1000 CFM Black Power Roof Mount Attic Fan

$16011
Apply Now
Pay $135.11 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Attic fan helps cool up to 1,600 sq. ft. of attic space
  • Compact fan size with hemmed dome for a sleek look
  • High efficiency attic fan motor with adjustable thermostat
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
caret

Product Details

The GAF Master Flow ERV4 Power Roof Vent is a great overall investment in attic ventilation. It can quickly remove a larger volume of hot and/or humid air from your attic when compared to static ventilation. This in turn can help save money on your heating and cooling costs. The ERV4 model Power Roof Mount Vent can move air at a rate of up to 1000 cu. ft. per minute. It is designed for attic spaces up to 1600 sq. ft.
  • Energy efficient uses up to 55% less electricity than typical competitor's vents (based on GAF testing at 120-Volt)
  • Helps reduce energy costs and helps prolong the life of the roof and shingles
  • Galvanized steel construction for durability
  • Excellent for roof slopes 3:12 to 12:12
  • Heavy-duty internal screen helps prevent animal infestation
  • UL Listed
  • Miami-Dade County Product Control approved, State of Florida approved, and meets or exceeds the requirements of Texas Department of Insurance
  • Optional humidistat available (H1) - sold separately
  • Return Policy
caret

Specifications

Dimensions: H 9 in, W 25 in, D 25 in

Dimensions

Coverage Area (Sq.Ft)1600Cut-Out Diameter (in.)15
Net-Free Area (Sq. In.)480Product Depth (in.)25 in
Product Height (in.)9 inProduct Width (in.)25 in
Rough Opening Height (in.)15 inRough Opening Width (in.)15 in

Details

Airflow (CFM)1000Amperage (A)1.35 A
Color FamilyBlackColor/FinishBlack
Color/Finish FamilyBlackFeaturesAdjustable Thermostat, Paintable, Thermostat Controlled, Wildlife Guard
Horsepower (hp)1/12Intake/ExhaustExhaust
MaterialGalvanized SteelMounting PositionRoof Mount
Power TypeElectric PoweredProduct Weight (lb.)17 lb
Recommended Sq. Ft.1600Returnable90-Day
Ventilation TypeRoofVoltage (V)120 V
Wattage (watts)108

Warranty / Certifications

Manufacturer Warranty5-year Limited Parts/2-year Labor Warranty
caret

Questions & Answers

81Questions
caret
Q:Hello, Have large attic area on single story house. What temperature should I set thermostat control for fan exhaust proper operation.
by|Nov 23, 2023
1 Answer
Answer This Question

A:  The recommended temperature setting on all Master Flow Attic Fans is 105°f. If you have any inquiries about Master Flow products please email MasterFlowTech@gaf.com

by|Nov 28, 2023
    caret
    Q:What wind speeds is this unit expected to survive? Will it blow off in a hurricane?
    by|Oct 18, 2023
    1 Answer
    Answer This Question

    A:  The ERV series has Miami-Dade and FBC approval. Hurricanes have a wide variety of wind speeds, the wind speed and direction would play a part in the sustainable damage to buildings and property.

    by|Oct 19, 2023
      caret
      Q:I have 1 fan already exsisting on my roof. How far apart does a 2nd need to be.?
      by|Aug 27, 2023
      1 Answer
      Answer This Question

      A:  Ideally they should be evenly spaced on the roof. If you have any other inquiries about our Master Flow products please email, warrantyllbp@gaf.com

      by|Aug 30, 2023
        caret
        Q:Does this fan provide a NFA value when not in use? The opening is 15" diameter, and I only want it to come on above 90 defrees. Under 90 degrees is there a NFA value attacjed?
        by|Aug 17, 2023
        2 Answers
        Answer This Question

        A:  The fan does not come with an NFA value when not in use.

        by|Nov 27, 2023

          A:  Hello Matty, Thank you for your recent inquiry with The Home Depot. This fan does not offer a NFA value when not in use? To calculate NFA, take the attic square footage ÷ 2 = square inches of exhaust and square inches of intake NFA needed. This Attic fan has a 1000 CFM which stands for Cubic Feet per Minute and is a measurement of the cubic feet per minute of air a fan can draw. This means that the higher the CFM, the more powerful the air suction. So a 1000 CFM fan will draw more air than say, a 400 CFM We appreciate your business and look forward to serving you in the future.

          by|Aug 31, 2023
            Showing 1-4 of 81
            caret

            Customer Reviews

            4.5 out of 5
            (193)
            • 4.5
              out of 193 reviews
            • 94% recommend this product
            Filter by:
            Showing 1-10 of 193 reviews
            I bought this unit to replace the old one which lasted about 10 years built with the home. This n...
            I bought this unit to replace the old one which lasted about 10 years built with the home. This new one lasted less that 2 years and started squealing a LOT. Neighbors noticed how loud it was so time to replace it again. Really with it would have lasted a bit longer.
            by
              2 found this review helpful
              I bought this fan about 2 years ago and installed it back in winter in 2016. It was too hot i the...
              I bought this fan about 2 years ago and installed it back in winter in 2016. It was too hot i the attic to do it in summer. When me and my wife moved into our new house, I put the remote thermostat in the attic. The house was newly built, and had attic insulation "blown" in. It was really good at holding in heat during winter and keeping the attic somewhat cool. The house we were renting was old, had worn down and flattened "Pink Panther" insulation. It was horrible. Our electric bills were about $200 a month during summer when we lived there. I put in a gable mounted fan, and it dropped our bills down to about $125-150, so a significant drop in costs. Having seen for herself the benefits of a attic fan, she allowed me to cut a hole in our new home to install this one. Even though the house was new, and had great insulation, this fan still helped to keep the heat to a minimum. I spray painted the aluminum cover with a galvanizing spray, then with Rustoleum brown, to match the house color. During summer, we keep the AC set at 75 when were gone (we both work), and drop it to 72 when we get home. After 10pm, we drop it to 69, because we sleep better when its cold. We use Green Mountain Energy as our provider, and they give us a decent rate. Our Electric bills are as follows: March: $68.74 April: $79.07 May: $123.76 Projected Cost For June (AS of this writing. I still have 2 weeks to go) $143.50 I anticipate a higher bill for June, as my wife took a week off from work and stayed home during the week. I'm sure it would have been lower had she gone to work. I also did an experiment last week. I shut off the fan from the power source for 2 days, so i could record the temps in the attic. I've also included 2 pictures of the before and after. The BEFORE (shutting off the fan) picture shows the highest temp in 48 hours was 135 degrees. The AFTER (turning the fan back on) picture shows that the highest temp in the attic was 101 degrees. Also, when the AC runs, since it doesn't have to overcome such a high temp in the attic, the house cools down significantly faster, which means less cycling of the outside unit, which means less energy used. As far as i'm concerned, this is a MUST HAVE for anyone in the Houston and surrounding areas. The cost of savings far outweigh the cost of installing this fan.
              by
                • Recommended
                19 found this review helpful
                by
                  This unit is sufficient for my needs. This one is to replace the same model that died after 1.5 years. We will see how long this one lasts.
                  by
                  Response from Master FlowOct 19, 2023
                  Sorry for your experience. We do not typically have issues with this product. Thank you for your feedback. MasterFlow
                    by
                      Very quiet and powerful
                      by
                      Response from Master FlowOct 5, 2023
                      Thank you for the feedback. Glad you were satisfied with your Master Flow purchase. MasterFlow
                        by
                          Work great !! Put it in my 12' x 24' shed... it is pulling the air up thru the solid open evaves vents.
                          by
                          Response from Master FlowAug 31, 2023
                          Glad you were satisfied with your Master Flow purchase. Thanks for the feedback MasterFlow
                          • Verified Purchase
                          by
                          • Verified Purchase
                          by
                          • Verified Purchase
                          Showing 1-10 of 193 reviews
