$1579
- 1/16 in. and mm Increments
- 90° Angle squares lock in place at 90°
- Adjustable interlocking squares adjust for outlet creation
- View More Details
Product Details
Sliding Angle Rulers
A pair of sliding angle rulers easily lock into place with the turn of a knob, making it easy to get a precise measurement every time.
Yellow Vials for a Clear Reading
Vials on the sides make it easy to make your outlet both level and plumb.
Makes it Easy to Precisely Position Outlets
This tool measures your outlets and makes it easy to transfer those measurements to the while in a straight fashion.
Use this 1/16 in. Electrical Outlet Marker for your next outlet installation. For accurate measuring, it features a pair of sliding angle rulers that lock into place easily by turning the knob. Two built-in vials allow easy viewing and give you the option of level and plumb readings.
- Easily adjustable
- Interlocking squares
- Vial accuracy: 1 mm
- Graduations 1/16 in. and mm
- 2 vials for easy level and plumb alignment
- 90-degree angle capacity
- Return Policy
- California residents
Specifications
Questions & Answers
Jul 12, 2017
GOOD TOOL FOR MARKING CUTOUTS BACKGROUND: I make cabinets and do other carpentry and electrical w...
GOOD TOOL FOR MARKING CUTOUTS
BACKGROUND:
I make cabinets and do other carpentry and electrical work in my shop and home. I’m always looking for something to use for layout for outlets and cutouts. The Outlet Marker looked like a neat tool to test.
FIT AND FINISH:
The marker is plastic but sturdy. It is a marking guide, NOT a cutting guide. The markings are in mm and inches so you can use either system if you need to mark a specific size without using it to match an existing fixture. The markings are cast in relief in the body so they are not easy to read.
USE:
You can mark cut lines two basic ways; adjust the guide to a measurement using the cast-in rulers, or adjust the guide around the piece to be installed. I took a single-gang box and adjusted the marker around it. Once the marker is set and the adjustment knobs are tight you place the guide where you want the opening and trace along the inside. You can use the built-in spirit levels to make the opening level and plumb if desired. After the marks are made you cut the opening. (NOTE: Because you trace inside the guide you must cut on the trace lines, not inside them, for the proper size cutout.) Once you have cut the marked section out your installation piece should slide in nice and snug.
SUMMARY:
A nice little jig for marking square or rectangular cut out holes.
by
Mar 12, 2019
Dont waste your money It is broken in first time...
Dont waste your money It is broken in first time use
by
Aug 9, 2017
Great for marking outlet holes in drywall or paneling. The only downfall I see is that it is made...
Great for marking outlet holes in drywall or paneling. The only downfall I see is that it is made of plastic so I don't know how durable it would be especially if it's placed in a tool box or bag. Or if it was to get dropped. It can be adjusted for multiple outlets in tandem if needed. It can also be used for washing machine water hook ups and drain boxes.
by
