Model # GE1LU032SS

Store SKU # 1000051310

RV Panel with 30 Amp RV Receptacle and 20 Amp GFCI Receptacle

$223.15
Apply Now
Pay $198.15 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • 100A Unmetered Power Panel for recreational vehicle park power
  • 2-Space 2-Circuit includes circuit breakers
  • Stay open position on door
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

The Unmetered Surface Mount is factory-assembled and factory-tested. It comes to the construction job site ready to use with no need to assemble individual parts, saving installation time. The single, heavy-gauge NEMA 3R rainproof enclosure protects against weather, vandalism and nuisance tripping. It is lockable and is engineered for maximum protection of receptacles, cords, plugs, breakers. The unit complies with National Electrical Code and OSHA requirements.

Highlights

  • All-in-1 construction for factory assured terminations
  • Rolled edge door for cord protection
  • Heavy galvanized zinc coated steel, with highest quality electro-deposition finish - resists corrosion and fading
  • Welded flange NEMA 3R construction for lasting service in outdoor installations
  • UL listed for RV use, not suitable for service entrance
  • Padlock provision can prevent unauthorized entry
  • Dead front construction prevents accidental contact with live parts
  • All components are factory wired and assembled, reducing installation time
  • Power outlet door has stay-open position for user convenience
  • All terminals accept copper or aluminum wire for added installation flexibility
  • Broad range of concentric knock-outs to accommodate wiring needs
  • All units with 12-2 Cu/Al equipment ground lug
  • Closure caps included, hubs ordered separately
  • Click here for more information on Electronic Recycling Programs
  • Return Policy

Product Information

Internet # 203393633

Model # GE1LU032SS

Store SKU # 1000051310

Additional Resources

Shop All GE

Specifications

Dimensions

Load center depth (in.)

5.2

Load center height (in.)

17

Load center width (in.)

9.4

Details

Electrical Product Type

Load Center

Load Center Type

Temporary Power

Maximum Amperage (A)

100

Number of Circuits

2

Number of Spaces

2

Phase Type

1 Phase

Product Weight (lb.)

14 lb

Returnable

90-Day

Voltage (V)

240

Warranty / Certifications

Certifications and Listings

UL Listed

Manufacturer Warranty

One year warranty from first use

Questions & Answers

25Questions
caret
Q:Can I run romex wiring out to a yard light off the 20 amp gfci duplex circuit?
by|Nov 15, 2023
0 Answer
Answer This Question
caret
Q:What size cable 10-3 or 10-2 from meter box to this panel box.
by|Jun 24, 2023
0 Answer
Answer This Question
caret
Q:Can I run directly from meter to this box. The power company supplies a main shutoff with three outputs. Or Do I need to run from a breaker box.
by|May 21, 2022
1 Answer
Answer This Question

A:  I used mine at my deer camp for RV hookup. Ran it directly from meter box.

by|May 26, 2022
    caret
    Q:Can I add a third breaker and run only 120 volts to the box? I want to power outlets to an outdoor kitchen but do not want to run 240 to this location.
    by|Jan 14, 2022
    1 Answer
    Answer This Question

    A:  Yes, you can solely use this enclosure for 120v & a 3rd breaker can be added. You will need to provide 240v to this panel if you plan on using all of the breaker spots for 120v. HD does offer smaller 3R enclosures that will accomplish what you’re wanting to do for a lot less money.

    by|Jan 15, 2022
      Showing 1-4 of 25

      Customer Reviews

      4.7 out of 5

      • 4.7 out of 44 reviews
      • 100% recommend this product
      Filter by:
      Showing 1-10 of 44 reviews
      Was easy to install and connect. I am not an electrician and I did it myself to replace an old br...
      Was easy to install and connect. I am not an electrician and I did it myself to replace an old breaker box and outlets damaged due to flooding, so the power to the meter was turned off. Passed the electrical inspection on the first try. Have only had it for a month so I don't know how it will hold up, but seems to be pretty solid.
      by
      • Verified Purchase
      • Recommended
      Perfect.
      Perfect.
      by
      • Verified Purchase
      • Recommended
      I chose this particular RV outlet box because of the additional 20a GFCI outlets. This is an out...
      I chose this particular RV outlet box because of the additional 20a GFCI outlets. This is an outdoor installation, and GFCI is important in such cases. Many comparable boxes did not have GFCI protection. Having extra outlets is very convenient. As long as you are paying for an electrician, the difference in cost for this convenience is minimal. I also chose this box for the external breakers. For safety, you can switch off the breakers before connecting the travel trailer. That way, you are not handling live wires. In addition, in the future, the box can easily be upgraded to a 50a connection, with some rewiring, the replacement of the NEMA TT-30R with a NEMA 14-50R, and the replacement of the breaker.
      by
      • Verified Purchase
      • Recommended
      1 found this review helpful
      by
      • Verified Purchase
      This was a much needed upgrade from my old 30...
      This was a much needed upgrade from my old 30 AMP RV power supply panel that did not include onsite breakers or a 110 outlet. This panel works as advertised and was worth the investment.
      by
      • Verified Purchase
      by
      • Verified Purchase
      Easy to wire in. An electrician wanted to charge me...
      Easy to wire in. An electrician wanted to charge me $1800 to tie it into my electric meter.
