 /each

Product Overview

Active Ventilation Products Aura Solar Attic Fan exhausts air continuously by using solar and wind power for optimum ventilation performance. Model ASF-14-C2-BL has a 15 Watt solar panel providing energy to 4 EC fans on sunny days to increase the CFM (cubic feet per minute) of 1007 of air flow performance. It is an excellent choice to exhaust attic heat in the summer to reduce hot attic temperatures. It will also exhaust moisture in the winter to keep the attic dry and cool to preserve attic insulation and prevent ice dams. The Aura Solar Attic Fan will produce 360 CFM at 11 mph without the solar powered fans through its patented engineered design with no moving parts. The attic fan is made of durable rust free aluminum and has 5 manufactured components: the vent head, 4 - EC fans, 1 - solar panel, vent collar and square flange. It has a 14 in. Dia throat opening with a 2 in. collar height and a 19 in. x 19 in. square flange. The vent head has three concentric cylinders with slotted vertical louvers. When air moves against the louvers of the outer and middle cylinders it is directed to create a circular airflow. The louvers of the inner cylinder face in the same direction as the air movement created by the outside cylinder. This air movement creates a Venturi effect which produces a vacuum or negative pressure to pull air from within the attic space.
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

Active Ventilation Products Aura Solar Attic Fan exhausts air continuously by using solar and wind power for optimum ventilation performance. Model ASF-14-C2-BL has a 15 Watt solar panel providing energy to 4 EC fans on sunny days to increase the CFM (cubic feet per minute) of 1007 of air flow performance. It is an excellent choice to exhaust attic heat in the summer to reduce hot attic temperatures. It will also exhaust moisture in the winter to keep the attic dry and cool to preserve attic insulation and prevent ice dams. The Aura Solar Attic Fan will produce 360 CFM at 11 mph without the solar powered fans through its patented engineered design with no moving parts. The attic fan is made of durable rust free aluminum and has 5 manufactured components: the vent head, 4 - EC fans, 1 - solar panel, vent collar and square flange. It has a 14 in. Dia throat opening with a 2 in. collar height and a 19 in. x 19 in. square flange. The vent head has three concentric cylinders with slotted vertical louvers. When air moves against the louvers of the outer and middle cylinders it is directed to create a circular airflow. The louvers of the inner cylinder face in the same direction as the air movement created by the outside cylinder. This air movement creates a Venturi effect which produces a vacuum or negative pressure to pull air from within the attic space.
  • No wiring or batteries required! Operates on solar energy
  • Does not require electricity to exhaust air from attics spaces
  • Solar panel operates at 12-Volt
  • Solar panel is manufactured tempered glass; rugged design to withstand high wind pressure, hail and snow load; providing exceptional panel rigidity
  • Quiet fan operation; designed to run up to 40,000 life hours per fan
  • Inner vertical louvers will keep insects, birds and squirrels from entering the vent allowing optimal air flow and no maintenance
  • Round aerodynamic design can with stand harsh weather and wind forces of up to 200 mph
  • Pitch capacity range: 3/12 to 12/12
  • Net free air: 144 sq. in. (1.00 sq. ft.) Use on pitched roofs 3/12 to 12/12
  • Ventilation rule 1:300: one unit per 600 sq. ft. of attic space (maximum up to 900 sq. ft.)
  • Black powder coating finish is significantly greater at resisting scratching, chipping, and oxidation
  • 1007 CFM at 0.1 SP
  • Removable vent head for easy access
  • Exhausts air continuously even after the sun sets or on cloudy days
  • Works 24/7, helps to reduce energy costs
  • 5 year warranty
  • Click here for more information on Electronic Recycling Programs

Product Overview

Model #: ASF-14-C2-BL
Internet #: 202321542

Active Ventilation Products Aura Solar Attic Fan exhausts air continuously by using solar and wind power for optimum ventilation performance. Model ASF-14-C2-BL has a 15 Watt solar panel providing energy to 4 EC fans on sunny days to increase the CFM (cubic feet per minute) of 1007 of air flow performance. It is an excellent choice to exhaust attic heat in the summer to reduce hot attic temperatures. It will also exhaust moisture in the winter to keep the attic dry and cool to preserve attic insulation and prevent ice dams. The Aura Solar Attic Fan will produce 360 CFM at 11 mph without the solar powered fans through its patented engineered design with no moving parts. The attic fan is made of durable rust free aluminum and has 5 manufactured components: the vent head, 4 - EC fans, 1 - solar panel, vent collar and square flange. It has a 14 in. Dia throat opening with a 2 in. collar height and a 19 in. x 19 in. square flange. The vent head has three concentric cylinders with slotted vertical louvers. When air moves against the louvers of the outer and middle cylinders it is directed to create a circular airflow. The louvers of the inner cylinder face in the same direction as the air movement created by the outside cylinder. This air movement creates a Venturi effect which produces a vacuum or negative pressure to pull air from within the attic space.

  • No wiring or batteries required! Operates on solar energy
  • Does not require electricity to exhaust air from attics spaces
  • Solar panel operates at 12-Volt
  • Solar panel is manufactured tempered glass; rugged design to withstand high wind pressure, hail and snow load; providing exceptional panel rigidity
  • Quiet fan operation; designed to run up to 40,000 life hours per fan
  • Inner vertical louvers will keep insects, birds and squirrels from entering the vent allowing optimal air flow and no maintenance
  • Round aerodynamic design can with stand harsh weather and wind forces of up to 200 mph
  • Pitch capacity range: 3/12 to 12/12
  • Net free air: 144 sq. in. (1.00 sq. ft.) Use on pitched roofs 3/12 to 12/12
  • Ventilation rule 1:300: one unit per 600 sq. ft. of attic space (maximum up to 900 sq. ft.)
  • Black powder coating finish is significantly greater at resisting scratching, chipping, and oxidation
  • 1007 CFM at 0.1 SP
  • Removable vent head for easy access
  • Exhausts air continuously even after the sun sets or on cloudy days
  • Works 24/7, helps to reduce energy costs
  • 5 year warranty
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Price
$201.22 /each
$285.45 /each
$285.45 /each
$291.10 /each
Name 740 CFM Black Powder Coated 10 Watt Solar Powered 12 in. Dia. Retrofit Attic Roof Fan 1007 CFM Black Powder Coated 15 Watt Solar Powered 14 in. Dia. Roof Mounted Attic Exhaust Fan 1007 CFM Weatherwood Powder Coated 15 Watt Solar Powered 14 in. Dia. Roof Mounted Attic Exhaust Fan 1007 CFM Brown Powder Coated 15 Watt Solar Powered 14 in. Dia. Roof Mounted Attic Exhaust Fan
Brand Active Ventilation Active Ventilation Active Ventilation Active Ventilation
Ratings (2) (3) (3) (8)
Power Type Solar Solar Solar Solar
Wildlife Guard Yes Yes Yes Yes
Ventilation Type Roof Roof Roof Roof
Material Aluminum Aluminum Aluminum Aluminum
View Product View Product View Product View Product

Specifications

Dimensions

Cut-Out Diameter (in.)
14.0
Product Depth (in.)
19
Product Height (in.)
12
Product Width (in.)
19

Details

Color Family
Black
Color/Finish Family
Black
Material
Aluminum
Power Type
Solar
Product Weight (lb.)
12lb
Recommended Sq. Ft.
600.0
Returnable
90-Day
Thermostat Controlled
No
Ventilation Type
Roof
Voltage (volts)
12
Wattage (watts)
15
Wildlife Guard
Yes

Warranty / Certifications

Manufacturer Warranty
5 YEAR

Specifications

Dimensions

Cut-Out Diameter (in.)
14.0
Product Depth (in.)
19
Product Height (in.)
12
Product Width (in.)
19

Details

Color Family
Black
Color/Finish Family
Black
Material
Aluminum
Power Type
Solar
Product Weight (lb.)
12lb
Recommended Sq. Ft.
600.0
Returnable
90-Day
Thermostat Controlled
No
Ventilation Type
Roof
Voltage (volts)
12
Wattage (watts)
15
Wildlife Guard
Yes

Warranty / Certifications

Manufacturer Warranty
5 YEAR

Questions & Answers

  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 215ms
  • QUESTIONS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Customer Reviews

1007 CFM Black Powder Coated 15 Watt Solar Powered 14 in. Dia. Roof Mounted Attic Exhaust Fan is rated 3.7 out of 5 by 3.
Rated 5 out of 5 by from This product is great! This product was perfect. It is lightweight and easy to install. They work great and look good on the house.
Date published: 2012-10-09
Rated 5 out of 5 by from I love this product. This product was so easy to put up. My husband had it done in about half an hour. It may the house so less hot. I had to turn up the temperture,becauseit got to cold inside.I love it,for the money I pay it was worth it. I told my sister about it and she said she was going to get one.
Date published: 2012-08-07
Rated 1 out of 5 by from Worst investment I've made in my home This was the worst money I've ever paid for a home improvement! This "fan" consists of 4 computer size fans run by a solar panel for power. You pay for the solar panel, not the "fan". There are no other moving parts so it does NOT act with wind at night to help with ventilation. I'm VERY disappointed. Shame on me for buying this product!
Date published: 2013-06-27
