- Global leader in structural construction products since 1956
- Products designed and tested for strength and easy installation
- Diverse product line trusted by Pros and DIYers alike
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The H2.5A single-sided hurricane tie is designed to resist moderate loads at the rafter/truss-to-top-plate connection. As part of a continuous load path, the H2.5A resists both lateral and uplift loads. The symmetrical design eliminates the need for separate right and left parts.
Highlights
- Embossments in bend line strengthen connection
- The top flange features an arrow line indicator to aid correct installation
- Made from 18-gauge steel
- ZMAX galvanization offers extra corrosion resistance for exterior and treated-wood applications
- Install with (10) 0.131-in x 2-1/2-in nails or (10) #9 x 1-1/2-in Strong-Drive SD screws
- Install with 8d common nails or 9 x 1-1/2 in. strong-drive SD screws
- Shop all Simpson Strong-Tie products
- Return Policy
Product Information
Specifications
Dimensions
Product Depth (in.) | 1.69 in |
|---|---|
Product Length (in.) | 6 in |
Product Width (in.) | 1.69 in |
Details
Color Family | Silver |
|---|---|
Connector Finish | G185 Galvanized |
Connector recommendation | Tie |
Fasteners Included | Fasteners Not Included |
Features | No Additional Features |
Gauge | 18 |
Material | Steel |
Package Quantity | 1 |
Product Weight (lb.) | 0.11 lb |
Returnable | 90-Day |
Strap Type | Hurricane Tie |
Warranty / Certifications
Manufacturer Warranty | Limited Warranty |
|---|
Questions & Answers
Do I need to use two per rafter (one on either side) for pergola application?
Hi Pergola, this is Lexus from Simpson Strong-Tie. We want to ensure we address your question accurately. The number of H2.5AZ’s needed for your specific application can depend on several factors. Please contact the Simpson Strong-Tie Customer Service team at 800-999-5099, and they will assist you further. We look forward to hearing from you!
how many needed per joust
Hi meto, thank you for your message. We want to make sure we address your question. The number of H2.5AZ's needed for your specific application can be dependent upon several things. Please contact the Simpson Strong-Tie Customer Service team at 800-999-5099. We look forward to hearing from you.
Can I use 1.5" #10 pan head wood screws? Or longer?
Hi Rnot51, this is Bekah from Simpson Strong-Tie. The H2.5A uses (5) 0.131 x 2 1/2" nails into the rafter/truss and (5) 0.131 x 2 1/2" nails into the plates for full catalog loads. Additionally we offer loads for using 0.131 x 1 1/2" nails as well or you can use #9 x 1 1/2" StrongDrive SD Screws (SD9112). If you need more information or have additional questions, please contact the Simpson Strong-Tie Customer Service team at 800-999-5099. We look forward to hearing from you.
Can this be used for treated lumber?
Hi Derek, this is Bekah from Simpson Strong-Tie. The H2.5AZ are ZMAX. ZMAX is a medium level of corrosion resistance. The level of corrosion resistance needed for your specific application would be depend upon the the treatment chemicals for your specific lumber. You can utilize the charts on the link below to help determine if medium level is what is needed or if your application might need a high/severe level of corrosion resistance. https://ssttoolbox.widen.net/view/pdf/wow3avewop/C-F-2023-p017-020.pdf?t.download=true If you need more information or have additional questions, please contact the Simpson Strong-Tie Customer Service team at 800-999-5099. We look forward to hearing from you.
Is it likely that my home already has something like these hurricane ties to prevent uplift
Hi crawdad, thank you for your message. It is likely that your home has some uplift connectors though depending on the year built and code requirements locally would impact to what extent there are uplift connectors. This is not something we would be able to say for sure either way for any home/building manufactured. If you need more information or have additional questions, please contact the Simpson Strong-Tie Customer Service team at 800-999-5099. We look forward to hearing from you.
What is the length of the piece? We are building a 4 ft x 8 ft on ground garden 12 inches high. One kit available seems weak, and someone suggested hurricane joints. Will these ties work?
Hi Gardener, this is Colin from Simpson Strong-Tie. The overall height of the H2.5AZ is 6". This tie provides a positive connection between truss/rafter and the wall of a structure, or a deck joist over top of a beam to resist wind and seismic forces. If you need more information or have additional questions, please contact the Simpson Strong-Tie Customer Service team at 800-999-5099. Thank you.
Do you carry this in left and ?
Dawn, this is McKenzie from Simpson Strongtie. The H2.5A is reversible so no need for a left and right. Thanks.
Is an H2.5T different from H2.5A?
Hey Angel, Ricardo here with Simpson. These look the same in appearance, but are different in length, hole pattern, and published load values. Please contact our Technical Support team at (800)999-5099 to discuss further if needs be.
