Maestro Dual-Tech Motion Sensor Switch, 6-Amp/Single-Pole, White (MS-A102-WH)

$79.86
Apply Now
Pay $54.86 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • For use with 6A lighting or 4.4A fan; Single-Pole
  • Detects fine motion 2-3x's better than other sensors
  • No ground connection required
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

Introducing Lutron's latest sensing technology, the Maestro Dual Technology sensor uses both passive infrared and ultrasound waves to ensure reliable sensing in small rooms. You'll never worry about accidently leaving the lights on again with the Maestro Sensing Switch because it turns the lights on when you enter the room and off after you leave. This sensor has an adjustable timeout (1, 5, 15 or 30 minutes), so you can control how long the lights stay on after you leave the room and features XCT Dual Sensing Technology (PIR and ultrasound) which detects very fine motion, such as typing at a desk or reading, ensuring lights do not turn off inadvertently. Equipped with ambient light detection, you can customize your sensor to detect daylight so lights don't turn on with enough natural light in your room. Maestro Sensors work with any bulb type, including CFL's and LED's and will match the decor of any room in your home. Installing and setting up a Maestro in-wall, dual-technology occupancy sensor is a simple, easy and low cost way to save energy and add light automation to your home. Coordinating Claro wall plate and accessories sold separately.

Highlights

Product Information

Internet # 205643008

Model # MS-A102-WH

Store SKU # 1001083664

Specifications

Details

Amperage (A)

6 A

Color Family

White

Color/Finish

White

Commercial/Residential

Residential

Compatible Bulb Type

Halogen

Coverage Area (sq. ft.)

900

Device Style Type

Sensor w/o Wall Plate

Durability

Not Applicable

Electrical Features

Programmable

Field of View

180 Degrees

Function Type

Single Pole

Included

No Additional Items Included

Indoor/Outdoor

Indoor

Material

Resin

Maximum Distance (ft.)

30 ft

Motion Sense Type

Occupancy

Mounting Type

In-Wall

Number of Poles

1

Number of Switches

One

Package Quantity

1

Rating

General Purpose

Returnable

90-Day

Sensing Technology

Dual Tech Hybrid

Switch Depth (in.)

2.3 in

Switch Height (in.)

4.69 in

Switch Style

Push Button

Switch Width (in.)

2.3 in

Time Delay

1 Min.,15 Min.,30 Min.,5 Min.

Voltage

120 volt

Voltage (V)

120 V

Wattage (W)

720 W

Warranty / Certifications

Certifications and Listings

UL Listed

Manufacturer Warranty

5 Years Limited

Questions & Answers

3Questions
caret
Q:The words in the advertisement say 'no ground required' but the videos show two ground wires coming from the switch, a bare ground wire and a green ground wire. I do not understand.
by|Jan 13, 2023
1 Answer
Answer This Question

A:  Hello! The MS-A102 sensor requires either a True-Earth Ground connection or a Neutral Wire connection in order to be installed. You can find wiring and installation information on the installation guide here: https://webapiaw1proddat01st01.blob.core.windows.net/assets/documents/032565.pdf If you still have questions or concerns, please give us a call at 1-844-LUTRON1. We're here 24/7, so you can reach out anytime, day or night.

by|Mar 13, 2024
    caret
    Q:What is the noise that comes frome the unit?
    by|Oct 2, 2018
    1 Answer
    Answer This Question

    A:  The MS-A102-WH will make an audible clicking noise as the internal relay turns on and off.

    by|Nov 16, 2018
      1 found this answer helpful
      caret
      Q:Can I use this switch to turn on both the light and the fan in a powder room?
      by|Aug 25, 2018
      1 Answer
      Answer This Question

      A:  Yes, this sensor can be used to control both a light and a fan. To control them individually with this control, it will require a separate switch leg for both the light and the fan. Please see the following specification sheet for more information: http://www.lutron.com/TechnicalDocumentLibrary/369773_ENG.pdf

      by|Nov 16, 2018
        1 found this answer helpful
        Showing 1-3 of 3

        Customer Reviews

        4.2 out of 5

        • 4.2 out of 5 reviews
        • 75% recommend this product
        Filter by:
        Showing 1-5 of 5 reviews
        by
        • Verified Purchase
        Works like a charm
        Have had 2 (wired parallel) operating in a room for a year now in a student rental, because many tenants are not hardwired to turn off lights when absent. Can even be mounted on the ceiling. Not aware of any "clicking sound" as reported by others. Can be interfaced with a relay / contactor to control baseboard heaters. Could control portable A/C, but don't recommend it due to fact unit continues to operate even when occupant leaves, due to the fact it misinterprets airflow from A/C as though the person is still in the room.
        by
          • Recommended
          I am an Electrician. This is the 3rd one I bought and installed in my house. It's best one on th...
          I am an Electrician. This is the 3rd one I bought and installed in my house. It's best one on the market.
          by
          • Verified Purchase
          • Recommended
          Works great, only complaint would be it is a little noisey
          Works great, only complaint would be it is a little noisey
          by
          • Verified Purchase
          • Recommended
          I was not able to use this product because it requires a ground and a common and the hot lead. M...
          I was not able to use this product because it requires a ground and a common and the hot lead. My house is 100 yrs old and has been remodeled several times. The stairway to the top floor needs a motion sensor that is very sensitive. I thought this product sounded hopeful since it was double sensor IR & Ultrasonic, but it is useless for my purpose.
          by
          • Verified Purchase
          1 found this review helpful
          Showing 1-5 of 5 reviews

          Maestro Dual-Tech Motion Sensor Switch, 6-Amp/Single-Pole, White (MS-A102-WH)

          thumbnail
          Lutron Maestro Occupancy Sensing Switch
          Lutron Maestro Occupancy Sensor Switch offers the best sensing technology with simple installation and set-up. The switch can control all lighting loads including LEDs, fluorescents, and fans, and can be used in both 120 and 277 volt applications.
