MP 3 in. x 6 in. 20-Gauge Galvanized Mending Plate

  • Steel construction with rich texture for added grip
  • 20-gauge steel with a galvanized finish for corrosion resistance
  • Mending plate designed for non-structural applications
  • See More Details
78¢

Frequently Bought Together

+
+
Price:
78¢

Product Overview

Simpson Strong-Tie straps and plates join and reinforce joints with simple, versatile solutions for a wide range of connections. Available in many lengths, widths and thicknesses, straps can be used on the wide or narrow face of lumber for light repairs or heavy-duty projects. Many straps are designed to be used back-to-back on a piece of lumber without fastener interference.
  • A versatile and easy-to-use mending plate for wood-to-wood connections
  • Non-structural connectors are ideal for general fix-up work
  • Installs without nails; align wood with arrows at joint and hammer plate to embed prongs
  • Used for non-structural applications only (not for truss applications)
  • 3 in. Width
  • Made from 20-Gauge steel
  • Galvanized for extra corrosion resistance
  • Shop all Simpson Strong-Tie here.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Product Depth (in.)
6
Product Length (in.)
6
Product Width (in.)
3

Details

Builders Hardware Product Type
Mending Plates
Connector Finish
None
Fasteners Included
Fasteners Not Included
Features
No Additional Features
Gauge
20
Material
Steel
Mending Plate Type
Prong Plate
Number of mounting holes
0
Number of Pieces
1
Package Quantity
1
Product Weight (lb.)
0.192
Returnable
180-Day

Warranty / Certifications

Manufacturer Warranty
Limited Warranty

Questions & Answers

9Questions15Answers

I have railroad ties surrounding my fire pit. Will these join the ties so that they wont mkve as much? If not what should i use?

Asked by GG June 11, 2020
1
Answer

The MP Mending Plates are not load rated; it would be up to the Designer to evaluate the suitability of this connector for the specific application. Also, railroad ties can be highly corrosive. The MP Mending Plates have the standard G90 galvanized finish which provides a low level of corrosion resistance. Thank you!

What size nails would be best to use for these?

Asked by Roger May 7, 2020
1
Answer

This product is a versatile and easy-to-use mending plate for wood-to-wood connections. No nails or notching of wood required. For non-structural applications only; not for truss applications. To install, place the plate over two pieces of aligned wood with arrows aligned at joint, place a wood block over the mending plate and hammer the wood block to embed the prongs. Thank you!

I want to join 2 poplar boards to make a wider surface. I want to connect the boards on the un...

Asked by consumer February 11, 2020
1
Answer

The MP Mending Plates are not a load rated product and are for non-structural applications only. It would be up to the Designer to evaluate the suitability of this connector for the specific application. They are versatile and easy-to-use for wood-to-wood connections with no nails or notching of wood required. Thank you!

Can they be used to repair trusses?

Asked by MrK August 22, 2019
2
Answers

That would probably depend on what is broken with your trus and building codes. I have used them to build trusses but in most places that have building codes that would probably not pass. I have used them to build sliding doors as well which I consider to be a more demanding application due to moving all the time(and potential wind damage) where a truss stays still. Your mileage may vary...

I have tried to use to repair broken 1x6 fence boards, and had trouble with attaching one side wi...

Asked by fenceguy June 3, 2019
3
Answers

I have used flat head and truss head screws at 3/4" to attach the mending plate. another way is to use another board big enough to cover the affected area and attach it it the same screws but long up to 1-1/4". Using a drill with a Phillips bit will do it and you would avoid pulling out the other side. Go slow.

Why not for truss construction? Do you have a product that can be? Like the MT20 that is used by truss companys?

Asked by TJ September 4, 2017
2
Answers

No

can these be used to join 2pieces of treated plywood??

Asked by blitzen October 9, 2016
3
Answers

Yes

Do you have 4x8

Asked by Jlong April 19, 2016
1
Answer

The MP36 (3" x 6") is the largest we offer. Thank you!

How to install steel 2 X 4 mending plates into wood?

Asked by Lewis November 24, 2012
1
Answer

Lewis, Place the MP mending plate over two pieces of aligned wood with the arrows aligned at the joint and hammer the plate to embed the prongs. Note: these plates are not load rated and are not intended for truss or structrual applications. Thank you!

Customer Reviews

  • 41 Customer Reviews
  • 4.1 out of 5 stars overall
71% of customers recommended.
Overall Ratings
5star-icon(27)
4star-icon(4)
3star-icon(3)
2star-icon(1)
1star-icon(6)
