Model # DWS709

Internet #205909852

DEWALT 15 Amp 12 in. Dual Bevel Sliding Compound Miter Saw
0885911366922

DEWALT

15 Amp 12 in. Dual Bevel Sliding Compound Miter Saw

  • Dual horizontal steel rails with innovative clamping mechanism
  • Linear ball bearings deliver an accurate, durable and compact saw
  • Adjustable stainless steel miter detent plate
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Dual horizontal steel rails with innovative clamping mechanism
  • Linear ball bearings deliver an accurate, durable and compact saw
  • Adjustable stainless steel miter detent plate
The DEWALT DWS709 miter saw is designed with a powerful 15 Amp, 3800 RPM motor that delivers exceptional power and durability. A tall sliding fence supports crown molding up to 5-1/2 in. nested and base molding up to 4-1/2 in. vertically against the fence while easily sliding out of the way for bevel cuts. This saw features an exclusive back fence design that cuts up to 2 in. x 14 in. dimensional lumbers at 90 degrees and 2 in. x 10 in. at 45 degrees.
  • Adjustable plate with 13 positive stops improves productivity and ensures cutting accuracy
  • Miters 60 degrees to the right and 50 degrees to the left, providing increased capacity
  • Oversized bevel scale makes bevel-angle adjustments accurate and easy
  • Compact, lightweight design (51 lbs.) allows for easy transport and storage
  • Precise miter system and machined base fence enhance durability and cutting accuracy
  • 15 Amp, 3800 RPM motor powers through rigorous applications
  • Includes carbide blade, blade wrench and dust bag
  • Backed by a 3-year limited DEWALT warranty
  • Click here for more information on Electronic Recycling Programs
  • California residents see Prop 65 WARNINGS

Product Overview

  • Dual horizontal steel rails with innovative clamping mechanism
  • Linear ball bearings deliver an accurate, durable and compact saw
  • Adjustable stainless steel miter detent plate
Model #: DWS709
Internet #: 205909852

The DEWALT DWS709 miter saw is designed with a powerful 15 Amp, 3800 RPM motor that delivers exceptional power and durability. A tall sliding fence supports crown molding up to 5-1/2 in. nested and base molding up to 4-1/2 in. vertically against the fence while easily sliding out of the way for bevel cuts. This saw features an exclusive back fence design that cuts up to 2 in. x 14 in. dimensional lumbers at 90 degrees and 2 in. x 10 in. at 45 degrees.

  • Adjustable plate with 13 positive stops improves productivity and ensures cutting accuracy
  • Miters 60 degrees to the right and 50 degrees to the left, providing increased capacity
  • Oversized bevel scale makes bevel-angle adjustments accurate and easy
  • Compact, lightweight design (51 lbs.) allows for easy transport and storage
  • Precise miter system and machined base fence enhance durability and cutting accuracy
  • 15 Amp, 3800 RPM motor powers through rigorous applications
  • Includes carbide blade, blade wrench and dust bag
  • Backed by a 3-year limited DEWALT warranty
  • Click here for more information on Electronic Recycling Programs
  • California residents see Prop 65 WARNINGS

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Customers Also Compared These

Price
Was $449.00
$349.00
Save $100.00 (22%)
See Lower Price in Cart
Was $499.00
$369.00
Save $130.00 (26%)
Was $599.00
$499.00
Save $100.00 (17%)
Name 15-Amp Corded 12 in. Double-Bevel Sliding Compound Miter Saw 15 Amp 12 in. Dual Bevel Sliding Compound Miter Saw 15 Amp Corded 12 in. Dual Bevel Sliding Miter Saw with 70 m Capacity 15 Amp 12 in. Double Bevel Sliding Compound Miter Saw
Brand DEWALT DEWALT RIDGID DEWALT
Ratings (212) (272) (1350) (384)
View Product View Product View Product View Product

Specifications

Dimensions

Blade Diameter
12
Product Depth (in.)
30.75
Product Height (in.)
19.5
Product Width (in.)
22.75

Details

Amperage (amps)
15
Arbor Size
5/8
Bevel Type
Dual
Blade Diameter (in.)
12
Color Family
Yellow
Condition
New
Cord Length (ft.)
6.667
Corded Tool Type
Miter Saw
Cordless/ Corded
Corded
Dust collection type
Bag
Keyless/keyed blade change
Keyed
Maximum Cutting Thickness (in.)
9.5
Maximum Degree Miter Cuts - Left
50
Maximum Degree Miter Cuts - Right
60
Miter Saw Type
Sliding Compound
Power Tool Features
Positive Stops
Product Weight (lb.)
51lb
Returnable
90-Day
Tools Product Type
Power Tool

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
3 Year Limited Warranty1 Year Free Service Contract90 Day Money Back Guarantee

Specifications

Dimensions

Blade Diameter
12
Product Depth (in.)
30.75
Product Height (in.)
19.5
Product Width (in.)
22.75

Details

Amperage (amps)
15
Arbor Size
5/8
Bevel Type
Dual
Blade Diameter (in.)
12
Color Family
Yellow
Condition
New
Cord Length (ft.)
6.667
Corded Tool Type
Miter Saw
Cordless/ Corded
Corded
Dust collection type
Bag
Keyless/keyed blade change
Keyed
Maximum Cutting Thickness (in.)
9.5
Maximum Degree Miter Cuts - Left
50
Maximum Degree Miter Cuts - Right
60
Miter Saw Type
Sliding Compound
Power Tool Features
Positive Stops
Product Weight (lb.)
51lb
Returnable
90-Day
Tools Product Type
Power Tool

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
3 Year Limited Warranty1 Year Free Service Contract90 Day Money Back Guarantee

Questions & Answers

What is the difference between the "double" bevel sliding compound miter saw for $600 and the "dual" bevel sliding compound miter saw for $400?

Example: I have looked at the manual and can't figure out what I did wrong.
Asked by: Possum
The biggest difference between this saw and the $600 saw is the other saw has a 2" taller capacity at the fence for cutting moldings. If you compare the drive mechanism of the two saws you will see the difference of the two, which is how they achieved the taller cut. There are a few other minor differences of the two but the cut at the fence is the biggest I saw.
Answered by: RodinMN
Date published: 2017-11-06

What is the difference between a dual bevel and a double bevel sliding mitre saw?

Asked by: JGT
I believe this is mis-labeled by Home Depot as dual bevel when in-fact it is only a single bevel saw.
Answered by: dangerousD
Date published: 2017-11-28

Can this saw cut 2x10 lumber in one pass ?

Asked by: Marc
straight across (90 degrees) it can cut up to 2x14 if you set up with a back fence. 2x12 with no special set up. Can cut a bevel on the wood also. If you need a 45 degree angle on the cut, then it's only 8 inches.
Answered by: Gary
Date published: 2018-06-26

what is the maximum width board this saw can cut?

Asked by: leo77
This saw can cut 2x10 lumber at 90 deg, however it will require the work piece to be supported by scrap 2x4's for more of the blade diameter to be used. This is explained in more detail in the provided instruction manual. Bevel cuts of 45 deg can also be performed on 2x10's with this method. Miter cuts at other than 90 deg will reduce the size of lumber that can be cut in one operation.
Answered by: DV
Date published: 2018-11-13
