Internet # 327684466

Model # AL2240LG-R5

Store SKU # 1010485290

Energy Efficient 10 ft.- 12 ft., 22.5 in. x 63 in. Insulated Aluminum Attic Ladder with 375 lbs. Type IAA Load Capacity

$348.00
Apply Now
Pay $298.00 after $50 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Ligther aluminum frame w/ pre-drilled holes for easy installation
  • R5 insulated door panel helps regulate temperature all year long
  • Attic Ladder fits 10 ft. to 12 ft. ceiling heights
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

This Louisville AL2240LG-R5 Aluminum Framed Attic Ladder features an R5 insulated door with factory installed weather stripping providing more energy efficiency than a traditional attic ladder. The aluminum frame is lighter weight and more square than traditional wood frames. It is designed for attic openings of 22.5 in. x 63 in. and fits ceiling heights from 10 ft to 12 ft. The gas piston system allows easier and smoother opening and closing of the door. This attic ladder has a working load capacity of 375 lbs.

Highlights

  • Rough opening 22 1/2 in. x 63 in.
  • Easier to open and close with gas piston system
  • Ansi certified for safety
  • Superior energy efficiency with r5 insulated door with weather stripping
  • Slip-resistant cross-tread steps provide steady footing and more comfort when ascending and descending
  • Return Policy

Product Information

Internet # 327684466

Model # AL2240LG-R5

Store SKU # 1010485290

Specifications

Dimensions

Maximum Ceiling Height (ft.)

12

Maximum Ladder Length (ft.)

12

Minimum Ceiling Height (ft.)

10

Recessed Opening Height (in.)

13

Recessed Opening Length (In.)

63

Recessed Opening Width (in.)

22.5

Rung/Step Depth (in.)

3.25 in

Step Rise (in.)

12

Swing Clearance (ft.)

7.6

Details

Features

Adjustable, Hardware Included, Insulated, Weather Resistant

Finish Type

Other

Fits Ceiling Height

10 ft.,12 ft.

Ladder Rating

Type 1A - 300 lbs.

Ladder Type

Attic

Load Capacity (lb.)

350 lb.

Material

Aluminum

Number of Steps

13

Product Weight (lb.)

48 lb

Returnable

90-Day

Rung/Step Material

Aluminum

Stainable/Paintable

Stainable & Paintable

Warranty / Certifications

Certifications and Listings

ANSI Certified

Manufacturer Warranty

90 Days Limited Warranty

Questions & Answers

404Questions
caret
Q:Is AH2240MS insulated door?
by|Apr 17, 2024
1 Answer
Answer This Question

A:  Thank you for the question! No, it is not insulated.

by|Apr 18, 2024
    caret
    Q:how do you define swing clearance? Where is it measured from? The back edge of the stair opening? Or the middle of the opening?
    by|Apr 16, 2024
    1 Answer
    Answer This Question

    A:  Thank you for the question! Swing clearance is measured from the piano hinge of the ladder to the outside edge of the middle section of the ladder when it is being unfolded and the middle section is parallel with the floor. This is the widest distance of the attic stairway or the "swing clearance" needed to open the ladder!

    by|Apr 18, 2024
      caret
      Q:We have a knotty pine wood ceiling. Can the knotty pine be installed onto the panel the closes to the ceiling flush to match the wood ceiling?
      by|Apr 15, 2024
      1 Answer
      Answer This Question

      A:  Thank you for the question! Yes, you can add the wood to the door panel. If it is too heavy, and the door won't stay closed, you may need to buy and install some type of latch that keeps the door closed.

      by|Apr 15, 2024
        caret
        Q:I have three questions. 1What size lag screws are recommended for that installation? 2. Is the aluminum frame pre drilled? 3. Can one person do the installation?
        by|Apr 12, 2024
        1 Answer
        Answer This Question

        A:  Thanks for the question! The lag screws are 1/4" diameter by 3 inches long. Yes, the aluminum frame has pre-drilled holes for the lag screws. This ladder needs 2 people for installation.

        by|Apr 15, 2024
          Showing 1-4 of 404

          Customer Reviews

          4.3 out of 5

          • 4.3 out of 2,026 reviews
          • 73% recommend this product
          Filter by:
          Showing 1-10 of 2,026 reviews
          I was worried hearing bad things about the aluminum pull downs but after seeing and installing it don't see what all the fuss was about installed great looks great functions perfectly love that is double sealed one for strip and insulated only had it 1 month now don't see how it could get damaged box was damaged during shipping but for was fine
          by
          • Verified Purchase
          Deliver as advertised. Installation was straight forward and easy. One note.... I did asked Louisville about adding a 5/8inch sheet rock to the door opening, as wanted more fire protection. They answered, saying the ladder/door could withstand the weight of the sheet rock. I wish I could add at picture of the installation, with the sheet rock. Best description, the ladder door is now flush with my ceiling, but adding the 5/8 rock, gave it a 5/8 recess, so I had to leave a 5/8 gap between the door hinge and my ceiling. . .
          by
          • Verified Purchase
          This is my 2nd purchase of this ladder. One in the house and this one for the garage…however it’s damaged and I have to return it and get another
          by
          • Verified Purchase
          Pretty ugly and the instructions are boring.
          Wasn’t bad. The instructions are pretty tedious but you can get through it. Its pretty ugly with big bolt heads on the cover, and the frame is metal but it still cased ok.
          by
            • Recommended
            Recommended — sturdy
            Overall this is a solid product and it adds so much accesibilty — well worth the purchase. I’ll mention a few “issues” I had, which were mainly the instructions. First, a schematic was missing and overall the renderings were faded and not well labeled. However, using logic made for a pretty sinple install overall. I did have a rough cut already in my garage before installing so most of the work had been done. It is tough to do this alone and its recommended that you have an extra set of hands.
            by
              • Recommended
              Nice sturdy attic ladder
              I bought this ladder for a second story attic I’ve been doing work in (wiring the rooms below for ceiling lights and fans. Our second story has 8 foot ceilings so it’s a pain to climb up into the attic through a high narrow scuttle hole and have fallen once from a step ladder climbing down so i decided to install this fold up access ladder to make it easier and safer. I bought the 22.5 x 54 rough opening ladder. Actual dimension are 21.5 x 53 so you have some wiggle room.
              by
                • Recommended
                Although the ladder itself is fine, the piece of composite board it is attached to is a disaster. the very first time i pulled it down, the bold went through the board. too expensive to remove and return the ladder!
                by
                • Verified Purchase
                Cardboard Door
                Horrible! The door is cracked on the corner just like the other people. The aluminum stairs are not stable and creak. I paid to have it installed. Now what do I do? Buy the old school wood one. I’ve always had good luck with those.
                by
                  1 found this review helpful
                  Cheap
                  The panel is thin and cheap. I have always bought Werner ladders. Ladder itself is good, but the cover panel is too thin and it is held on by small rivets that pulled through the panel after a few uses. I have installed at least 20 of the other brands and have never seen this happen
                  by
                    very cheaply made
                    We are returning it. The door is MDF and has ugly rivets and it was warped out of square and and door was cracked from the warping… not recommended
                    by
