50 CFM Ceiling/Wall Mount Easy Roomside Installation Bathroom/Bath Exhaust Fan with Adjustable LED Lighting, ENERGY STAR

$64.78
Apply Now
Pay $39.78 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • 50 CFM bathroom ceiling exhaust fan for 50 sq.ft. of ventilation
  • Adjustable LED light temp- warm white, bright white, day light
  • Easy installation with SheetLock tabs - installs in 30-minutes
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy

Product Details

About This Product

Highly reviewed by both professionals and DIY homeowners alike, ReVent has quickly become a trusted and top selling bathroom exhaust fan. Installing from the roomside happens in HALF THE TIME with Revent's award-winning Sheetlock installation method, featured on all ReVent models. No attic access needed. ReVent fans are ideal for replacing an existing bathroom fan or installing in new construction. Watch the installation video at in the image carousel at the top of the page.The RVL50 is a high performance 50 CFM, quiet bath fan that features an adjustable LED light that can switch between 3 different color temperatures to match the other lighting in your room. Select between Warm White (2700 Kelvin), Bright White (4000 Kelvin), and Daylight (5000 Kelvin). The RVL50 is also one of the QUIETEST operating bath fans on the market, at 0.5 Sones.We are known for our stellar customer service and speedy response time, you can rest assured that our friendly ReVent team will be there to help with any questions before, during, and after your purchase.

Highlights

  • 50 CFM bathroom ceiling exhaust fan for up to 50 sq.ft. of ventilation
  • Easy install bath fan from the roomside -No attic access required
  • Installs in HALF the time with SheetLock- Watch the install video
  • Dimensions for the fan box are 7 1/2 inches L by 7 1/4 inches W by 4 3/8 inches D
  • Shield cover dimensions are 9 3/4 inches by 9 3/4 inches
  • Sound level is 0.5 sones (very quiet)
  • SheetLock (fast, screwless fan mounting) mounts directly to sheetrock - with no attic access required
  • Adjustable 3 level LED lighting (2700K, 4000K, 5000K) offers 3 dimmable light temperature options.
  • Can be installed on both the ceiling and wall
  • Pro preferred, homeowner approved
  • Easy replacement fan for DIY installers
  • Click here to view the ReVent Room Selector Buying Guide
  • Shield can be painted to match your ceiling color
  • UL listed for use over a bathtub or shower when installed in a GFCI protected circuit
  • ENERGY STAR and HVI certified
  • 3 Year Warranty
  • Questions? We're happy to help! Call us at 1-877-543-8698 or email info@reventfans.com
  • Click here for more information on Electronic Recycling Programs
  • Return Policy

Product Information

Internet # 317845262

Model # RVL50-D

Store SKU # 1006694034

Specifications

Dimensions: H 4.375 in, W 7.5 in, L 7.25 in

Dimensions

Housing Length (in.)

7.25

Housing Width (in.)

7.5

Product Height (in.)

4.375 in

Product Length (in.)

7.25 in

Product Width (in.)

7.5 in

Details

Air Volume (CFM)

50

Amperage (amps)

0.27

Color/Finish

White

Duct Compatible Sizes

3 in, 4 in

Features

Light, No Cut Installation, Roomside Installation

Grill Shape

Square

Housing Material

Metal

Included

Light Bulb

Installation Type

Ceiling, Wall

Light Bulb Type Included

Integrated LED

Maximum Light Bulb Wattage (watts)

13

Maximum Room Size (sq. ft.)

50

Mount Type

Flush Mount

Number of Bulbs Required

0

Pack Size

1

Product Weight (lb.)

4 lb

Returnable

90-Day

Room Size

Small Room Fan

Voltage (V)

120

Wattage (watts)

5.8

Warranty / Certifications

Certifications and Listings

Energy Star, HVI Certified, UL Listed

Manufacturer Warranty

3 Year Limited Warranty

Questions & Answers

153Questions
caret
Q:Can this be hook up to a dimmer or do u need manually climb a ladder change the light setting each time...thanks
by|Jun 8, 2024
1 Answer
Answer This Question

A:  Yes, the light can be connected to a dimmer. The switch on the fan shield allows you to change the white light color temperature. Most will set it to one temperature and leave it.

by|Jun 19, 2024
    caret
    Q:How many sones is the 50 cam ?
    by|May 17, 2024
    1 Answer
    Answer This Question

    A:  The RVL50 is 0.5 sones, which is considered very quiet.

    by|May 20, 2024
      caret
      Q:Hi, we have an older building with a duct size of 3" only for a 40 squ ft BA. I saw in your prior answers that the 50 CFM model will work. What exactly do I have to do to reduce fit the fan into the smaller hole? Is there an instruction video/manual?
      by|May 10, 2024
      1 Answer
      Answer This Question

      A:  The opening size for the RVL50 is 7.5" xx 7.25", so you will want to cut the hole to that size if it is smaller than that. We have an installation video in the image carousel on homedepot.com, or several other helpful videos on YouTube by searching ReVent Ventilation Fans. Here's an in-depth install video: https://www.youtube.com/watch?v=_DYZ-m0Jnvw

      by|May 15, 2024
        caret
        Q:Do you make a larger trim ring? The one provided does not cover the entire opening. Leaves the edge of the hole exposed on one side..
        by|May 8, 2024
        2 Answers
        Answer This Question

        A:  You can buy an adapter trim. Just search goof ring or goof adapter.

        by|Jun 12, 2024

          A:  The trim ring matches the size of the fan box. For the gap, we recommend patching the drywall. Or you may want to consider sizing up to a larger CFM size, like the 110 CFM model. Feel free to call us directly with any questions 1-877-543-8698.

          by|May 15, 2024
            Showing 1-4 of 153

            Customer Reviews

            4.2 out of 5

            • 4.2 out of 751 reviews
            • 65% recommend this product
            Filter by:
            Showing 1-10 of 751 reviews
            Replacing the old bathroom exhaust fan would have been impossible from above, as large HVAC vents were positioned over that portion of the ceiling. Thankfully, the ReVent fan made the job much simpler because it's designed to be installed from below. The finished installation was excellent. The fan is seated securely in the ceiling and runs quietly and effectively. The Kelvin-adjustable light fills the room. (We have it set on 3,500K, which is toward the softer end of the brightness scale.) Bottom line: I would buy it again.
            by
            Response from ReVentJun 19, 2024
            Great feedback! Thanks for taking the time to leave us a review. ReVent
            • Verified Purchase
            1 found this review helpful
            Great fan and better than average light.
            2yrs old. Prior to installing the exhaust duct this fan (RVL110) pulled the bath door open 5" and nearly silent. Connecting the old 3" foil duct the perf fell to 3/4" and was loud. While upgrading to a 4" alum semi-rigid duct I found a major restr at the roof vent. Now it pulls open 3" w/ less noise that the prev. much smaller fan. It didn't keep the mirror from fogging until I trimmed the door to a 3/4" gap, a huge improvement! This morning I found the springs broke. I can't find ReVent parts.
            by
            Response from ReVentMay 20, 2024
            Thanks for your feedback. You made all the right changes to improve the performance. Call us and we'll send you new springs free of charge 1-877-543-8698.
            If the bathroom is sealed tightly, replacement air may not be entering the room fast enough to displace moist air. You need a gap under the bathroom entrance door to allow air to enter the bathroom. If your home uses 3 inch diameter ducting, upgrading the duct pipe to 4 inch diameter can greatly increase the airflow. ReVent
              1 found this review helpful
              Excellent customer service
              Great light output. I contacted customer service through email with an issue. I believe mine was pest the support date, but I was still able to obtain parts with instruction for repair direct from the manufacturer. I was impressed with the support very much. Thank you! 😊
              by
              Response from ReVentMay 8, 2024
              We pride ourselves on our fantastic customer support team- and this is why! Thank you so much for taking the time to leave a review. ReVent
                • Recommended
                Modern
                I didn’t know they made good looking fan/light combos like this. So modern and sophisticated looking. It even works on a dimmer is you want it that way. My sisters who recently remodeled their bathrooms were blown away by the new style. Looks good. Works great.
                by
                Response from ReVentMay 8, 2024
                We felt it was about time for an updated look for bathroom fans, and thus, ReVent was created! Glad to hear you are enjoying the style and function that ReVent offers. ReVent
                  • Recommended
                  1 found this review helpful
                  Very quiet, light can be set to your preference. Easy installation. Very happy with the end results.
                  by
                  Response from ReVentMar 6, 2024
                  Thanks for the feedback, Jerry! We appreciate you taking the time to leave a review. ReVent
                  • Verified Purchase
                  1 found this review helpful
                  Great light, fan doesn’t do much
                  I bought this because I needed a fan big enough to cover the hole in my ceiling. My bathroom is about 5.5x11. My window remains totally fogged during a shower, so I’m not sure how much the fan does. The light is bright enough to be the only light in the room and is attractive
                  by
                  Response from ReVentFeb 28, 2024
                  It’s actually a common misconception that bathroom mirrors should not fog up, because this is not always the case. If windows and mirrors are very cold, condensation can still form on those surfaces. Here are some other things to check for to help the performance: If the bathroom is sealed tightly, replacement air may not be entering the room fast enough to displace moist air. You need a gap under the bathroom entrance door to allow air to enter the bathroom. If your home uses 3 inch diameter ducting, upgrading the duct pipe to 4 inch diameter can greatly increase the airflow. The vent pipe length should be 10 feet or less with minimal bends. Ensure that the vent pipe is not blocked. Please give us a call if you have any questions 1-877-543-8698 or email info@reventfans.com ReVent
                    • Recommended
                    Pretty easy install. I have installed 3 of these in my house. Fan is quiet & led light is bright.
                    by
                    • Verified Purchase
                    3 years old and broken
                    When removing cover/light both retention springs broke due to corrosion and can not be replaced because the attachment screws are so corroded they can not be removed. If the manufacturer had spent a few pennies more on good stainless steel hardware they would not be getting a failing one star review.
                    by
                    Response from ReVentOct 25, 2023
                    We're sorry to hear about this, but we can absolutely send you a replacement. Please give us a call and we will take care of you! 1-877-543-8698 or email info@reventfans.com ReVent
                      1 found this review helpful
                      DO NOT BUY - NOT ENOUGH POWER!
                      We bought several of these exhaust fans while doing a whole house refresh a year ago. None of them work well. We installed TWO of the 150 CFM at either end of our 150 sf master bathroom, which originally had just one larger one, so this should have been overkill. They turn on together, and even so, they barely pull in any air, and the walls and ceiling are literally dripping with condensation! And all of the fans are like this! Not nearly enough power to do the job! Waste of money and time!
                      by
                      Response from ReVentOct 25, 2023
                      We're thankful you reached out to us because we are certain we can help with this! For what you are describing, there is ample CFM for your room size, so we believe there may be something blocking the airflow. Sometimes it's as simple as forgetting to remove the cap or tape on the damper. This is very simple to troubleshoot and diagnose, so please give us a call and we can help! 1-877-543-8698 or email info@reventfans.com ReVent
                        1 found this review helpful
                        Loud Loud Loud
                        Installed this fan as part of home remodel 3 months ago and I had to retrofit sheetrock from old Broan to get it to fit.. This thing is so loud I can’t think in the water closet. I’m hoping it is just defective. Wish I could post a video.
                        by
                        Response from ReVentSep 19, 2023
                        Thank you for your review. This is an often easy fix! It’s likely that another aspect of the installation is causing the fan to be louder than it should. Sometimes it's as simple as forgetting to remove the cap or tape on the damper. Please give us a call and we can help troubleshoot the root cause 1-877-543-8698 or info@reventfans.com. In the meantime, please check for the following:
                        1. Dirty or clogged vent pipe 2. Closed vent pipe damper 3. Vent pipe should be 4 in diameter. 4. Length of vent pipe should not exceed 10 ft. ReVent
