Model #ECTRU30179R

Crosstown Undermount Stainless Steel 32 in. Single Bowl Kitchen Sink

  • 31.5in. x 18.5in. x 9in. Minimum cabinet size 36in.
  • 18-Gauge stainless steel
  • Deep high-capacity bowl for easy use
  • See More Details

Product Overview

Elkay Crosstown is the ultimate mix of beauty, function and modern design. Straight sidewalls, a flat bottom and tight corners provide more space inside the sink for stacking and washing dishes. The striking geometric aesthetic has universal appeal and makes an impact in any space.
  • UNDERMOUNT INSTALLATION: Sink is installed beneath the countertop creating a seamless appearance between the sink and the countertop.
  • SINGLE BOWL: Bowl gives you uninterrupted space for washing and stacking dishes or other household tasks.
  • 18-GAUGE STAINLESS STEEL: Highest quality 18-gauge thickness and Type 304 stainless steel for lasting durability, performance and lustrous beauty.
  • QUIET: Sound-deadening pad(s) minimizes sound and vibration for a quieter time at the sink.
  • TIGHT CORNERS: Fresh, geometric design offers straight sidewalls and a flat bottom for a modern look and more usable space; easy to clean.
  • OFFSET DRAIN: Drain placement provides more usable space on the bottom of the sink and in the cabinet below.
  • EXTRA DEEP BOWLS: High-capacity bowls offer more room inside for stacking dishes, filling stockpots, and handling large baking sheets and roasters.
  • CROSS BREAKS: Creased accent lines in the sink bottom deliver superior drainage and give the sink a professional appearance.
  • Accessories Available: Elkay accessories are designed to fit perfectly and coordinate with your Elkay sink. Accessories available include: Grid - GFOBG3017RSS.
  • CABINET SIZE: Minimum cabinet size for this sink is 36".
  • Garbage Disposal Compatible: Most garbage disposal brands, including InSinkErator disposers, can be installed. Garbage Disposal sold separately.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Actual Left to Right Length (In.)
31.5
Bowl Below Counter Depth (in.)
9
Bowl Front to Back Width (in.)
17
Bowl Left to Right Length (in.)
30
Bowl Top to Bottom Depth (in.)
9
Cut-Out Below Counter Depth (in.)
9
Cut-Out Depth (in.)
16.75
Cut-Out Width (in.)
29.75
Kitchen Sink Front to Back Width (In.)
18.5

Details

Bundle Type
Sink Only
Color Family
Stainless Steel
Color/Finish
Polished Satin Finish
Features
Insulated,Sound Dampening
Included
Sink Only
Kitchen Product Type
Kitchen Sink
Minimum Cabinet Size (in.)
36
Mount Type
Undermount
Number of Bowls
Single Bowl
Number of Faucet Holes
0
Product Weight (lb.)
37
Returnable
90-Day
Sink Finish Type
Satin
Sink Material
Stainless Steel
Sink Shape
Rectangular

Warranty / Certifications

Certifications and Listings
CSA Certified,IAPMO Certified
Manufacturer Warranty
Lifetime limited

Questions & Answers

7Questions10Answers

Can this fit in a 33" cabinet if I'm willing to do a little carpentry?

Asked by Steve March 21, 2018
1
Answer

Hi Steve, The minimum cabinet size refers to the width needed to support the size and weight of the sink. We recommend you follow the recommended cabinet size. Thank you!

What are all of the dimensions of this sink.

Asked by VS June 1, 2017
1
Answer

Hi VS- Thank you for you interest in Elkay's Crosstown stainless sinks! The dimensions of this sink are Overall: 31-1/2 in. L x 18-1/2 in. W x 9 in. D Inside bowl: 30 in. x 17 in x 9 in. For more information please refer to our spec sheet here: http://www.homedepot.com/catalog/pdfImages/8a/8a9368b8-a3aa-4311-b6e7-1fcecc042832.pdf.

Is this a zero radius or small radius sink?

Asked by ScotofMKE March 25, 2016
0
Answers

Are mounting clips included? If so where find them?

Asked by smitty March 23, 2016
1
Answer

Yes, supplied in box

If I'm putting in a garbage disposal do I need the drain kit? Also is there stopper that will fit the garbage disposal hole?

Asked by smitty March 23, 2016
3
Answers

Firstly, I'm not a professional plumber, but I did install my own garbage disposal, and so no, you don't need the drain kit, as the disposal attaches directly to the sink's hole itself. And the stopper for the resultant garbage/drain hole should come with the actual disposal unit itself.

can you put hole on left

Asked by skiptill September 15, 2015
2
Answers

Yes ours is left forward.

is there a bottom grid that I can order to go with this?

Asked by ssss March 8, 2015
2
Answers

I think so but we didn't order it.

Customer Reviews

  • 4.4
    out of 8 reviews
  • 100% recommend this product
Filter by:
Showing 1-8 of 8 reviews
Wonderful Sink with Great Finish
We replaced our current double bowl sink with this single bowl. We had a plumber come and do all the hard work. He replaced the plastic plumbing from the old sinks and we also cleaned out the garbage disposal since everything was apart. The sink went in well. We had to caulk around the edge to prevent any leaking. The entire job took about 4 hours to complete. We love the extra room a single bowl offers especially when hand washing pots or larger dishes. We have been using the sink for about a month now and the finish is still in tact. There are a few minor scratches from silverware but overall it is holding up nicely to our daily use.
by BPuttkammer
Great one basin sink option w/ right hand drain
I love my new Elkay sink. It is so large and functional. If you are vertically challenge this sink may be a little deep for you given that's it's also an under mount. I'm 5'10 and it's perfect. It does scratch easily but it's a sacrifice that I'm willing to give for a large one basin with a right hand drain. I've had no problem with water draining from the sink. There is a little water left but it dries within minutes.
by rapidsblue
9 people found this helpful
Love my new sink nice and big but I wish...
Love my new sink nice and big but I wish I would have purchased on the grate to go with it.
by Andi
Response from Elkay Product ExpertJan 24, 2018
Hi Andi, Thank you so much for your review. We are so happy to hear you lobe your new Crosstown Undermount Sink. If you would like to purchase the recommended bottom grid the part number is GFOBG3017RSS. Enjoy!
I really liked the look of this sink but ended...
I really liked the look of this sink but ended up returning it because we went with an apron sink.
by Kathleen
Response from Elkay Product ExpertSep 28, 2017
hi Kathleen, Our Crosstown sinks, whether Farmhouse style or undermount, have modern style and practical functionality. We hope you found the perfect sink for your kitchen!
Beautiful sink! Easy to install…per contractor! LOVE love love how...
Beautiful sink! Easy to install…per contractor! LOVE love love how deep it is and the satin finish!!
by Robbie
Response from Elkay Product ExpertSep 28, 2017
Hi Robbie, Thanks for your rave review! This is a big, beautiful sink that makes kitchen clean-up easy. Enjoy!
4 Star Review
Rating provided by a verified purchaser
by Anonymous
The drain on the right side gives me more usable...
The drain on the right side gives me more usable room in the cabinet.
by HomeDepotCustomer
Nice sink, weak mounting hardware
This sink was fine but after one week of use the sink dropped down below the counter top by about 1/2 inch, pulling away the sealer. The installer returned and found that the mounting brackets supplied had bent. He added a stronger bracket on one side and then tripled up the supplied brackets. For the price and quality of this sink the manufacturer should do a better job. If you buy one get your own stronger mounting hardware .
by Remodeler
7 people found this helpful
