Internet #202687934

Model #U860R300

1/2 in. x 300 ft. Coil Red PEX Pipe

  • Can be installed wet for immediate pressure testing
  • Strong, Flexible, and Corrosion Resistant Pipe
  • Connectable with SharkBite Push to Connect or barbed fittings
  • See More Details

Frequently Bought Together

+
+
Price:
$7375

Product Overview

Mix of the versitile Pex and PTC Assortment

Versatile Applications

Compatible with multiple fitting systems including, SharkBite EvoPEX, SharkBite Push-to-Connect, plastic barb, and brass barb fittings.

Installing PEX Pipe behind a wall with PTC fittings

Time Saving Installation

Faster installation time compared to rigid pipe

Image showing PEX Pipe under concrete

Approved for Underground

Approved for water service lines and burial applications, including being buried under concrete.

Man installing PEX Pipe that is showing the flexiblilty

Flexible

PEX Pipe has the ability to bend around corners, which removes the need for elbow fittings in tight spaces.

Men installing PEX Pipe behind a wall

Versatile

PEX can be installed under wet or dry conditions

PEX Pipe being coiled in a plant

Versatile Length Availability

PEX Pipe is available in cold up to 1,000 ft. in length, allowing longer runs and fewer connections -- reducing cost, time, and potential leak points.

Man carrying pipe

Cost Effective

PEX Pipe costs a third of the price of Copper Pipe.

SharkBite Logo

Proven and Dependable

Brought to you by SharkBite, the leading brand in innovation.

Chlorine Molecule Icon

Chlorine Resistant

Offers the highest-rated chlorine resistance and six-month UV resistance

PEX Corrosion resistant

Corrosion resistant

Immune to mineral build up

Pipe Frozen Icon

Freeze Resistant

Pipe expands and contracts as water freezes and thaws within pipe. Ideal for hot and cold potable water distribution and municipal water service lines.

Check Mark Icon

Approved

Approved for residential and commercial applications

Made in the USA Icon

Made in the USA

Proudly Manufactured in the USA

SharkBite PEX tubing is cross-linked polyethylene tubing for a wide range of residential and commercial plumbing applications. PEX Pipe is durable, flexible and corrosion resistant. Manufactured without an oxygen barrier for potable water systems (available in white, blue, and red). A repeating SharkBite imprint patterns provides a visual aid to determine if the tube has been inserted all the way into the SharkBite Push-to-Connect Fitting. This feature only works if the tubing is cut between the SharkBite imprint patterns. In addition to Potable Water Supply SharkBite PEX meets UL Standard for Plastic Piping in Fire Systems.
  • Strong, flexible, corrosion-resistant pipe
  • Flexibility reduces number of fittings needed to complete a job; reducing cost and leak points
  • Can be installed wet or dry for immediate pressure testing
  • SharkBite imprint pattern provides a visual aid to ensure pipe is fully inserted when using SharkBite push-to-connect fittings
  • SharkBite system provides a variety of connection options, SharkBite PEX can be connected with SharkBite push-to-connect fittings or barbed fittings
  • Listed to NSF 14 and CSA B137.5 for use in potable water systems
  • Meets UL1821 standard for plastic piping for fire systems (3/4 in. and 1 in. only)
  • Manufactured and tested to meet or exceed the requirements of the ASTM F-876/877/2023 and CSA B137.5
  • Shop all SharkBite Fittings
  • Find additional savings at your local PRO Desk with the Buying Guide

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar PEX Pipe

3/8 in. x 100 ft. Coil Red PEX Pipe
current product
1/2 in. x 300 ft. Coil Red PEX Pipe
1/2 in. x 300 ft. Coil White PEX Pipe1/2 in. x 500 ft. Coil White PEX Pipe
BrandSharkBiteSharkBiteSharkBiteSharkBite
Name3/8 in. x 100 ft. Coil Red PEX Pipe1/2 in. x 300 ft. Coil Red PEX Pipe1/2 in. x 300 ft. Coil White PEX Pipe1/2 in. x 500 ft. Coil White PEX Pipe
Price
$3328
$7375
$7510
$13100
Ratings
(147)
(42)
(43)
(33)
Nominal Inside Pipe Diameter (In.)3/8"1/2"1/2"1/2"
Product Length (ft.)100 ft300 ft300 ft500 ft
PEX TypeBBBB
ApplicationPotable WaterPotable WaterPotable WaterPotable Water
ConnectivityPush FitPush FitPush FitPush Fit
MaterialCross-Linked Polyethylene (PEX)Cross-Linked Polyethylene (PEX)Cross-Linked Polyethylene (PEX)Cross-Linked Polyethylene (PEX)
Actual outside diameter (in.)0.50.6250.625.625
Actual inside diameter (in.).350.4750.4750.475
Pipe FeaturesFlexibleFlexibleFlexibleFlexible
View ProductView ProductView ProductView Product

Specifications

Dimensions

Actual inside diameter (in.)
.475
Actual outside diameter (in.)
0.625
Nominal Inside Pipe Diameter (In.)
1/2"
Pipe Wall Thickness (In.)
.15
Product Length (ft.)
300 ft

Details

Application
Potable Water
Color Family
Red
Color/Finish
Red
Connectivity
Push Fit
Material
Cross-Linked Polyethylene (PEX)
Maximum Flow Rate (gallons per minute)
4.4
Maximum working pressure (psi)
160
Maximum Working Temperature (F)
200
Minimum working temperature (F)
32.0
Pack Size
1
PEX Type
B
Pipe Features
Flexible
Pipe or Fitting Product Type
Pipe & Tubing
Product Weight (lb.)
17
Returnable
180-Day

Warranty / Certifications

Certifications and Listings
IAPMO Certified
Manufacturer Warranty
For warranty information on this product, please call our Internet Customer Service Center at 1-800-435-4654.

Questions & Answers

26Questions15Answers

What is the country of origin?

Asked by Jj September 3, 2020
1
Answer

Hello, SharkBite PEX tubing is manufactured in the U.S.A. If you have additional questions please don't hesitate to reach out to our technical support department at 877-700-4242. Best Regards,

can the product be buried to run water to horse pasture. If so what depth do you recommend? We also get snow sometimes

Asked by Matt July 22, 2020
1
Answer

Hello, SharkBite PEX tubing is suitable for burial but should not be used in areas where the soil is or may become contaminated* including the soil used for back filling. All SharkBite Universal fittings with brass bodies must have an impervious barrier (such as SharkBite silicone wrap) between the fitting and the surrounding soil. Self-fusing, formaldehyde and chloride-free, fully cured silicone tape with a minimum thickness of 0.020" should be used for this purpose. The soil used for back filling must be free of rocks, debris or any sharp objects that may cause damage to the fitting or pipe through impact or abrasion. * Examples of contamination include, but are not limited to, petrochemicals (reclaimed service station sites), high levels of nitrogen compounds (this could be caused by animal waste or fertilizer that may be found in some agricultural applications), low pH levels (below pH 6), high pH levels(above pH 8), run off from land fill, formaldehyde compounds, and solvents. It should be noted that such contaminants have been known to migrate through plastic piping systems and contaminate the Potable water supplied through these pipes. It will be necessary to find the frost line depth for pipes in your particular area as this is different from place to place. If you have additional questions please don't hesitate to reach out to our technical support department at 877-700-4242. Best Regards,

can this be used as buried pipe to a yard hydrant?

Asked by hydrant September 9, 2019
1
Answer

I believe as long as its not for drinking water purposes it should be fine. The issue with burial in soil is the leaching of chemicals from the dirt into the water supply, so generally burial of pex is not recommended for drinking water applications. Other than that, thats what i dug up from previous research. If i had to do it for a non drinking application i definitely would do it.

can this pipe be buried under ground?

Asked by MadeinMaine September 3, 2019
2
Answers

Hello, Yes, SharkBite PEX tubing is suitable for burial in most areas. We do recommend checking with your local AHJ (Authority Having Jurisdiction) for approval in your area. Please be aware our brass fittings are approved for burial but our fitting wrap must be used to prevent potential contaminants in the soil from negatively effecting the brass. Below is a link to our silicone wrap along with a link to our installation instructions. Please see page 4 our installation instructions for burial requirements and instructions on how to use our burial wrap. There is also a link to a video that goes over how to wrap a fitting. If you have additional questions please feel free to contact our technical support department at 877-700-4242. http://www.sharkbite.com/product/sharkbite-silicone-wrap/ https://www.sharkbite.com/sites/g/files/rgohfh321/files/2018-05/SharkBite_Installation_Instructions_2018_WEB.pdf https://www.sharkbite.com/resources/video/how-wrapping-sharkbiter-fittings-underground-installations Best Regards,

Can shark bite be used for pluming and shop with air compressors

Asked by Randy6411 August 7, 2019
1
Answer

Hello, SharkBite push-to-connect fittings are approved for potable water and radiant/hydronic heating applications. We do not recommend the use of our fittings with air. If you have additional questions please feel free to contact our technical support department at 877-700-4242. Best Regards,

can I use an expansion tool with Uponor fittings instead of Sharkbite or clamps?

Asked by FumblePlummer July 26, 2019
2
Answers

No. Uponor is a different size.

what is the material of the PEX Pipe

Asked by Alex April 8, 2019
1
Answer

PEX pipe is made from cross-linked HDPE (high density polyethylene). The HDPE is melted and continuously extruded into a tube to form a high-performing pipe suitable for a variety of potable plumbing applications.

Can Sharkbite pex be buried underground

Asked by clay November 13, 2018
2
Answers

I live in Georgia and burried close to 300 feet over a year ago and I have had no issues. I run over it with my heavy John Deere tractor all the time, still no problems.

Can this be used to connect my well to water stickers around my property? Is 1 inch big enough? I’ll be attaching a hose

Asked by Troy November 2, 2018
2
Answers

Yes it can be. You can use our red, white or blue PEX pipe. All are manufactured the same and have all same plumbing codes. We just add a color additive to the red and blue for customers to remember which line is for hot and cold when installing new fixtures. If you have further questions, please contact Customer Service M-F, 8am-5pm at (877) 700-4242.

is this pipe suitable to use underground from service meter to house?

Asked by christi June 23, 2018
2
Answers

Yes, SharkBite PEX pipe is approved to AWWA C904 which covers PEX pipe in regards to burial. Be sure to check with local, city or state codes to see if the pipe needs to have sleeves or any type of protective burial for your area. PEX pipe can be used as a service line based on its corrosion resistance to soil and water, its long life, and its oxidative resistance. Please contact Customer Service M-F, 8am-5pm at (877) 700-4242, if you have any further questions.
