Compression Spring, Spring Steel Construction, Nickel-Plated Finish, .080 GA x 7/8 in. x 4 in., (2-Pack)
- Spring steel material withstands high stress without deformation
- Nickel plating prevents corrosion and enhances wear resistance
- Maximum safe load of 24.8 pounds
Free & Easy Returns In Store or Online
Return this item within 30 days of purchase.
Get an immediate answer with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
These Handyman compression springs by Prime-Line Products are constructed of durable spring steel, and they come finished in a beautiful, corrosive-resistant, nickel-plated finish. Compression springs like these are used for a variety of household and professional applications, and they feature a strong spring rate. These springs are easy to install and are used by many. The outside diameters, lengths and gauge thicknesses vary between each of these springs, while their dependability does not. Use these springs for repairs around the house, in the office, vehicle, garage and in many other applications.
Highlights
- For use in a variety of applications; appliances, automotive, marine, toys, tools, mechanical devices, contraptions and more
- Compression springs are designed with flat end coils and feature strong spring rates
- Spring dimensions: 7/8 inch outside diameter, 4 inch length, 0.08 inch wire diameter, 24.8 lbs. maximum safe load, 1.28 inch maximum deflection
- All springs come in a beautiful, corrosion resistant, nickel plated finish allowing them to be used both indoors and out
- Constructed of durable spring steel (tempered steel wire) to provide optimum expansion when compressed
- Designed for use with a variety of household and professional applications
- Easy to install with only a few simple tools
- For further dimensional information, please see the line drawing
- Return Policy
Product Information
Specifications
Dimensions: H 7.75 in, W 2.813 in, D 1 in
Dimensions
Product Depth (in.) | 1 in | Product Height (in.) | 7.75 in |
|---|---|---|---|
Product Width (in.) | 2.813 in |
Details
Builders Hardware Product Type | Window Operator | Material | Steel |
|---|---|---|---|
Package Quantity | 2 | Returnable | 30-Day |
Window Repair Type | Accessory |
Warranty / Certifications
Manufacturer Warranty | Goods are warranted against defects in manufacturing for 1 year. In no case is Prime-Line responsible for user related damage or damage incurred during installation. Warranty is void if products are subjected to abnormal conditions, misapplication or abuse. |
|---|
Questions & Answers
Can the spring be stretched to a length of over 4 inches?
Thank you for your inquiry regarding this item from Prime-Line Products. Use your own discretion. The is not an extension spring so will damage if it is stretched.
What is the compressed height? I
Thank you for your inquiry regarding this item from Prime-Line Products. The compressed height for this spring is 1.28 inches, also known as the "solid height" and "coil bind" measurement. For faster service, be sure to take advantage of the CHAT option located in the lower right-hand corner of your screen, where you can quickly be connected to a representative for assistance. Otherwise, you can contact the manufacturer directly with your questions regarding this item, or any other product manufactured by Prime-Line Products by calling their toll free number at (877) 649-9740, or by contacting them by email at prodtech@primeline.net
I have the same question for the same reason, but i need a better answer. What is the spring constant?
This spring has a spring constant of 7.392 Lbs. per in. For additional questions regarding this item, or any other product manufactured by Prime-Line Products, please call their toll free number at (877) 649-9740, or contact them by email at info@primeline.net
I am currently using this for an engineering project, and some calculations are required, so this would be useful information to have.
Thank you for your recent inquiry regarding this item from Prime-Line Products. Our goal is to make your shopping experience as easy as possible, but sometimes there are products like this one that requires additional information in regards to the specifics of your desired hardware. Please feel free to contact Prime-Line Products directly where a Customer Service Representative there can better assist you. For additional questions regarding this item, or any other product manufactured by Prime-Line Products, kindly call their toll free number at (877) 649-9740, or contact them by email at info@primeline.net
