Wiremold 500 Series Metal Surface Raceway 90° Inside Elbow, Ivory

$5.43
  • Add fixtures and outlets without disturbing drywall
  • Extend circuits indoors with ease (drilling required)
  • Durable metal construction
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

The Legrand Wiremold 500 series raceway is ideal for surface mounting small amounts of electrical wiring or communication cables. Surface metal raceway allows you to add fixtures and outlets without disturbing the drywall, plaster or insulation in your home. It is also ideal for adding wire when you can't go into the wall, such as on concrete foundations or brick walls. Combine with other 500 series connectors, fittings, and channel to ensure you have the right customization for every project.

Highlights

  • For making a 90 degree turn around an inside corner from wall-to-wall or wall-to-ceiling
  • Single channel raceway connector conceals power, phone, or data line wiring
  • Neutral ivory finish features an exclusive ScuffCoat finish
  • Paintable and stainable with oil based products to blend with your decor
  • Low profile appearance
  • Pre-assembled once piece base speeds the installation process
  • Durable metal construction
  • 500 series raceway capacity measures 17/32-inches by 3/4-inches
  • Shop the entire Metal Raceway Collection here
  • Note: product may vary by store
  • Return Policy

Product Information

Internet # 100112000

Model # B-7

Store SKU # 402621

Specifications

Dimensions: H 0.75 in, W 2.75 in, D 0.531 in

Dimensions

Product Depth (in.)

0.531 in

Product Height (in.)

0.75 in

Product Width (in.)

2.75 in

Details

Color Family

Off White

Color/Finish

Ivory

Electrical Product Type

Metallic Raceway Box/Fitting/Kit

Features

Paintable/Stainable

Location

On-wall

Material

Steel

Product Weight (oz.)

0.175 oz

Raceway Cord Covers System

None

Returnable

90-Day

Warranty / Certifications

Manufacturer Warranty

Limited warranty for 1 year

Questions & Answers

7Questions
caret
Q:Are bushings required/included with these parts?
by|Jun 2, 2023
2 Answers
Answer This Question

A:  no

by|Jun 3, 2023

    A:  Hello, Bushings are not included and are available separately using part number 502. The 500/700 series raceway is UL listed to the UL5 Standard for  Surface Metal Raceway and Fittings. The 500/700 series raceway and fittings are to be installed as governed by NEC 386 (Surface Metal Raceways). NEC 386 states the followings: "Surface metal raceways and their elbows, couplings and similar fittings shall be designed so that the sections  can be electrically  and mechanically coupled together and installed without subjecting  the wires to abrasion". Our instructions do not show the requirement for bushings at system fittings because UL and the NEC do not have this requirement for connections between raceway and their associated fittings. If the local AHJ requires the use of a bushing at each connection, he has the authority to enforce that requirement. He may be looking at other areas of the code that dictate the use of bushings when transitioning from conduit to raceway and from conduit to boxes. He may also read NEC 386 as requiring a bushing to provide protection from abrasion at fitting connections within the 500/700 system. Thank you

    by|Jun 2, 2023
      caret
      Q:What if I have a soffit with 2.5?? Can this be cut to make the length of leg to be shorter?
      by|Jun 14, 2022
      2 Answers
      Answer This Question

      A:  Yes. You'll need a hacksaw and you might want touch-up paint. I installed an overhead fan using this and had to cut some of the pieces to fit. The cut edges were a little ragged so I used an emory cloth and dabbed a little white model paint on afterward.

      by|Jun 14, 2022

        A:  Hello, The Inside Elbow cannot be shortened. We alternative fittings depending on the application including twist elbows, 5711LHAWH or 5711RHAWH. In case this is an exterior soffit, the 700 Series Raceway is for indoor dry locations only. Please email us directly with additional questions at technical.support@legrand.us. Thank you

        by|Jun 14, 2022
          caret
          Q:Can I paint these fittings with a sprayed latex paint to match my walls?
          by|Sep 4, 2020
          1 Answer
          Answer This Question

          A:  We recommend using an oil based paint (like most spray paint) for best adhesion. Hope this helps!

          by|Sep 4, 2020
            caret
            Q:What is the difference between the series 500 and series 700 systems. Will both be able to fit 12 gauge wire? Will Romex (covered) wire fit inside the raceways or will I need to strip off the outer covering?
            by|Sep 4, 2020
            1 Answer
            Answer This Question

            A:  You should be able to fit both, but because the 700 series is a little larger, you will have more room to work with.

            by|Sep 4, 2020
              Showing 1-4 of 7

              Customer Reviews

              4.6 out of 5

              • 4.6 out of 82 reviews
              • 88% recommend this product
              Filter by:
              Showing 1-10 of 82 reviews
              • Verified Purchase
              • Verified Purchase
              by
              • Verified Purchase
              Form and functional cover.
              by
              • Verified Purchase
              by
              • Verified Purchase
              Excellent product for adding a receptacle, or device in a garage or workshop. Simple to install with a few screws, and a hacksaw. The only problem that I experienced was the fact that Home Depot didn’t have a very good selection of fittings.
              by
              • Verified Purchase
              • Verified Purchase
              • Verified Purchase
              Easy to work with and very durable. The clamps needed to secure it to the wall, or in my case the ceiling, were a bit hard to use. It took more force than expected to seat them and I had butted them up against a beam so that made it a bit harder. Once clamped into place, they are not going to come loose over time. Would use again.
              by
              • Verified Purchase
              This elbow made for an excellent finish to our wiring project. Legrand provides effective, aesthetically pleasing products for easily adding electrical components to your home.
              by
              • Verified Purchase
