Internet #100375058

Model # CB44

Store SKU #461687

Store SO SKU #592854

0044315151002

CB Galvanized Column Base for 4x4 Nominal Lumber

  • Provides high structural values and rugged performance
  • Mounts the post flush with the top of the concrete
  • 7-gauge steel construction ensures strength
$ 18 79
Loading Options

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Provides high structural values and rugged performance
  • Mounts the post flush with the top of the concrete
  • 7-gauge steel construction ensures strength
Simpson Strong-Tie connectors make projects easier to build while making them stronger and safer. They are engineered and tested to perform and are manufactured to the highest quality standards. Whether working on a home project or building a structure to comply with building codes, go with the choice of engineers and contractors, go with genuine Simpson Strong-Tie connectors. The CB column base is made for columns and posts that require high structural values and rugged performance.
  • Designed to mount the post flush with the top of the concrete
  • Helps reduce uplift loads on posts or columns
  • Diamond holes are included to provide for temporary fastening
  • Nominal column size: 4 in. x 4 in.
  • Made from 7-Gauge steel
  • Galvanized (G90) for extra corrosion resistance
  • Install with 5/8 in. diameter machine bolts
  • Shop all Simpson Strong-Tie here.

Product Overview

  • Provides high structural values and rugged performance
  • Mounts the post flush with the top of the concrete
  • 7-gauge steel construction ensures strength
Model #: CB44
Sku #: 461687
Internet #: 100375058

Simpson Strong-Tie connectors make projects easier to build while making them stronger and safer. They are engineered and tested to perform and are manufactured to the highest quality standards. Whether working on a home project or building a structure to comply with building codes, go with the choice of engineers and contractors, go with genuine Simpson Strong-Tie connectors. The CB column base is made for columns and posts that require high structural values and rugged performance.

  • Designed to mount the post flush with the top of the concrete
  • Helps reduce uplift loads on posts or columns
  • Diamond holes are included to provide for temporary fastening
  • Nominal column size: 4 in. x 4 in.
  • Made from 7-Gauge steel
  • Galvanized (G90) for extra corrosion resistance
  • Install with 5/8 in. diameter machine bolts
  • Shop all Simpson Strong-Tie here.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Nominal Post Size (in.)
4x4
Product Depth (in.)
3.563
Product Height (in.)
16.688
Product Width (in.)
3.938

Details

Base Type
Regular Column Base
Connector Finish
G90 Galvanized
Fasteners Included
Fasteners Not Included
Features
No Additional Features
Gauge
7
Material
Steel
Material Connector Compatibility
Wood to Concrete
Number of Pieces
1
Package Quantity
1
Product Weight (lb.)
4.53lb
Returnable
180-Day

Warranty / Certifications

Manufacturer Warranty
Yes

Specifications

Dimensions

Nominal Post Size (in.)
4x4
Product Depth (in.)
3.563
Product Height (in.)
16.688
Product Width (in.)
3.938

Details

Base Type
Regular Column Base
Connector Finish
G90 Galvanized
Fasteners Included
Fasteners Not Included
Features
No Additional Features
Gauge
7
Material
Steel
Material Connector Compatibility
Wood to Concrete
Number of Pieces
1
Package Quantity
1
Product Weight (lb.)
4.53lb
Returnable
180-Day

Warranty / Certifications

Manufacturer Warranty
Yes

Questions & Answers

how deep should the 10"x10" cement pier be to accommodate a 6' or 7' fence?

Asked by: Burly
I am a general contractor and 40 year carpenter. As one stated these wet anchors are not designed for fence posts--a waste of resources. A well anchored fence post is secured in a hole 20 to 24" deep. One can have a ring of concrete at the bottom and again at top with soil in between. There is no need to fill entire hole with concrete. One can also tamp in rocks and soil at bottom and top and use no concrete.
Answered by: James
Date published: 2018-06-25

I want to use two of these these to anchor two seperate posts that are about 11.5 feet apart on c...

I want to use two of these these to anchor two seperate posts that are about 11.5 feet apart on center that will be supporting a 12 foot 3X 2x8 beam that will be used to support four childrens swings; the beam to post connection will be made using 7 gauge Simpson StrongTie ECC4.62-5.50 . Is this going to be ridiculously strong or what?
Asked by: mikey
depends on who is going to use the swing
Answered by: mt
Date published: 2020-07-01

Are these rated for treated lumber

Asked by: Robert
Yes, I have used Home Depot's pressured treated 4 x 4 x 8' with great success. I dug my holes to a depth of 16" - 18", using about 60lb - 70lbs of redi-mix cement.
Answered by: GTA390
Date published: 2019-05-21

Are these galvanized?

Are these galvanized?
Asked by: Bob
Yes they are.
Answered by: yasureyoubetcha
Date published: 2017-08-08
