ENERGY STAR Certified Ultra Quiet Variable Dual Speed Ceiling Bathroom Exhaust Fan with LED Light
- Almost Silent, Energy Efficient Bathroom Exhaust Fan with Light
- Adjustable CFM for bathrooms and continuous operation settings
- Perfect for small to large bathrooms including master bathrooms
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The EVL Series Exhaust Fan with LED Light from Air King provides energy efficient operation at almost silent sounds levels. The variable, dual speed motor can be set from 30 to 130 CFM and adjusted after the fan has been installed. The 6 in. round duct collar ensures proper air flow making it an ideal solution to comply with ASHRAE 62.2 whole dwelling or local exhaust as well as California Title 24. Perfect for standard to larger sized bathrooms.
Highlights
- White grill matches any decor
- Durable 23-Gauge galvanized steel housing provides years of worry free operation
- Almost silent motor operates at less than 0.3 Sones
- Easily installs using the included adjustable hanging brackets
- Can be used to comply with ASHRAE 62.2 standards as well as Califirnia title 24
- 30 to 130 CFM exhaust reduces moisture to prevent mildew
- 30 to 130 CFM at less than 0.3 Sones
- Variable speed for almost all residential bathrooms
- Uses (1) 8-Watt LED lamp, included
- ENERGY STAR certified for energy efficient operation
- UL listed for use above the shower
 2098690.jpg)
- Click here for more information on Electronic Recycling Programs
- Return Policy
Product Information
Additional Resources
Shop All Air KingSpecifications
Dimensions
Housing Length (in.) | 12.875 |
|---|---|
Housing Width (in.) | 12.75 |
Product Height (in.) | 10.25 in |
Product Width (in.) | 14.25 in |
Details
Air Volume (CFM) | 100, 110, 120, 30, 50, 60, 70, 80, 90 |
|---|---|
Amperage (amps) | 0.3 |
Color/Finish | White |
Duct Compatible Sizes | 6 in |
Features | Adjustable Fan Speed, Light |
Grill Shape | Square |
Housing Material | Galvanized Steel |
Included | Hardware |
Installation Type | Ceiling |
Light Bulb Base Code | GU24 |
Light Bulb Type Allowed | LED |
Light Bulb Type Included | LED |
Maximum Light Bulb Wattage (watts) | 8 |
Maximum Room Size (sq. ft.) | 150 |
Mount Type | Recessed |
Number of Bulbs Required | 1 |
Pack Size | 1 |
Product Weight (lb.) | 15.6 lb |
Returnable | 90-Day |
Room Size | Large Room Fan |
Voltage (V) | 115/120 |
Wattage (watts) | 37 |
Warranty / Certifications
Manufacturer Warranty | 5 Year Limited |
|---|
Questions & Answers
how much does the sound level increase using a 4 inch vent at 150 cfm? (What is the sone level?)
I want to add a timer function to the high/low yellow control wires. But I don’t know what the yellow wires do. Do they close a line voltage? Can I close the dual speed(yellow wires) with a Leviton decora+ timer switch?
May I install this unit with just one switch? If so, what am I sacrificing if anything?
Hi Bob, thank you for your inquiry. I believe the best advice would be to talk to one of our specialty department professionals at your local Home Depot store. For any other questions, please visit your nearest local Home Depot store. We appreciate your business and look forward to serving you in the future. Thank you for shopping Home Depot.
Can this be installed on a vaulted ceiling? My bathroom has a tall ceiling with walls ranging from 9 feet to 13 feet. I planned on mounting this above the shower (about 12 feet above the floor) but didn't know if the angle would affect the unit's performance. Is an angled installation validated?
These fans can be installed into a vaulted ceiling given you have enough clearance. It is also important that the fan be facing in a way that allows the backdraft damper to open and close properly.
Does this fan run continuously? Or can it run strictly off the humidity sensor? That is, leave the wall switch on and the fan turns on above a certain humidity level and turns off below a certain humidity level?
The fan runs at low speed continuously and when high humidity is detected it switches to high speed.
This fan is designed to run continuous and can be set up at time of installation for the continuous operation. In addition the humidity sensor will kick the fan on at the humidity level that it has been set at. Please see link to instruction manual. We also have 2 videos on our website, one on installation and one on setting the humidistat. www.airkinglimited.com http://www.airkinglimited.com/instructions/EVDIO.pdf
Where can I find installation and also operating instructions?
Go to the product page and look for the info and guides tabs , select the info you want and the PDF will load. Here is the info on this product. https://images.homedepot-static.com/catalog/pdfImages/10/10eaa4de-d898-4e7b-8710-4bd0c84296c7.pdf
You can find our installation and operating manual on our website www.airkinglimited.com, go to the download tab of the product and click on instructions
Installation instructions: https://images.homedepot-static.com/catalog/pdfImages/77/778db39c-4bc2-4bcc-bb03-5bb3d1b3ef05.pdf Operating instructions are in section 10 of the installation guide.
Can this be installed vertically (through a wall)?
It can be installed in a ceiling vertically, it can be installed in a wall but it would have to be horizontally, and you would have to make sure you have a thick enough wall to hold the housing
It only vents out the side. There is no option to vent out the top, which would be needed if you want to mount it in a wall.
how bright is the light? Needs to be bright for my installation!
The Air King BFQL series is 450 lumens while most of the other series are 800 lumens - these are all for units that include the bulbs. Non ENERGY STAR units can utilize brighter bulbs - usually 60 watt or more.
