The SUR/L are 45-degree skewed hangers designed to support solid sawn and engineered wood products used in wood construction. These U-shaped hangers encapsulate the top flange of the joist, so no web stiffeners are required for standard installation. The SUR and SUL hangers are identical except that they are skewed 45-degrees to the right (SUR) and the left (SUL), respectively.
Dimensions: H 2.56 in, W 4.65 in, D 4.38 in
Joist Hanger Size | 2x6 |
|---|---|
Product Depth (in.) | 4.38 in |
Product Height (in.) | 2.56 in |
Product Width (in.) | 4.65 in |
Connector Finish | G185 Galvanized |
|---|---|
Fasteners Included | Fasteners Not Included |
Features | No Additional Features |
Gauge | 16 |
Hanger Flange Type | Other |
Hanger Modifications | Skewed |
Material | Steel |
Package Quantity | 1 |
Product Weight (lb.) | 0.64 lb |
Returnable | 90-Day |
Manufacturer Warranty | Limited Warranty |
|---|
Hi Benjamin, this is Lexus from Simpson Strong-Tie. Thank you for your inquiry regarding out item SUR26Z. The amount of holes varies with size, the picture you are referring is a SUR24. The SUR26Z does have 3 screw holes per side on the U-shaped hanger. We apologize for the confusion this has caused you. Our team will work with The Home Depot Team to correct this. If you have any additional questions, please do not hesitate to reach out to our Simpson Strong-Tie Customer Service team at 800-999-5099.
Hi, Aaron, this is McKenzie from Simpson Strongtie. The SUR26 is approved with our SD screws (6) SD9112 to the face, and (6) SD9112 to the joist. Thanks.
Hi Thrilldew , this is McKenzie from Simpson Strong-Tie. Please contact The Home Depot's Customer Service at 1-800-466-3337 for further assistance with pricing and quantity. Thanks.
Yes, there is. Those are SUR26Z and SUL26Z.
Hi DesertBob, thank you for your message. This is Ricardo with Simpson Strong-Tie. Please consider the SUL26/SUR26 skewed at 45°. If you need more information or have additional questions, please contact the Simpson Strong-Tie Customer Service team at 800-999-5099. We look forward to hearing from you.
Yes, the SUR210Z can be installed with can be installed with the SD9112. Please see the second table at the following link for allowable loads with the SD screws: https://www.strongtie.com/facemounthangers_engineeredwoodconnectors/sur-sul-hsur-hsul_productgroup_wcc_ijoist/p/sur.sul.hsur.hsul#LoadTables. Thank you!
My setup was more like 37 degrees than 45. I found that it worked best if I only put 2 screws in the header until I had the joist screwed in place, then I added the other screws to the header. It worked well for me.
"Joist hangers are designed to provide support underneath the joist, rafter or beam to provide a strong a connection. SUL/SUR hangers provide a 45° connection between a joist and header. These hangers will normally accommodate a 40° to 50° skew." More than that may compromise the hanger metal strength.
The SUR hangers are skewed at 45 degrees (can generally accomodate 40-50 degree skews). For a 30-35 degree skew, you might consider the LSSU hanger which is field adjustable (maximum 45 degrees). The hanger shown here is a single 2x10 hanger, but the description states double (we are working to get this corrected). If you indeed have a single 2x10, please see the LSSU210, or please see the LSSU210-2 if it is a double 2x10. Thank you!
I don't know exactly which one you are seeing.... I paid over $6 for mine. It seems very expensive, since the straight ones are a little over $1.
Hello Chipp55, Thanks for your question. The price of this item will vary based on your area. To obtain pricing and availability for this item please contact your local Home Depot store. To locate a store near you, please click on the “store locator” found on the top of each page. If you have any additional questions, please contact our Online Customer Service department at 800-430-3376. Thanks!
This price seems way out of line
