Maestro Motion Sensor Switch, No Neutral Required, 5-Amp, Single-Pole/Multi-Location, Snow (MS-OPS5M-SW)

$40.76
Apply Now
Pay $15.76 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Motion sensor turns lights on and off when you enter/leave room
  • UL listed to work with all bulb types, including LED bulbs
  • For lights or exhaust fans controlled from one or more location
  • View More Details
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

Let Lutron's Maestro Occupancy Sensor switch turn the lights or fan on and off for you. It's a simple, easy, and low-cost way to save energy and add automation to your home. Install a Maestro Sensor and lights/fan turn on when you enter the room, and then turn off automatically after you leave. It features XCT sensing technology to detect fine motion, such as typing at a desk or reading a book, to ensure lights won't turn off inadvertently when you're still in the room. It also learns your preferred natural light level and keeps lights off with smart ambient light detection. Program your lights to turn off 1, 5, 15, or 30 minutes after you leave the room. Alternatively, you can set the motion sensor to vacancy-only mode to only turn off the lights when you leave a room, to meet Title 24 requirements. Equipped with ambient light detection, you can customize your sensor to detect daylight so lights don't turn on with enough natural light in your room. Keeping the sleek design of the Maestro family, Lutron sensors will match the decor of any room in your home. Install a sensor in your bedroom so lights aren't left on mistakenly or in the bathroom for your exhaust fan. This Maestro Sensor works with any bulb type, including LED bulbs, or fans up to 3 amps. This switch can also be easily programmed to function as a vacancy (manual-on) sensor. Coordinating Claro Wall plates and Accessories sold separately.

Highlights

  • Motion sensor switch automatically turns the lights on when you enter the room and off when you leave; covers major motion in a room up to 900 sq ft
  • Features XCT sensing technology which detects fine motion (up to 20 ft. away), such as typing at a desk or reading, ensuring lights do not turn off inadvertently
  • No neutral wire required
  • Smart Ambient Light Detection: Senses daylight in the room and learns your preferred light level over time, so your lights stay off if it's already bright
  • Programmable time-out of lights - set to turn off 1, 5, 15 or 30 minutes after leaving a room
  • Vacancy-Only Mode: Can be programmed as a vacancy-only sensor to meet Title 24 requirements
  • Can be used in single-pole, 3-way, or multi-location applications (use with MA-AS-WH, sold separately); great for larger rooms like garages, bathrooms, and private offices
  • Installs in as little as 15 minutes; works with up to 600W incandescent, halogen and electronic low-voltage, 450W magnetic low-voltage, 360W LED, 5-Amp ballasts, or 3-Amp fans
  • Includes (1) 5-Amp Maestro sensor switch; coordinating wallplate sold separately
  • Includes (1) 5-Amp Maestro sensor switch; coordinating wallplate sold separately coordinating wallplate sold separately




  • Lutron wiring wizard for installation help for dimmer switches, fan switches, 3 way switches


  • Need installation help? Click here for an interactive step by step wiring guide.
  • Click here for more information on Electronic Recycling Programs
  • Return Policy

Product Information

Internet # 203762945

Model # MS-OPS5M-SW

Specifications

Details

Amperage (A)

5 A

Color Family

White

Color/Finish

Snow

Commercial/Residential

Residential

Compatible Bulb Type

CFL, Halogen, Incandescent, LED

Coverage Area (sq. ft.)

900

Device Style Type

Sensor w/o Wall Plate

Durability

Not Applicable

Electrical Features

Programmable

Field of View

180 Degrees

Function Type

Single Pole

Included

No Additional Items Included

Indoor/Outdoor

Indoor

Material

Resin

Maximum Distance (ft.)

30 ft

Motion Sense Type

Occupancy, Vacancy

Mounting Type

In-Wall

Number of Poles

1

Number of Switches

One

Package Quantity

1

Rating

General Purpose

Returnable

90-Day

Sensing Technology

Passive Infared

Switch Depth (in.)

2.3 in

Switch Height (in.)

4.69 in

Switch Style

Push Button

Switch Width (in.)

2.3 in

Time Delay

1 Min.,15 Min.,30 Min.,5 Min.

Voltage

120 volt

Voltage (V)

120 V

Wattage (W)

600 W

Warranty / Certifications

Certifications and Listings

UL Listed

Manufacturer Warranty

5 Years Limited
