3/4 in. Brass PEX-B Barb x 3/4 in. Garden Hose Thread Quarter-Turn Sillcock
- 45° angle greatly reduces hose kinking
- Backed by a 5 year limited warranty
- Robust mounting plate for securing to structure
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The ApolloPEX 3/4 in. Brass PEX Barb x 3/4 in. Garden Hose Thread No-Kink Quarter-Turn Hose Bibb is an easy way to install a new or replacement hose bibb. The valve is designed for potable water and hydronic applications where a shut-off is needed. The ApolloPEX system is a comprehensive piping system comprised of brass fittings, poly alloy fittings, manifolds, valves, fasteners, tools and tubing designed for implementation in water delivery systems, simple or complex.
Highlights
- 45 angle greatly reduces hose kinking
- Constructed of lead free dezincification resistant (DZR) brass for superior reliability and strength
- Quarter-turn ball valve design for simple flow control
- Corrosion resistant to improve longevity
- Listed by IAPMO and design certified and listed to ASSE 1061/NSF 62
- Meets all UPC, IPC, and cUPC requirements
- Maximum working pressure of 200 psi and maximum temperature of 200 degree F
- Can secured in place using copper crimps, stainless steel pinch clamps or stainless steel crimp sleeves
- Compatible with 1/2 in. PEX pipe
- Designed for potable water distribution
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions
Inlet Diameter (In.) | 3/4 |
|---|---|
Outlet Diameter (In.) | 3/4 |
Product Length (in.) | 3.388 in |
Details
Application | Potable Water |
|---|---|
Compatible Pipe Material | PEX |
Connection | Barb |
Features | Corrosion Resistant, Lead Free |
Indoor/Outdoor | Indoor, Outdoor |
Material | Brass |
Maximum Pressure (PSI) | 200 PSI |
Maximum Working Temperature (F) | 200 |
Pack Size | 1 |
Returnable | 90-Day |
Warranty / Certifications
Manufacturer Warranty | 5 Years: Must be installed per published installation instructions. |
|---|
Questions & Answers
Can the black turn valve be rotated 180 ?? It looks like it'll get in the way with what's going on the threads...
Yes, but only 90 degrees.
(2/2) The handle will get in the way if you have a garden hose with a large coupling (or a plastic outer shell) that makes it easier to hand tighten. ie hose SKU 432543 is OK, 1004921552 I'd test out first. I had interference with one similar
(1/2) No, the end stops are postitioned where the thumb lever will stop only at 6 and 9 o'clock. when you turn it around, it will become a 3/4 turn valve, where the ball will be partially open at either end stop that way.
The black valve handle is a quarter-turn. There is enough space between the black valve handle and the male garden hose threads to allow for a female garden hose threaded connection to be made.
What country is this valve made in?
China
This valve is manufactured in China.
Just installed three of these and one is leaking, just a minor drip every couple of seconds. It looks as though there is a hex nut inside that can be tightened, but every Allen wrench I’ve tried is either too big or too small. Anyone know the correct size? Or if I’m wrong altogether about this?
Answering my own question - tightened with an 8mm Allen wrench, no more leaks. Had to buy a new set as my wrenches were all SAE but likely a good addition to my tool bag.
This is a silly question, but does the 1/4 turn allow you to easily regulate flow from the bib?
Yes just less turn
This is a quarter turn ball valve which is best for on-off control. The other type of sill cock is a globe valve which requires multiple full turns for full off to full on and allows better control for flows less than the full open. The issue with globe valves is that they have a rubber washer and rubber packing which fail causing leaks. Ball valves have no rubber parts to fail and last longer.
Yes you can adjust the flow easily.
yes. 1/8 of a turn is about 50% flow.
Yes, the 1/4 turn allows for easy regulation of the water flowing through this fitting.
Is this PEX-A compatible?
Yes, it will work with all PEX. The only difference between PEX A, B, and C is its manufacturing process and flexibility.
This is a PEX-B fitting that may be used with Apollo PEX-A or PEX-B pipe. This fitting must be secured to PEX-A or PEX-B pipe via a crimp ring or pinch clamp. It's not 3/4 in x 3/4 in., but we do sell a 1/2 in. Brass PEX-A Barb x 3/4 in. Garden Hose Thread Quarter-Turn Sillcock. This is Apollo MFG# EPXSCV1234, Store SKU# 1003818603, Store Special Order SKU# 1003224720.
