Internet #205227051

Model #ABW46Z

Store SKU #1002746099

ABW ZMAX Galvanized Adjustable Standoff Post Base for 4x6 Nominal Lumber

  • Adjustable post base designed for versatility
  • Great for use on patios and decks
  • Easy to install
  • See More Details

Frequently Bought Together

+
+
Price:
$2065

Product Overview

Deck Glamour Photo

Deck It Out

Strong decks bring beauty and entertaining space to your outdoor living area

Deck Glamour Photo

Make Your Deck Beautiful and Safe

Building a safe, strong deck starts with the proper connectors and fasteners

Photo of a deck being built

Deck Building Tips and Tricks

Installing corrosion-resistant connectors and fasteners helps extend the life of your deck

SDWH Screw being installed into ledger

Ledger connections critical for deck safety

Strong-Drive® SDWH Timber-Hex HDG screw delivers high-strength, wood-to-wood connectivity, such as deck ledger applications

DTT2Z guardrail install

Guardrail Installation Tips and Tricks

Don’t take chances with guardrail connections. DTT2Z deck tension ties fasten guardrails to deck framing.

DTT1Z install

Securing the Deck to the House

Install DTT1Z as a tension tie to meet building codes and eliminate the need to access to the floor joists inside the home

LSCZ install

Take the Step to Secure Deck Stairs

LSCZ adjustable stair-stringer connector offers a concealed connection between the stair stringer and the carrying header or rim board

Tight LUS26Z install shot

Joist Hangers

Provides bearing and uplift resistance

Tight H1 install shot

Hurricane Ties

Ideal for preventing lateral movement of joists

Tight SD screw install photo

SD Connector Screw

The only screw approved with Simpson Strong-Tie connectors

Tight install shot of LCEZ4

Post Caps

LCEZ end post caps provide a post-to-beam connection in new or retrofit deck applications

Tight PBSZ install photo

Post Base

Features a 1 in. standoff to resist wood decay

Stainless-steel connector product shot

Prevent Corrosion

Deck-Drive DWP stainless-steel fasteners are recommended for higher-exposure environments or applications

Post and column bases secure the bottom of posts or columns to concrete and are perfect for decks or patio covers. Models are available for attaching to existing hardened concrete, wet concrete, as well as wood. The AB series also offers adjustability around the anchor bolt to achieve optimum post placement. Many models provide a 1 in. standoff from the concrete to help avoid post-end rot from moisture.
  • Attaches a post to existing concrete for decks, patio covers and other top-supported structures
  • Features 1 in. standoff to help prevent rot at post end
  • Slotted for adjustability
  • Designed for versatility, cost-effectiveness and maximum uplift performance
  • Nominal post size: 4x6
  • Steel gauge: Base 12, strap 16
  • ZMAX galvanization offers extra corrosion resistance for exterior and treated-wood applications
  • Install with 10d common nails or #9 x 1-1/2 in. Strong-Drive® SD screws
  • Shop all Simpson Strong-Tie here.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Nominal Post Size (in.)
4x6
Product Depth (in.)
5.5625
Product Height (in.)
3
Product Width (in.)
3.5625

Details

Base Type
Standoff Post Base
Connector Finish
G185 Galvanized
Fasteners Included
Fasteners Not Included
Features
No Additional Features
Gauge
12
Material
Steel
Material Connector Compatibility
Wood to Concrete
Number of Pieces
1
Package Quantity
1
Product Weight (lb.)
2.7
Returnable
180-Day

Warranty / Certifications

Manufacturer Warranty
Limited Warranty

Questions & Answers

17Questions12Answers

Hi, what size or model screws should i get?

Asked by Jo July 15, 2020
1
Answer

The ABW46Z attaches to the post with a quantity of 10 - *0.148" diameter x 3" long common nails or 10 - SD9112 structural connector screws. It anchors to the concrete with a 1/2" diameter anchor; anchor bolt type, length and embedment to be specified by the Designer/Engineer of Record. (*hot dip galvanized nails with the Z-MAX connectors) Thank you!

Can this be used without using the bolt into the concrete just to keep the post off the concrete ...

Asked by Rick May 26, 2020
2
Answers

but I need to be able to move the post around and this base looks like it would keep the post from sitting in water... Surely there is some sort of 'stand' if this is not it? Any ideas?

How deep do you need to pour concrete?

Asked by Jared April 15, 2020
1
Answer

Sorry I did not have to pour concrete. I did drill to install the anchors and the concrete was approx 5 in thick. I installed large 6x6 cedar posts, everything is solid!!

What size wedge anchor diameter is required?

Asked by LB August 20, 2019
2
Answers

I would not use anything smaller than a 1" expansion anchor minimum of 4" long. This is presuming you are attaching the standoff on a concrete support.

What size anchor bolt fits through the bottom and what size screws do you use to secure the post?

Asked by Brian April 23, 2019
1
Answer

I used 1/2” anchor bolts (make sure the are galvanized or stainless). Also you don’t use screws to secure the post. Because it is an application where the fastener will experience significant shearing nails are recommended here. Again make sure they are galvanized. I would do a quick web search for Simpson strong ties online catalog that has all of this information.

What is the difference between this item (ABW44Z) and the ABA44Z?

Asked by Ryan April 15, 2019
1
Answer

The difference is the product dimensions. Model ABA44Z has a depth of 3.063, height of 3.125 and width of 3.563 compared to ABW44Z's 3.563 in depth, 2.25 in height and 3.563 in width.

How much adjustment ( up

Asked by Bigmatt April 2, 2019
1
Answer

I'm not sure what you are asking but I can tall you this is what you need to protect a supporting wood column from a concrete support. I used a 1/2" expansion anchor drilled into the concrete and then set the wood post into the galvanized base with galvanized screws. This procedure meets all necessary Codes.

Can this be used to attach a 4x4 post to concrete patio for use in a railing system?

Asked by gigemsteve07 March 24, 2019
1
Answer

Post bases do not provide adequate resistance to prevent members from rotating about the base and therefore are not recommended for non-top-supported installations (such as fences, railings or unbraced carports). We do not have a base to recommend for railing applications to existing concrete. Thank you!

Are there holes in the base for anchoring this to wood using screws or nails?

Asked by Jeff July 4, 2018
1
Answer

Yes, there are holes for anchor bolts.

I'm replacing a post that's holding up a small corner (7'x10') of the house, which seems to be do...

Asked by PT August 29, 2017
1
Answer

sounds like your problem is at the attched beams or supports...Anchoring the deck or roof or floor to the proper upper support beams is critical to keep the post level and upright ... Do not worry about the 1" gap as it is stronger than the post itself. it helps keep termites away from the wood as a disruptor to their food source. Very strong metal. I have used these for years with no problems what so ever.

ABW ZMAX Galvanized Adjustable Standoff Post Base for 4x6 Nominal Lumber - page 2

Customer Reviews

  • 36 Customer Reviews
  • 5 out of 5 stars overall
100% of customers recommended.
Overall Ratings
5star-icon(34)
4star-icon(2)
3star-icon(0)
2star-icon(0)
1star-icon(0)
Sort By:
Works great and provides a solid base for your posts. I used this for my main structural support...
Works great and provides a solid base for your posts. I used this for my main structural support of my 22'X14' deck. produced a very sturdy structure.
Was this helpful?
1
0
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
Was this helpful?
0
0
Just what I needed....
Just what I needed.
Was this helpful?
0
0
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
Was this helpful?
0
0
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
Was this helpful?
0
0
they hold the post solid easy to work with
they hold the post solid easy to work with
Was this helpful?
0
0
5 Star Review
Rating provided by a verified purchaser
Was this helpful?
0
0
I was moving a patio cover post and needed one of these. It's really nice b...
I was moving a patio cover post and needed one of these. It's really nice because the bottom of the wood post sits inside this a good inch off the ground. Really protects the post from water that could collect around the base of the post.
Was this helpful?
0
0
Perfect for what I needed.
Quality :
5
Value :
5
I was moving a patio cover post and needed one of these. It's really nice because the bottom of the wood post sits inside this a good inch off the ground. Really protects the post from water that could collect around the base of the post.
Was this helpful?
0
0
Super easy to use and works great
Super easy to use and works great
Was this helpful?
0
0
