2-Gang 25 cu. in. Electrical PVC Old Work Electrical Switch and Outlet Box (B225R-UPC)
- Perfect for use with non-metallic sheathed cable
- Made of rust-resistant thermoplastic for durability
- UL listed for safety
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The Carlon Zip Box Blue 2-Gang 25 cu. in. Old Work Non-Metallic Switch and Outlet Box are designed to work with non-metallic sheathed cable in accordance with Article 314 of the NEC. Great for light commercial and residential applications, the box is crafted with non-conductive PVC for durability and is fire rated and UL listed to help ensure safety.
Highlights
- Residential and commercial use
- Use with non-metallic cable on accordance with code
- Thermoplastic construction resists rust and won't conduct electricity
- Mounting ears and swing clamps provide versatile installation options
- Sized for standard devices and switches and extra capacity for wiring and/or larger devices
- Built-in cable clamps hold wires firmly in place
- For safety, product is UL listed and fire rated
- Click here to shop everything Carlon
- Return Policy
Product Information
Specifications
Dimensions
Product Depth (in.) | 2.75 in |
|---|---|
Product Height (in) | 4.3 |
Product Width (in.) | 4.00 in |
Details
Application | Wall |
|---|---|
Material | PVC |
Metallic/Non-Metallic | Non-Metallic |
Number of Gangs | 2 |
Number of Knockouts/Holes | 1 |
Pack Size | 1 |
Returnable | 90-Day |
Work Type | Old Work |
Warranty / Certifications
Certifications and Listings | UL Listed |
|---|---|
Manufacturer Warranty | Yes |
Questions & Answers
The runway for the clamp is just a hair short of being able to handle a standard drywall + osb thickness, is there a version of this product that could handle this thickness?
If you have access to a stud, consider using part number B249B. This box works for both new and old work applications. If you remove the side mounting tab, you gain additional flexibility by fastening the box directly to the stud with screws.
Can you use divider plate with this
This box does not accept a divider plate. Please consider part number B249B which accepts divider plate part number SCDIVS.
Cut out dimension, 4 x 4 box old work
Cut dimensions are 3.71" (H) by 3.96 (W)
What size is the KO? Is this big enough for 3 3-conductor #6 NM?
The KO on this box is 1/2", which accepts a 3/8 Connector. You would need to make sure that brand connector you use allows for a #6 wire.
Can this box be used as a junction box as well?
Yes, this box can be used as a junction box as long it stays exposed.
Will this work with a NEMA 14-50?
Yes, this product is generally suitable for NEMA 14-50 outlets, as it's designed for non-metallic sheathed cable and has enough capacity for wiring and devices.
How do I secure a blank cover plate to this box? The only screw holes that line up are the ones used by the box’s clamps, but even those results in the cover being cockeyed.
You have to purchase a two gang blank cover. And the holes for the cover will line up with the holes for the devices on the box.
What size is the round knock-out in the back of the box?
The round knockout is 1/2".
Viewing 1-8 of 26
Customer Reviews
4.7 out of 5
Loading Recommendations
Compare Key Features
Product Snapshot | |||
|---|---|---|---|
Ideal for homeowners looking for durable and safe electrical boxes, making installation easier and more efficient. | Ideal for homeowners looking for a fire-rated electrical box, ensuring safety and code compliance for new construction projects. | Ideal for homeowners looking for dual-voltage applications, making installation easier. This old work box is perfect for those who need a durable and reliable solution. | Ideal for new work ceiling installations, this PVC box safely supports fixtures up to 35 lbs. with easy non-metallic cable connections. |
Capacity | |||
25 cu. in. | 44 cu. in. | 20 cu. in. | |
Dimensions | |||
H 4.3 in. x W 4.0 in. x D 2.7 in. | H 3.7 in x W 5.8 in x D 2.75 in | H 3.75 in x W 4 in x D 3 in | H 4 in. x W 4 in. x D 2.25 in. |
Fire Resistance | |||
Weatherproof | |||
Number of Gangs | |||
2 | 3 | 2 | 1 |
