1500 CFM Shingle Match Weathered Wood Power Roof Mount Attic Fan
- Helps cool attics up to 2,800 sq. ft. in size
- Compact size with hemmed dome for a sleek look
- High efficiency motor with adjustable thermostat
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The GAF Master Flow ERV6 Power Roof Vent is a great overall investment in attic ventilation. It can efficiently remove a larger volume of hot and/or humid air from your attic when compared to static ventilation. This in turn can help save money on your heating and cooling costs. The ERV6 model Power Roof Mount Vent can move air at a rate of up to 1500 cu. ft. per minute. It is designed for attic spaces up to 2800 sq. ft.
Highlights
- Don't know how much to order? A GAF QuickMeasure report provides all of the measurement data you need when planning your material orders. A complete bill of materials, with Home Depot product SKUs, is provided with each single-family report delivered in under 1 hour. Learn more here. [gaf.com [gaf.com]]
- Helps to reduce energy costs and helps prolong life of the roof and shingles
- Galvanized steel construction for durability
- Excellent for roof slopes 3:12 to 12:12
- Heavy-duty internal screen helps prevent animal infestation
- UL Listed
- Miami-Dade County Product Control approved, State of Florida approved, and meets or exceeds the requirements of Texas Department of Insurance
- Optional humidistat available (H1) - sold separately
- Return Policy
Product Information
Additional Resources
Shop All Master FlowSpecifications
Dimensions
Coverage Area (Sq.Ft) | 2800 |
|---|---|
Cut-Out Diameter (in.) | 15 |
Net-Free Area (Sq. In.) | 720 |
Product Height (in.) | 9 in |
Product Width (in.) | 25 in |
Rough Opening Height (in.) | 15 in |
Rough Opening Width (in.) | 15 in |
Details
Airflow (CFM) | 1500 |
|---|---|
Color Family | Brown |
Color/Finish | WeatheredWood |
Features | Adjustable Thermostat, Built-in Screen, Paintable |
Intake/Exhaust | Exhaust |
Material | Galvanized Steel |
Mounting Position | Roof Mount |
Power Type | Electric Powered |
Recommended Sq. Ft. | 2800 |
Returnable | 90-Day |
Ventilation Type | Roof |
Voltage (V) | 120 V |
Wattage (watts) | 127 |
Warranty / Certifications
Manufacturer Warranty | 10-year Limited Parts/5-year Labor Warranty |
|---|
Questions & Answers
Can you install this on a tile roof?
These have been designed for and tested on shingled roofs only. If you have any other questions about Master Flow products, please email MasterFlowTech@gaf.com
How close to the ridge should it be mounted?
The top opening of the hood must be 24" (609 mm) BELOW the ridge line. If you have any other questions regarding Master Flow products, please email MasterFlowTech@gaf.com
What temperature does uni turn off
This fan has an adjustable thermostat; it will start the fan when the temperature reaches the desired setting (recommended 105°f) and remain on until the temperature drops approximately 8-10 degrees from this setting. If you have any other inquiries about our Master Flow products, please email masterflowtech@gaf.com
How many wattage need for starter
This unit is a 1.65-amp motor equipped with a start capacitor; we recommend ensuring at least 3 amps are available per circuit. Please note that wattage is calculated by multiplying amperage by voltage.
what amperage and wire size is required
The ventilator should be connected to a 120 volt, 60 hertz, grounded circuit only with minimum 14-gauge wiring that has at least 3 amperes of available capacity. If you cannot confirm there is sufficient electrical capacity on an existing circuit, install a separate dedicated circuit. Do NOT use an extension cord to operate.
I have 2 Bitcoin Miners exhausting via a 12 inch diamater duct to the outside of my garage. I do not have a cover for it, and just have a 12 inch hole in the side of my garage. Measured the CFM and it is 1100 exhausting. Would this work as a Cover?
No, this is a roof-mount attic fan designed to ventilate an unoccupied attic space only.
Is it possible to replace motor from inside of attic ?
Yes, please see this link to replace the motor, https://youtu.be/5ghYG6j5cjY. You can contact masterflowtech@gaf.comif you have any questions.Thank you.
How does the "shingle match" feature work?
The Shingle Match Weathered Wood color fan matches the GAf Weathered Wood Shingles.
This product is offered in three color at match it to your current singles. Mike
