3/4 in. Liquidtight NM Straight PVC Conduit Fitting Connector

  • Liquidtight conduit fitting is suitable for Indoor or Outdoor use
  • Simple, easy installation with use of PVC Conduit & Flex Conduit
  • Conduit connector includes steel lock nut and rubber seal gasket
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

Non-metallic liquid tight connectors are made to use with type B Non-metallic liquid tight conduit. There is no threading of conduit or tubing required. Southwire connectors give a superior liquid tight seal and pull out strength.
  • Suitable for indoor or outdoor use
  • Included steel locknut and seal gasket
  • Protects from rain, liquid and oils
  • Simple, quick and easy assembly
  • For use with flexible liquidtight conduit
  • Note: product may vary by store

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Conduit Fittings

3/4 in. Liquid-Tight Coupling3/4 in. Straight Non-Metallic Liquid Tight PVC Fitting3/4 in. 90-Degree Non-Metallic Liquid Tight PVC Fitting
current product
3/4 in. Liquidtight NM Straight PVC Conduit Fitting Connector
Brand CarlonCarlonSouthwire
Name3/4 in. Liquid-Tight Coupling3/4 in. Straight Non-Metallic Liquid Tight PVC Fitting3/4 in. 90-Degree Non-Metallic Liquid Tight PVC Fitting3/4 in. Liquidtight NM Straight PVC Conduit Fitting Connector
Price
$174
$241
$379
Ratings
(12)
(32)
(23)
(3)
Application typeLiquid tightLiquid tightLiquid tightLiquid tight
Fitting typeCouplingConnectorConnectorConnector
Trade Size (in.)3/43/43/43/4
MaterialPVCPVCPVCPVC
Electrical Product TypeStandard FittingStandard FittingStandard FittingConnector
Product Weight (lb.)0.0620.0350.0550.10
View ProductView ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)
2.2
Product Height (in.)
1.7
Product Width (in.)
1.70
Trade Size (in.)
3/4

Details

Application type
Liquid tight
Compatible conduit type
LFNC
Electrical Product Type
Connector
Fitting type
Connector
Material
PVC
Package Quantity
1
Paintable/Stainable
No
Product Weight (lb.)
0.10
Returnable
180-Day

Warranty / Certifications

Certifications and Listings
CSA Certified,UL Listed
Manufacturer Warranty
N/A

Questions & Answers

4Questions4Answers

can these connectors be used under ground?

Asked by rjrc October 21, 2019
1
Answer

Hi rjrc. Thank you for your question. This connection is not rated for underground use. The 3/4 in. x 10 ft. PVC Schedule 40 Conduit is designed to route electrical wire above and below ground and features heat and corrosion resistance for longevity providing all connections are properly sealed. https://www.homedepot.com/p/Weld-On-16-oz-PVC-700-Low-VOC-Cement-in-Clear-10080/202309205 https://www.homedepot.com/p/JM-eagle-3-4-in-x-10-ft-PVC-Schedule-40-Conduit-67454/100129197 Please let us know if we can be of further assistance. Rick_HD_OC

How to install the connector?

Asked by Red May 16, 2017
1
Answer

Unscrew the conncector into two parts. Slide the smaller part (loose sleeve) onto the liquidtite pipe. Firmly push the other part of the connector into the pipe, threads going into the box facing out. Slide the two parts back together and tighten firmly by hand.

Can this be used with 8-4 SOO cable to make a 220 volt extension into a weatherproof 2 gang box??

Asked by JAMES May 4, 2017
1
Answer

It would be an extremely tight fit, but SO cable is a very poor choice and not code in many areas to use in this situation.

$2.41 I see, under specs it shows pack size of 20. So - 20 for 2.41, is this correct?

Asked by Steve March 21, 2017
1
Answer

The $2.41 is the cost for an individual item not the 20 pack.

Customer Reviews

  • 3 Customer Reviews
  • 5 out of 5 stars overall
100% of customers recommended.
Overall Ratings
5star-icon(3)
4star-icon(0)
3star-icon(0)
2star-icon(0)
1star-icon(0)
Sort By:
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
Was this helpful?
0
0
Great product easy to use...
Great product easy to use
Was this helpful?
0
0
Wire very easy to go thru
Wire very easy to go thru
Was this helpful?
0
0
