2222, 2230, 2234, 2246 High-Profile Tile Roof Flashing with Adhesive Underlayment for Curb Mount Skylight

$236.00
Apply Now
Pay $211.00 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Required for VELUX No Leak Skylight installation warranty
  • Engineered to fit VELUX skylights perfectly for easy installation
  • Includes adhesive underlayment for watertight protection
  • View More Details
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy

Product Details

About This Product

VELUX ECW curb mount flashing is designed to work with tiles (over 1/2 in. thickness) and other high-profile roofing materials. The flashing is pliable and pleated, making it easy to form the flashing to the roof tiles. It includes an adhesive underlayment that provides an additional layer of water protection and prevents leaks. When paired with the VELUX No Leak Skylight (models FCM, VCM, VCE, VCS) this flashing makes the skylight eligible for the VELUX 10-year installation warranty.

Highlights

  • ECW flashing is designed for use on roofs with tile or high-profile roofing materials with a minimum pitch of 14° and a maximum pitch of 60°
  • ECW 2246 flashing is designed specifically to fit VELUX curb mounted 2222, 2230, 2234 and 2246 models with an outside curb width of 25-1/2 in. and maximum length of 49-1/2 in.
  • Designed to work in conjunction with a site built curb and the ECW cannot be installed on skylights from other manufacturers or other VELUX skylight models not noted above
  • Curb mounted flashing kits for shingle roofs are available (model ECL)
  • Return Policy
  • California residents
     see Prop 65 WARNINGS

Product Information

Internet # 202892013

Model # ECW 2246 0000C

Specifications

Details

Color Family

Gray

Compatible Roof Type(s)

Tile

Features

No Additional Features

Included

Flashing

Returnable

90-Day

Warranty / Certifications

Manufacturer Warranty

10-year limited

Questions & Answers

206Questions
caret
Q:Does this fit the 22 1/2 window
by|May 18, 2024
1 Answer
Answer This Question

A:  If you have a VELUX FS D06 or FS D26 model skylight...yes, this will fit and is used with a shingle roof. If you have a different skylight part number, please reach out to VELUX directly @ 1-800-888-3589 for guidance on flashing kits.

by|May 21, 2024
    caret
    Q:Is this kit adjustable for different sized skylights?
    by|May 15, 2024
    1 Answer
    Answer This Question

    A:  The metal roof flashing kit is size specific. It will need to be used with a correlated C06 size skylight.

    by|May 15, 2024
      caret
      Q:I have a velux fixed deck mounted window model FS306 measuring 30x 46 to be installed with a new shingles roof. Can you please advise if this is the right flashing system? If not, which one is it? Thanks
      by|Feb 26, 2024
      1 Answer
      Answer This Question

      A:  If you are placing the FS 306 model skylight on your home, you will need the previous generation flashing kit called: EDL 308 0000A. This kit fits FS 302, 304, 306 & 308 models skylights with a shingle roof system.

      by|Feb 27, 2024
        caret
        Q:Are these 3 low e skylights approved by Miami-Dade County?
        by|Feb 17, 2024
        1 Answer
        Answer This Question

        A:  In most cases, you will want to choose a curb mounted skylight with Impact Rated glass for those HVHZ areas. One thing to keep in mind: According to the state of Florida, both Miami-Dade and Broward Counties must also recognize products listed on the Florida Product Approval website. If it is stated that only Miami-Dade NOA listed product are to be used, they must explain their rationale, because Florida allows any product listed on the Florida Product Approval website to be “considered” for possible use anywhere in Florida. There is a caveat: Just because a product is listed on the Florida Product Approval website does not mean it meets the minimum performance requirements in that part of Florida or for the project. Meaning- the skylight or sun tunnel may be HVHZ approved and have a Cycle Pressure rating of +/-50 PSF, but the project spec might require a +/-60 Cycle Pressure rating or might require a stronger design pressure. As with all building products, please check with your local building code official for product acceptance.

        by|Feb 21, 2024
          Showing 1-4 of 206

          Customer Reviews

          4.6 out of 5

          • 4.6 out of 507 reviews
          • 96% recommend this product
          Filter by:
          Showing 1-10 of 507 reviews
          When I picked up the item The box was all beat up, and the skylight itself has stretches on it. I was very disappointed, The way the box was all beat up when I received the item. The skylight will not be installed until June 27 and I’m hoping when I take it completely out of the box the skylight won’t be damaged.
          by
          • Verified Purchase
          My old skylights were leaking, and it was going to rain more. The replacements were handsome and sturdy. There is a ten-year warranty. I am happy!
          by
          • Verified Purchase
          Great Mechanics!
          Great mechanics, made tge job flow smooth!
          by
          • Verified Purchase
          • Recommended
          FLASHING GREAT FOR NEW INSTALL: MODS REQUIRED FOR REPLACEMENT UNITS OR NEW HOLE IN EXISTING ROOFING
          The flashing kit for the deck mounted skylight is comprehensive and fairly straight forward for a new installation on virgin decking (new roof). Based on past experience, it is critical that the adhesive roll flashing tape be adhered all the way up to the rim of the vertical sides of the window (per instructions.) FOR REPLACEMENT SKYLIGHTS ON AN EXISTING ROOF or new units on an existing roof, the flashing kit is not so easy. Existing roofing needs to be taken back away from the roof opening and the existing underlayment/sheathing needs to be scrupulously clean of grit and adhesive etc. We had to modify the application of the adhesive with overlapping layers rather than a single roll up application as designed vs removing a substantial portion of shingles and re-roofing/waterproofing. This would likely void any anticipated warranty on installation, although I'm confident in our application and so far, no leaks through winter storms. Prior skylights failed due to adhesive tape flashing not going all the way up to the rim of the vertical edge, so this is important. (took over 10 years, but it rotted all the way through, allowing seepage in the lower corners. (Not visible until the top metal flashing was removed.) The glass seals remained intact, and otherwise the prior skylights (same size VELUX deck mount) were perfectly fine.
          by
          • Verified Purchase
          • Recommended
          2 found this review helpful
          Looks great and perfect.
          Looks great and perfect.
          by
          • Verified Purchase
          • Recommended
          1 found this review helpful
          I think the second time around it would be easier....
          I think the second time around it would be easier. First time for this DIYer.
          by
          • Verified Purchase
          1 found this review helpful
          Great fit, easy to use and install.
          Great fit, easy to use and install.
          by
          • Verified Purchase
          • Recommended
          1 found this review helpful
          Flashing kit fit my skylight perfectly .
          Flashing kit fit my skylight perfectly .
          by
          • Verified Purchase
          • Recommended
          1 found this review helpful
          this is the flashing kit for the velux skylights .Its a superior product sold only to fit their u...
          this is the flashing kit for the velux skylights .Its a superior product sold only to fit their units! simple to install! best bnb of all using this product you will never have to call your contractor back because of malfunctioning! it keeps the elements out side where they belong and at the same time letting the beautiful light shine in! I highly reccomend this product from the Home Depot store.
          by
          • Verified Purchase
          • Recommended
          2 found this review helpful
          These worked perfect, very easy to install yourself with instructions provided, no leaks.
          These worked perfect, very easy to install yourself with instructions provided, no leaks.
          by
          • Verified Purchase
