Bosch

15 Amp Corded 10 in. Dual-Bevel Sliding Glide Miter Saw with 60-Tooth Carbide Saw Blade

$ 572 54
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

+

Product Overview

The innovation responsible for both the unique appearance and the unparalleled level of performance of the Bosch 10 in. Dual Bevel Glide Miter Saw is Bosch's patented Axial-Glide System. Beyond giving the saw its distinctive profile, Bosch's Axial-Glide System eliminates three key challenges miter saw users have endured since the first slide systems debuted many years ago. While the traditional sliding compound miter saw approach enables users to make wider cross cuts that system takes up more space and is prone to misalignment and stickiness over time. By replacing the sliding rail system with a hinged or articulating glide arm system similar to the linkage used in a four-bar suspension design Bosch created a more compact miter saw that delivers durable precision, remaining true and smooth over time.
  • Expanded cutting capacity: 12 in. horizontal capacity (nominal); 5-1/2 in. vertical capacity against the fence (base); 6 in. crown capacity against the fence (45° spring)
  • Upfront bevel controls all-metal bevel lock lever and range selector located upfront for quick and easy bevel settings without reaching behind the saw
  • Chop/crown lock: locks head in place for maximum chop cutting capacity for upright base molding and nested crown molding
  • Tall sliding 4-1/4 in. fences: for easy bevel setups and increased crown and base molding capacity
  • Large easy-to-read uniform bevel and stainless-steel miter scales: 52° left/60° right miter capacity; 47° left/47° right bevel capacity with marked detents and roof pitch angles
  • Includes: 10 in. 60-tooth blades, material clamp, dust bag
  • Adjustable miter detents: detents at 0°, 15°, 31.6°, 22.5°, 45°, 60° right super-accurate and durable design
  • Push-button miter detent override easy-to-access thumb actuated control right up front for fine miter angle adjustment
  • Bevel detents: 0°, 33.9°, 45° left/right for accurate cuts
  • Category best 90% dust collection optimized for cutting 2X material with a vacuum
  • Ergonomic ambidextrous trigger handle with soft grip large form fitting ergonomic handle provides comfort for all-day use
  • Click here for more information on Electronic Recycling Programs

Product Overview

Model #: CM10GD
Internet #: 204668975

The innovation responsible for both the unique appearance and the unparalleled level of performance of the Bosch 10 in. Dual Bevel Glide Miter Saw is Bosch's patented Axial-Glide System. Beyond giving the saw its distinctive profile, Bosch's Axial-Glide System eliminates three key challenges miter saw users have endured since the first slide systems debuted many years ago. While the traditional sliding compound miter saw approach enables users to make wider cross cuts that system takes up more space and is prone to misalignment and stickiness over time. By replacing the sliding rail system with a hinged or articulating glide arm system similar to the linkage used in a four-bar suspension design Bosch created a more compact miter saw that delivers durable precision, remaining true and smooth over time.

  • Expanded cutting capacity: 12 in. horizontal capacity (nominal); 5-1/2 in. vertical capacity against the fence (base); 6 in. crown capacity against the fence (45° spring)
  • Upfront bevel controls all-metal bevel lock lever and range selector located upfront for quick and easy bevel settings without reaching behind the saw
  • Chop/crown lock: locks head in place for maximum chop cutting capacity for upright base molding and nested crown molding
  • Tall sliding 4-1/4 in. fences: for easy bevel setups and increased crown and base molding capacity
  • Large easy-to-read uniform bevel and stainless-steel miter scales: 52° left/60° right miter capacity; 47° left/47° right bevel capacity with marked detents and roof pitch angles
  • Includes: 10 in. 60-tooth blades, material clamp, dust bag
  • Adjustable miter detents: detents at 0°, 15°, 31.6°, 22.5°, 45°, 60° right super-accurate and durable design
  • Push-button miter detent override easy-to-access thumb actuated control right up front for fine miter angle adjustment
  • Bevel detents: 0°, 33.9°, 45° left/right for accurate cuts
  • Category best 90% dust collection optimized for cutting 2X material with a vacuum
  • Ergonomic ambidextrous trigger handle with soft grip large form fitting ergonomic handle provides comfort for all-day use
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
The innovation responsible for both the unique appearance and the unparalleled level of performance of the Bosch 10 in. Dual Bevel Glide Miter Saw is Bosch's patented Axial-Glide System. Beyond giving the saw its distinctive profile, Bosch's Axial-Glide System eliminates three key challenges miter saw users have endured since the first slide systems debuted many years ago. While the traditional sliding compound miter saw approach enables users to make wider cross cuts that system takes up more space and is prone to misalignment and stickiness over time. By replacing the sliding rail system with a hinged or articulating glide arm system similar to the linkage used in a four-bar suspension design Bosch created a more compact miter saw that delivers durable precision, remaining true and smooth over time.
  • Expanded cutting capacity: 12 in. horizontal capacity (nominal); 5-1/2 in. vertical capacity against the fence (base); 6 in. crown capacity against the fence (45° spring)
  • Upfront bevel controls all-metal bevel lock lever and range selector located upfront for quick and easy bevel settings without reaching behind the saw
  • Chop/crown lock: locks head in place for maximum chop cutting capacity for upright base molding and nested crown molding
  • Tall sliding 4-1/4 in. fences: for easy bevel setups and increased crown and base molding capacity
  • Large easy-to-read uniform bevel and stainless-steel miter scales: 52° left/60° right miter capacity; 47° left/47° right bevel capacity with marked detents and roof pitch angles
  • Includes: 10 in. 60-tooth blades, material clamp, dust bag
  • Adjustable miter detents: detents at 0°, 15°, 31.6°, 22.5°, 45°, 60° right super-accurate and durable design
  • Push-button miter detent override easy-to-access thumb actuated control right up front for fine miter angle adjustment
  • Bevel detents: 0°, 33.9°, 45° left/right for accurate cuts
  • Category best 90% dust collection optimized for cutting 2X material with a vacuum
  • Ergonomic ambidextrous trigger handle with soft grip large form fitting ergonomic handle provides comfort for all-day use
  • Click here for more information on Electronic Recycling Programs

Product Overview

Model #: CM10GD
Internet #: 204668975

The innovation responsible for both the unique appearance and the unparalleled level of performance of the Bosch 10 in. Dual Bevel Glide Miter Saw is Bosch's patented Axial-Glide System. Beyond giving the saw its distinctive profile, Bosch's Axial-Glide System eliminates three key challenges miter saw users have endured since the first slide systems debuted many years ago. While the traditional sliding compound miter saw approach enables users to make wider cross cuts that system takes up more space and is prone to misalignment and stickiness over time. By replacing the sliding rail system with a hinged or articulating glide arm system similar to the linkage used in a four-bar suspension design Bosch created a more compact miter saw that delivers durable precision, remaining true and smooth over time.

  • Expanded cutting capacity: 12 in. horizontal capacity (nominal); 5-1/2 in. vertical capacity against the fence (base); 6 in. crown capacity against the fence (45° spring)
  • Upfront bevel controls all-metal bevel lock lever and range selector located upfront for quick and easy bevel settings without reaching behind the saw
  • Chop/crown lock: locks head in place for maximum chop cutting capacity for upright base molding and nested crown molding
  • Tall sliding 4-1/4 in. fences: for easy bevel setups and increased crown and base molding capacity
  • Large easy-to-read uniform bevel and stainless-steel miter scales: 52° left/60° right miter capacity; 47° left/47° right bevel capacity with marked detents and roof pitch angles
  • Includes: 10 in. 60-tooth blades, material clamp, dust bag
  • Adjustable miter detents: detents at 0°, 15°, 31.6°, 22.5°, 45°, 60° right super-accurate and durable design
  • Push-button miter detent override easy-to-access thumb actuated control right up front for fine miter angle adjustment
  • Bevel detents: 0°, 33.9°, 45° left/right for accurate cuts
  • Category best 90% dust collection optimized for cutting 2X material with a vacuum
  • Ergonomic ambidextrous trigger handle with soft grip large form fitting ergonomic handle provides comfort for all-day use
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand Makita Bosch Makita Bosch
Name 13 Amp 10 in. Slide Compound Miter Saw 15 Amp Corded 10 in. Dual-Bevel Sliding Glide Miter Saw with 60-Tooth Carbide Saw Blade 18-Volt 5.0Ah X2 LXT Lithium-Ion (36V) Brushless Cordless 10 in. Dual-Bevel Sliding Compound Miter Saw with Laser Kit 15 Amp 12 in. Corded Dual-Bevel Sliding Glide Miter Saw Combo Kit with Bonus Gravity Rise Wheeled Miter Saw Stand
Price
$355.42
$572.54
$679.00
$968.06
Ratings (48) (84) (104) (394)
Blade Diameter 10
Maximum Cutting Thickness (in.) 3.625 6 2.8125 4
Miter Saw Type Sliding Compound Sliding Compound Sliding Compound Sliding Compound
Bevel Type Dual Dual Dual Dual
Power Tool Features Electric Brake Electric Brake,Positive Stops Keyed Blade Change,Laser Guide Electric Brake,Positive Stops
Cordless/ Corded Corded Corded Cordless Corded
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
32
Product Height (in.)
20.5
Product Width (in.)
26.5
Table Length (in.)
13.75
Table Width (in.)
27

Details

45 Degree Crosscut Capacity Maximum
3.25 x 12.5
90 Degree Crosscut Capacity Maximum - Left
4 x 12
90 Degree Crosscut Capacity Maximum - Right
4 x 12
Amperage (amps)
15
Arbor Size
0.625
Bench & Stationary Tool Type
Slide Miter Saw
Bevel Type
Dual
Blade Diameter (in.)
10
Color Family
Blue
Condition
New
Construction Material
Aluminum
Cord Length (ft.)
6
Cordless/ Corded
Corded
Dust Collection Method
Bag
Included Accessories
Allen Key/Wrench
Maximum Cutting Thickness (in.)
6
Maximum Degree Miter Cuts - Left
52
Maximum Degree Miter Cuts - Right
60
Maximum Speed (rpm)
4800
Miter Saw Type
Sliding Compound
Portability
Bench
Power Tool Features
Electric Brake,Positive Stops
Product Weight (lb.)
64lb
Returnable
90-Day
Tools Product Type
Power Tool

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
Limited 1 Year

Specifications

Dimensions

Product Depth (in.)
32
Product Height (in.)
20.5
Product Width (in.)
26.5
Table Length (in.)
13.75
Table Width (in.)
27

Details

45 Degree Crosscut Capacity Maximum
3.25 x 12.5
90 Degree Crosscut Capacity Maximum - Left
4 x 12
90 Degree Crosscut Capacity Maximum - Right
4 x 12
Amperage (amps)
15
Arbor Size
0.625
Bench & Stationary Tool Type
Slide Miter Saw
Bevel Type
Dual
Blade Diameter (in.)
10
Color Family
Blue
Condition
New
Construction Material
Aluminum
Cord Length (ft.)
6
Cordless/ Corded
Corded
Dust Collection Method
Bag
Included Accessories
Allen Key/Wrench
Maximum Cutting Thickness (in.)
6
Maximum Degree Miter Cuts - Left
52
Maximum Degree Miter Cuts - Right
60
Maximum Speed (rpm)
4800
Miter Saw Type
Sliding Compound
Portability
Bench
Power Tool Features
Electric Brake,Positive Stops
Product Weight (lb.)
64lb
Returnable
90-Day
Tools Product Type
Power Tool

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
Limited 1 Year

Questions & Answers

Does the CM10GD have a depth stop for dados?

Asked by: Bob
Yes, the saw has depth stop for dados.
Answered by: CommunityAnswer
Date published: 2018-12-02

Can you hook up the saw to an external dust collection system? If so whale size hose connection d...

Can you hook up the saw to an external dust collection system? If so whale size hose connection does the bag have?
Asked by: Mark
Yes, this saw hooks up to external dust extraction. Bosch sells a hookup adaptor that fits in where the dust bag goes, not sure of the size.
Answered by: Jay
Date published: 2019-01-28

How loud is this saw? I have a Hitachi that makes my ears bleed, even with ear protection!

Asked by: DogwoodD
With ear protection you will be fine.
Answered by: BZ
Date published: 2018-09-20

Does this saw have a "soft-start" motor? Will it accept a laser?

Asked by: kh
It does not have a soft start motor. In fact it will shift your workpiece if you don't secure it extra tight.
Answered by: BZ
Date published: 2018-02-28
  • y_2019, m_8, d_17, h_4CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_17
  • loc_, sid_204668975, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 54ms
  • QUESTIONS, PRODUCT

Customer Reviews

15 Amp Corded 10 in. Dual-Bevel Sliding Glide Miter Saw with 60-Tooth Carbide Saw Blade is rated 4.4 out of 5 by 84.
Rated 4 out of 5 by from Uncommonly Smooth Action, Tighter Tolerances In The Glide Feature Would Make It Five Star I have been chasing one of these saws for a while starting with a display I saw at a local store several years ago, it was a twelve inch model. A radical change from the norm of various incarnations of the tube rail slide is what caught my eye. I don't like twelve inch saws for reasons I won't bore you with here, and so I waited and bided my time, and sure enough they came up with a ten inch version. Considerably more RPM at the blade and overall rigidity is pretty good on the ten inch model. For a space saving stationary shop saw that won't be getting thrown in the truck much, this is the saw to buy. Four star rating is for the fiddly adjustments out of the box that are required to get all the detents stopping true, and the cumulative flex in the various sections of the glide mechanism that add up to about a half degree either way. It is a Chinese built saw after all, no sense deluding ourselves about that. Be forewarned it is a heavy pig, and only a pound lighter than it's bigger cousin.
Date published: 2013-12-17
Rated 5 out of 5 by from Great miter saw There is a lot that i like about this saw. It is my upgrade from the slidig saw and i love it. Pros: Smooth gliding action, you can put right against the wall so it's a space saver, all controls are in the front of the saw so you dont have to reach out in the back to set your bevel cuts, cutting angles above 45° degrees also helpful 47 bevel and 60 miter, you can lock arm in the right position to cut crown moldings also cutting depth adjustment for cutting notches or something else. Cons: Material supporting clamp is hard to use and takes too much time with that screw type adjustment I would recommend some type of quick locking clamps for it. Dust extraction is not too bad but could be improved, i have made some improvements to it and now it catches more dust. This saw is not cheap so should have nice laser guide right out of the box. Saw is pretty heavy so not very portable by one person, i have to use wheeled stand to transport to the job site and it takes a lot of space in my truck.
Date published: 2016-11-18
Rated 5 out of 5 by from Professional Results I purchased this saw, along with a T4B stand, in the spring of 2015 for the installation phase of my cabinetry business. This is an excellent site saw when used in conjunction with the gravity stand, as it is easy to load, unload, and set up single-handed. The dual bevel comes in quite handy for miters on baseboards, and wide apron molding under crown. The motion of the articulating glide is fluid on crosscuts and miters, though with bevels the operator needs to be attentive to keeping even pressure on the handle to keep the cut straight. The safety button is aggravating when one is trying to raise the guard slightly to sight the blade to the cut mark on the work. It is impossible to sight and start the saw, as the thumb must release the guard to depress the safety. The slots in the guard aren't sufficient for sighting with the guard in the down position. All of the other features of the saw are very user-friendly. We believe it was definitely a good investment, and highly recommend this product.
Date published: 2015-12-10
Rated 4 out of 5 by from Good saw Bought this saw two weeks ago along with T4B Base .The base is great easy to assemble , study and easily collapses for mobility or storage. Now for the saw, came out of the box way out of calibration in every way. Would like to see a micro adjustment on the miter. Took some time to true up every thing to my liking. Now that the saw is calibrated it works great. Glide is silky smooth with no deflection or play unless you pull or push real hard. Dust collection and blade are decent. The things I don't like are the plastic miter rail and detent handle already showing signs of ware, and the bevel lock won't release completely when working with wide stock. I might be able to flip it 180 if every thing works. I'll see how good Bosch replacement warranty is for the plastic. Hope there durable in the cold. Over all real impressed with the saw accuracy true clean cuts. I also installed the laser guide the other day really like it but might be worthless in direct sunlight. Time and use will be the true test.
Date published: 2016-03-23
Rated 5 out of 5 by from Superb Design, flawless functionality I received the CM10GD sliding dual bevel Sliding Miter saw a few days ago as a gift along with the Bosch Miter saw stand. Assembling the sturdy stand was very easy. The Miter Saw documentation was easy to follow and I had the saw in operation in a few minutes. A quick project was completed and the saw performed flawlessly. The documentation mentioned about adjusting the miters and bevel scales, but when I checked these, there were accurately set right out of the box. I am not a professional woodworker or carpenter and purchased the saw to assist me in building items for the house and garden. Up till now, I had only used a circular saw and a router for woodworking projects. I am just learning all the optional uses of this Miter Saw and am amazed at the versatility and accuracy of the device. The functionality and design exceeded my expectations. I strongly recommend purchasing the Bosch Stand with the saw, it eases the transport and is rock solid once set up. Best gift in years.
Date published: 2015-11-01
Rated 5 out of 5 by from Couldn’t ask for a better saw! I am the envy... Couldn’t ask for a better saw! I am the envy of all the other carpenters.
Date published: 2019-07-17
Rated 1 out of 5 by from Great Design, Poor Execution When I first saw this saw I had to have it. When I first played with the glide system at a wood show I had to have it. When I finally saved up enough money to buy it I got it. For the last year I've been fighting with it to get it to cut accurately. Today I read some reviews about the arbor not being aligned with the glide mechanism. I went out and tested my saw and found this to be the problem that has been plaguing me. I was able to get my blade perpendicular to the fence but that doesn't matter if the blade travels from left to right as you push the saw in. I also discovered that the vertical travel of the blade down during chop cuts is also off. In 3 1/2" cutting from the right side the blade travels a 1/16" from right to left. By the time I've finished my cut the blade no longer touches the board I cut. From what I have read there is no correcting this issue. Love the idea of saving space in my little shop. Love the fluid motion of the glide arms. Hate the fact that the blade couldn't stay true during any of the cutting motions. Bosch is correct in that their tools are very precise. I get the same results with every cut. Unfortunately they have compromised accuracy, I can't get the results I want.
Date published: 2016-11-15
Rated 5 out of 5 by from Precise cuts over 2 years I have this saw almost 2 years and precision is still like day one. This saw is amazing and every pro should invest on this rather then getting sliding mitersaw. You can cut any material with it saw has plenty power. Since its so precise you dont waste no material (speacially croen mouldinh) everytime cuts it dead on. I purchased the ls010 laser too so no more guessing where the blades is gonna land. Bevel control in the front makes bevel cuts a breeze. You can move from right to left in matter of seconds. No more leaning back to saw to adjust the bevel.
Date published: 2016-12-29
