Textured Black Aluminum Hand Rail Wall Bracket

$3077
Apply Now
Pay $5.77 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Helps mount ADA round handrails to walls or posts at any angle
  • Made of aluminum alloy for enhanced strength
  • Includes fasteners and mounting brackets for swift installation
caret

Product Details

The EZ ADA 1.9 in. Round Hand Rail Wall Bracket is a heavy duty aluminum bracket for mounting EZ ADA Round handrails to any type of wall or post at any angle. Additionally, the three fastener mounting system secures the bracket for weight loads exceeding 450 lbs. Predrilled holes for quick installation.
  • Mounting bracket for attaching handrail to wall or post
  • Meets 2010 ADA standards for accessible design
  • 100% Aluminum alloy for superior strength
  • Compatible with all EZ Handrails and components
  • Includes Fasteners For Installing To Wood 1 - 9/16 Bolt Cap 1 - 5/16 x 2 ½" Lag Screw 2 - 1" SMS Stainless
  • Outer edge of the handrail is 3-1/2 in. away from wall when installed
  • Made in USA, custom powder coat colors available through your local Home Depot Pro Desk
  • Return Policy

Additional Resources

From the Manufacturer

caret

Specifications

caret

Questions & Answers

4Questions
caret
Q:My run is 14'. Can I place post 1 @ 1' mark P2 @ the 7' mark and P3 @ the 13' mark??? Or will I n...
by|Jun 13, 2019
3 Answers
Answer This Question

A:  3 should be fine....

by|Jun 14, 2019

    A:  P1 & P3 1'-0" at each end, P2 at center. Perfect.

    by|May 30, 2020

    A:  SHOULD WORK FINE - GREAT HAND RAIL BRACKETS - I USE THEM ALL THE TIME.

    by|Jun 14, 2019
    caret
    Q:What is the recommended maximum spacing between brackets on long hand rail?
    by|May 4, 2018
    5 Answers
    Answer This Question

    A:  The installation instructions can be found at: www.hdezhandrail.com/documents/ezadahandrail/instructions.pdf Per the instructions wall brackets should be installed incrementally every 4’-6’ attached to a solid mounting surface (stud).

    by|May 4, 2018

      A:  Bracket spacing should be between four and six feet. The ideal spacing for post supported brackets and railing should be likewise, with each bracket centered on the post. With wall mounted brackets, mounting spacing should be determined by the railing length divided by 5, for maximum spacing, with an end brackets no more than 10” from the rail ends.

      by|May 5, 2018

        A:  6'-0" maximum spacing is normal. Longer spacing may cause pipe sagging or an insecure feeling of pipe wobble.

        by|May 30, 2020

        A:  I used 3 brackets on a 10' handrail I created from 2 rail sections and an internal splice. Bracket spacing is approx 4'. It is plenty sturdy, and if you want sturdy, I wouldn't space much more than that.

        by|May 5, 2018

          A:  Hi TH. The recommended maximum spacing between brackets on a long handrail is 6 ft. Thank you for getting this important Q&A out there. Dan H. (EZ Handrail Dev. Team)

          by|May 4, 2018
            caret
            Q:Could this be mounted to a 4x4 post ?
            by|Apr 8, 2017
            4 Answers
            Answer This Question

            A:  Yes, if outside use treated wood.

            by|May 5, 2018

              A:  Yes, this could be affixed to a 4 x 4 post.

              by|Apr 10, 2017

                A:  Hi. Absolutely, this bracket is 2" in width and can installed at virtually any slope on a 4" x 4" post without the bottom hanging off. A stainless wood lag fastener is included with the kit. Thank you for your consideration, Dan H. (EZ Handrail Dev. Team)

                by|Apr 10, 2017

                  A:  Yes, absolutely.

                  by|May 30, 2020
                  caret
                  Q:Distance railing is from wall?
                  by|Dec 23, 2015
                  4 Answers
                  Answer This Question

                  A:  2-1/4" from wall to handrail pipe centerline, 1-1/2" clear from wall to handrail pipe.

                  by|May 30, 2020

                  A:  approx 1.5 inches, which is what it should be by code.

                  by|Apr 3, 2018

                  A:  The bracket will determine the projection from the wall. Accessibility code requires no more than 3” to the center of the rail from the wall. Do not use spacers, brackets come with hardware, but require lead anchor for masonry or concrete walls.

                  by|May 5, 2018

                    A:  The space between the edge of the handrail and the wall when installed is 1-1/2". Thank you for your consideration, Dan H. (EZ Handrail Dev. Team)

                    by|Dec 24, 2015
                      1 found this answer helpful
                      Showing 1-4 of 4
                      caret

                      Customer Reviews

                      4.9 out of 5
                      (17)
                      • 4.9
                        out of 17 reviews
                      • 100%recommend this product
                      Filter by:
                      Showing 1-10 of 17 reviews
                      Excellent product, and comes with drill bit, stainless steel screws to attach pipe handrail, and ...
                      Excellent product, and comes with drill bit, stainless steel screws to attach pipe handrail, and 1/4" SS bolt to attach unit to side of building wall. A black plastic cap is provided to securely fit over bolt head. It all looks very nice and professional.
                      by
                      • Verified Purchase
                      • Recommended
                      1 found this review helpful
                      Rating provided by a verified purchaser...
                      Rating provided by a verified purchaser
                      by
                      • Verified Purchase
                      by
                      • Verified Purchase
                      Very sturdy and good looking just like I want to be!! Haha!
                      Very sturdy and good looking just like I want to be!! Haha!
                      by
                      • Verified Purchase
                      • Recommended
                      It is very strong. zzzz xxxx vvvv ssss...
                      It is very strong. zzzz xxxx vvvv ssss
                      by
                      • Verified Purchase
                      Looks amazing & simple to install...
                      Looks amazing & simple to install
                      by
                      • Verified Purchase
                      Excellent product. Very sturdy....
                      Excellent product. Very sturdy.
                      by
                      • Verified Purchase
                      I installed 5 of these onto EZHandrail metal posts, 1 onto a rock wall, and 2 onto wood trim. Th...
                      I installed 5 of these onto EZHandrail metal posts, 1 onto a rock wall, and 2 onto wood trim. They look great and match the handrail perfectly. The only downside is that the two screw holes are very close to the flat metal edge, so it's difficult to drill holes in the handrail and install the screws without scratching the adjacent metal. Fortunately, glossy, black enamel paint covers the scratches well, and it all looks great in the end. Be careful not to over-tighten the screws, I did break a couple off and had to drill new holes for bigger screws.
                      by
                      • Verified Purchase
                      • Recommended
                      Rating provided by a verified purchaser...
                      Rating provided by a verified purchaser
                      by
                      • Verified Purchase
                      Strong brackets and all hardware came with them.High price!...
                      Strong brackets and all hardware came with them.High price!
