Internet #203393687

Model #GE1LU502SS

Store SKU #1000051320

RV Panel with 50 Amp RV Receptacle and 20 Amp GFCI Receptacle

  • 70A Unmetered Power Panel for recreational vehicle park power
  • 2-Space 2-Circuit includes circuit breakers
  • Stay open position on door
  • See More Details
$9593

Frequently Bought Together

+
+
Price:
$9593

Product Overview

The Unmetered Surface Mount is factory-assembled and factory-tested. It comes to the construction job site ready to use with no need to assemble individual parts, saving installation time. The single, heavy-gauge NEMA 3R rainproof enclosure protects against weather, vandalism and nuisance tripping. It is lockable and is engineered for maximum protection of receptacles, cords, plugs, breakers. The unit complies with National Electrical Code and OSHA requirements.
  • All-in-1 construction for factory assured terminations
  • Rolled edge door for cord protection
  • Heavy galvanized zinc coated steel, with highest quality electro-deposition finish - resists corrosion and fading
  • Welded flange NEMA 3R construction for lasting service in outdoor installations
  • UL listed
  • Padlock provision can prevent unauthorized entry
  • Dead front construction prevents accidental contact with live parts
  • All components are factory wired and assembled, reducing installation time
  • Power outlet door has stay-open position for user convenience
  • All terminals accept copper or aluminum wire for added installation flexibility
  • Broad range of concentric knock-outs to accomodate wiring needs
  • All units with 12-2 Cu/Al equipment ground lug
  • Closure caps included, hubs ordered separately
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar RV Electrical Panels

current product
RV Panel with 50 Amp RV Receptacle and 20 Amp GFCI Receptacle
RV Pad Mount Pedestal with 50 Amp and 30 Amp RV Receptacles and 20 Amp GFCI ReceptacleMetered RV Panel with 50 Amp and 30 Amp RV Receptacles and 20 Amp GFCI ReceptacleRV Earth Burial Pedestal with 50 Amp and 30 Amp RV Receptacles and a 20 Amp GFCI Receptacle
BrandGEGEGEGE
NameRV Panel with 50 Amp RV Receptacle and 20 Amp GFCI ReceptacleRV Pad Mount Pedestal with 50 Amp and 30 Amp RV Receptacles and 20 Amp GFCI ReceptacleMetered RV Panel with 50 Amp and 30 Amp RV Receptacles and 20 Amp GFCI ReceptacleRV Earth Burial Pedestal with 50 Amp and 30 Amp RV Receptacles and a 20 Amp GFCI Receptacle
Price
$9593
$18973
$19933
$24708
Ratings
(220)
(29)
(41)
(27)
Maximum Amperage (amps)70100100100
Number of Circuits2555
Voltage (volts)240240240240
Electrical Product TypeLoad CenterDistribution Load Center / Breaker AccessoryLoad CenterLoad Center
Number of Spaces2555
View ProductView ProductView ProductView Product

Specifications

Dimensions

Load center depth (in.)
3.8
Load center height (in.)
14
Load center width (in.)
7

Details

Electrical Product Type
Load Center
Load Center Type
Temporary Power
Maximum Amperage (amps)
70
Number of Circuits
2
Number of Spaces
2
Phase Type
1 Phase
Product Weight (lb.)
10
Returnable
180-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

33Questions62Answers

Can i wire this directly from a power source?

Asked by Don August 20, 2020
1
Answer

This unit contains a main breaker and is to be wired to a power source.

is it approved by the camping regulations?

Asked by adams July 31, 2020
3
Answers

Not sure what you're asking. This panel is very similar if not identical to what you might find in a well-maintained RV park. If installing at a residence, you will need a sub-panel and a 50-amp breaker if it is installed remotely. Make sure it is installed per NEC and any local code requirements.

Looking at the product sheet, it says to refer to table P for wire size range information. The li...

Asked by metrojethro October 9, 2019
5
Answers

As described. It’s has breakers and receptacles. I did not get electrocuted while installing it, which was a plus.

What gauge wiring did everyone run under ground for this 50 amp system.

Asked by TC September 11, 2019
9
Answers

I didn’t run underground but used it as a sub panel. I installed 6g as it met the 75 amp load rating.

Can you loop feed this panel

Asked by Mike July 23, 2019
5
Answers

Yes you can loop multiple RV disconnects together you will have to look at your national electrical code determine your wire size and your demand factor for how many you can put together in one row if I remember right you can put 5-30amp pedestals on a 80amp breake And 3-50amp pedestals on a 90p breaker with wire size bass on breaker but remember to look up the calculations yourself these are just suggestions Thank you from R&R electric

Anyone know the panel mounting hole dimensions?

Asked by adbeng May 6, 2019
5
Answers

Not sure what you're asking here, as this is a surface mount box. The only "hole" would be the knockouts for conduit or wire, depending on location. In most situations (especially if used outside) you would need to run at least 3/4" or 1" conduit, depending on how you decide to wire it. Be sure to check the NEC and any local codes before installing.

CAN I CHANGE THE 50AMP RV BREAKER TO A GFCI Safety Circuit BREAKER

Asked by FRANK April 21, 2019
9
Answers

As far as I’m aware you can’t.

Do I have to install a grounding rod with this box?

Asked by Daniel April 7, 2019
10
Answers

No because it should already be grounded at the source. You do not want current to flow in a ground loop.

I am not 100% clear, does it come with the breakers ?

Asked by joec March 29, 2019
10
Answers

Yes it dose

Is this box aluminum feeder wire compatible?

Asked by DJ September 26, 2018
5
Answers

Al/CU identifies it is compatible with both Aluminum and Copper conductors.

RV Panel with 50 Amp RV Receptacle and 20 Amp GFCI Receptacle - page 2

Customer Reviews

  • 220 Customer Reviews
  • 4.9 out of 5 stars overall
97% of customers recommended.
Overall Ratings
5star-icon(198)
4star-icon(15)
3star-icon(2)
2star-icon(2)
1star-icon(3)
Sort By:
After getting advice from an electrician that I needed a 8-3 with ground wire I found it was easy...
After getting advice from an electrician that I needed a 8-3 with ground wire I found it was easy to hookup and the box is made very well.
Was this helpful?
1
0
Great product, have one in the garage and one outside. The one outside provides extra outlet for ...
Great product, have one in the garage and one outside. The one outside provides extra outlet for my wife's Christmas lights.
Was this helpful?
0
0
This was a snap to install and works like a champ. Great quality build and looks great on the out...
This was a snap to install and works like a champ. Great quality build and looks great on the outside of the shop.
Was this helpful?
0
0
Perfect. Just like the rv parks. Now I can connect the rv at home and invite guests to stay in ...
Perfect. Just like the rv parks. Now I can connect the rv at home and invite guests to stay in it during cold/hot weather.
Was this helpful?
0
0
This worked perfect to power my motorhome. The 20A outlet is a bonus. Now I can power Christmas l...
This worked perfect to power my motorhome. The 20A outlet is a bonus. Now I can power Christmas lights, power tools, etc. Without long extension cords.
Was this helpful?
0
0
This product was exactly what I was looking for to install an EV charger outside my house. The o...
This product was exactly what I was looking for to install an EV charger outside my house. The only reason why I didn't give it a 5 star rating is because I found the description on the website to be a little incomplete. I wasn't sure if the 50amp and 20amp breakers where included or available separately. I was confusing because it mentioned a 20 amp GCFI in the same statement. Maybe I missed that somewhere. For the record, everything is included (50 Amp dual pole, 20 amp single pole & 20 amp GCFI).
Was this helpful?
4
0
Good value for the price. Simple to install and appears to be very sturdy.
Good value for the price. Simple to install and appears to be very sturdy.
Was this helpful?
0
0
This box is really well built. Easy to follow instructions made installation a piece of cake. Any...
This box is really well built. Easy to follow instructions made installation a piece of cake. Anyone with some basic knowledge of wiring and circuits can install this. I can now safely, confidently plug in our 50 amp RV in the driveway. The 20 amp gfci recepticle is a bonus.
Was this helpful?
0
0
Doraville, GA, USA
Excellent product at a great price!
Quality :
5
Value :
5
I purchased two of these boxes to be installed at my office and my weekend house to use for charging my electric vehicle. They were well made and easy to install. Would highly recommend to anyone needing a NEMA 14-50 outlet.
Was this helpful?
4
0
Arizona, USA
Full feature box
Quality :
5
Value :
5
Keep in mind, I am a Electrician. ALL OTHERS DO THIS AT YOUR OWN RISK! This 70 amp (rated) box is very well constructed. Nema 3R rated for exterior use. My RV is 30 amp 120 volt. So I swapped out the 50 amp 240 volt receptacle for a 30 amp 120 volt RV receptacle. I then ran a 50 amp supply line to the main lugs with proper grounding. With the history of some newer RV's drawing more current on the 30 amp 120 volt sites and burning out the sites receptacle. I can just plug into the sites 50 amp receptacle with this setup and I'm good to go. EDIT: I just moved to Yuma, AZ and the site I am in doesn't have a separate 120 volt gfci to run my aux A/C. But it DOES have the 50 amp receptacle. Yeah, I'm golden because I am able to use the new GE box, plug it into the the sites 50 amp. Then I plug my RV into the new box and use the auxiliary 20 amp 120 volt gfci this new box has to run my additional A/C unit. No Sweating for me!
Was this helpful?
9
0
