Internet #303507892

Model # RAD80

0885917002602

Delta Breez

Radiance Series 80 CFM Ceiling Bathroom Exhaust Fan with Heater

  • Operates quietly and backed with 3-year warranty
  • Heater included with built in thermostat to regulate temperature
  • To complete installation, a dedicated 15 Amp circuit is required
$ 94 27
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Operates quietly and backed with 3-year warranty
  • Heater included with built in thermostat to regulate temperature
  • To complete installation, a dedicated 15 Amp circuit is required
The Delta BreezRadiance RAD80 combines a quiet bath fan and heater all in 1 with built-in thermostat and brushless DC motor engineered to run continuously for a minimum 70,000 hours; airflow rating of 80 CFM (10%) and 1.5 Sones is at 0.1 static pressure. Power consumption approximately 10.5-Watt with an efficiency rating approximately 7.6 CFM/Watt. Duct diameter is no less than 4 in. Built-in thermostat to regulate temperature. Metal guard to help prevent user contact with heating wire. Heater element with 1300W and conforms to cUL safety standards. Heater module equipped with thermal cutoff fuse and thermostat.
  • Energy saving brushless DC motor technology engineered to run continuously for a minimum 70,000-hours
  • Quiet operation at 1.5 Sones
  • Energy efficiency at 7.6 CFM/Watt
  • Built-in thermostat for consistent temperature
  • Metal guard to prevent user contact with heating wire
  • 1300W heating element evaluated by cUL for safety standards
  • Heater module equipped with thermal cutoff fuse and thermostat
  • Requires a dedicated minimum 15 Amp circuit

Product Overview

  • Operates quietly and backed with 3-year warranty
  • Heater included with built in thermostat to regulate temperature
  • To complete installation, a dedicated 15 Amp circuit is required
Model #: RAD80
Internet #: 303507892

The Delta BreezRadiance RAD80 combines a quiet bath fan and heater all in 1 with built-in thermostat and brushless DC motor engineered to run continuously for a minimum 70,000 hours; airflow rating of 80 CFM (10%) and 1.5 Sones is at 0.1 static pressure. Power consumption approximately 10.5-Watt with an efficiency rating approximately 7.6 CFM/Watt. Duct diameter is no less than 4 in. Built-in thermostat to regulate temperature. Metal guard to help prevent user contact with heating wire. Heater element with 1300W and conforms to cUL safety standards. Heater module equipped with thermal cutoff fuse and thermostat.

  • Energy saving brushless DC motor technology engineered to run continuously for a minimum 70,000-hours
  • Quiet operation at 1.5 Sones
  • Energy efficiency at 7.6 CFM/Watt
  • Built-in thermostat for consistent temperature
  • Metal guard to prevent user contact with heating wire
  • 1300W heating element evaluated by cUL for safety standards
  • Heater module equipped with thermal cutoff fuse and thermostat
  • Requires a dedicated minimum 15 Amp circuit

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand Hunter Delta Breez Delta Breez NuTone
Name Halcyon Decorative 90 CFM Ceiling Bathroom Exhaust Fan with Light Radiance Series 80 CFM Ceiling Bathroom Exhaust Fan with Heater GreenBuilder Series 80 CFM Ceiling Bathroom Exhaust Fan with LED Light and Humidity Sensor, ENERGY STAR 70 CFM Ceiling Bathroom Exhaust Fan with Light and Heater
Price
$93.99
$94.27
$110.85 /box
$344.91
Ratings (88) (52) (18) (112)
Housing Length (in.) 11.88 14.37 8.25 13.25
Maximum Room Size (sq. ft.) 80 80 80 60
Housing Width (in.) 7.79 8.25 8 13.25
Features Decorative,Light Heater Humidity Sensing,Light Heater,Light,Light,Nightlight
View Product View Product View Product View Product

Specifications

Dimensions

Housing Length (in.)
14.37
Housing Width (in.)
8.25
Maximum Room Size (sq. ft.)
80
Product Height (in.)
6.68
Product Length (in.)
16.81
Product Width (in.)
10.68

Details

Air Volume (CFM)
80
Amperage (amps)
12
Area Heated (Sq. Ft.)
80
Color/Finish
White
Duct Compatible Sizes
4 in
Fan Sound Level (Sones)
1.5
Features
Heater
Grill Shape
Square
Housing Material
Metal
Included
No Additional Items Included
Installation Type
Ceiling
Mount Type
Flush Mount
Product Weight (lb.)
9.81lb
Returnable
90-Day
Room Size
Medium Room Fan
Voltage (volts)
120
Wattage (watts)
10.5

Warranty / Certifications

Certifications and Listings
cUL Listed
Manufacturer Warranty
Three year limited

Specifications

Dimensions

Housing Length (in.)
14.37
Housing Width (in.)
8.25
Maximum Room Size (sq. ft.)
80
Product Height (in.)
6.68
Product Length (in.)
16.81
Product Width (in.)
10.68

Details

Air Volume (CFM)
80
Amperage (amps)
12
Area Heated (Sq. Ft.)
80
Color/Finish
White
Duct Compatible Sizes
4 in
Fan Sound Level (Sones)
1.5
Features
Heater
Grill Shape
Square
Housing Material
Metal
Included
No Additional Items Included
Installation Type
Ceiling
Mount Type
Flush Mount
Product Weight (lb.)
9.81lb
Returnable
90-Day
Room Size
Medium Room Fan
Voltage (volts)
120
Wattage (watts)
10.5

Warranty / Certifications

Certifications and Listings
cUL Listed
Manufacturer Warranty
Three year limited

Questions & Answers

How many switches are required. It is 2, 1 for the heater and 1 for the exhaust?

How many switches are required. It is 2, 1 for the heater and 1 for the exhaust?
Asked by: TK
Yes, they should be wired separately.
Answered by: KennyG
Date published: 2019-03-19

Can this unit be safely installed in the ceiling of a shower enclosure?

Can this unit be safely installed in the ceiling of a shower enclosure?
Asked by: Jan
Never put an exhaust fan or heater directly inside a shower enclosure. The unit should be installed outside of the shower enclosure,. If possible at least 4 feet away.
Answered by: Zedo
Date published: 2018-08-20

Can this be installed without access to an attic? I would have to install from the ceiling side.

Can this be installed without access to an attic? I would have to install from the ceiling side.
Asked by: HomeDepotCustomer
Yes, as long as you already have exhaust system connected.
Answered by: Raj
Date published: 2019-03-26

What other equipment is needed for a complete installation of this product?

What other equipment is needed for a complete installation of this product?
Asked by: Coach
Outlet box, electrical wire, on/off switch. Timer switch if you wish.
Answered by: Zedo
Date published: 2018-08-21
  • y_2019, m_6, d_18, h_19CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_21
  • loc_, sid_303507892, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 208ms
  • QUESTIONS, PRODUCT

Customer Reviews

Radiance Series 80 CFM Ceiling Bathroom Exhaust Fan with Heater is rated 4.4 out of 5 by 52.
Rated 5 out of 5 by from We find this heater/exhaust fan to be perfect for our needs. It replaced a cheap builders exhaust... We find this heater/exhaust fan to be perfect for our needs. It replaced a cheap builders exhaust fan; an electrician installed it last week and added an additional circuit and wall switch. We used a double paddle switch to eliminate need for 5th rocker on wall. He enlarged the 8x8 opening to accommodate the larger size with no trouble. The heater heats up our 100 square foot bathroom very nicely as long as we turn it on about 5 minutes before beginning our showers. it is EXTREMELY quiet, much better than heaters we've had in previous homes and than the builders exhaust fan. Because it's installed in the ceiling it takes up no wall space and has clean lines. We are so pleased with this heater and will really enjoy it next winter when it is cold again. It was shipped free to our home and delivered quickly. The price was certainly "right" and it is a good value for what we paid. We recommend it.
Date published: 2019-03-26
Rated 4 out of 5 by from Seems to work OK. Construction is solid. Quiet, but exhaust... Seems to work OK. Construction is solid. Quiet, but exhaust fan start up very slowly. I thought I had it wired incorrectly at first because it takes a few seconds to spin-up. It seems to exhaust air but I am not sure if it is 80cfm as specified. I do not like that the heater blows very hard and the air is not directed straight down but to the side at a 45 degree angle. I wish I would have known this before I mounted it. My wall and medicine cabinet will be very warm. The heat seems very adequate for a small bathroom. Mounting this unit will definitely require drywall work. IMO it is designed more for new construction than a remodel. Also, there is no access to the wiring from the front like other units. If the connection goes bad then this unit will have to be accessed from the attic. I have no attic access, so any problems will require removing drywall. My old heater mounted from the inside front using screws into the stud/rafter allowing access from the bathroom. This unit has no mounting screws accessible by removing the vent cover. It cannot be removed through the hole from the front. Other than the angle of the heated air and the difficult access it performs as expected and am happy with it.
Date published: 2019-05-21
Rated 5 out of 5 by from Straight forward install. Unit is quiet and the heater warms... Straight forward install. Unit is quiet and the heater warms the bathroom quickly.
Date published: 2019-04-02
Rated 5 out of 5 by from Very quiet great heat and easy to install if you know what you’re doing Very quiet great heat and easy to install if you know what you’re doing
Date published: 2019-05-14
Rated 4 out of 5 by from Very silent and efficient. Impossible to install without attic access.... Very silent and efficient. Impossible to install without attic access.
Date published: 2019-05-21
Rated 5 out of 5 by from Quiet, great price for heater and fan combo. Highly... Quiet, great price for heater and fan combo. Highly recommend.
Date published: 2019-06-11
Rated 5 out of 5 by from Quiet fans, heater works well. Simple install. Quiet fans, heater works well. Simple install.
Date published: 2019-03-26
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-04-18
