13 Amp Corded 1-5/8 in. SDS-max Variable Speed Rotary Hammer Drill with Auxiliary Side Handle and Carrying Case

$54900
$599.00
Save $50.00 (8%)
Apply Now
Pay $499.00 after $50 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Chisels, drills and chips through block, tile and tough materials
  • 2 modes: rotary hammer and hammer only for chipping applications
  • Includes: Auxiliary handle and carrying case
  • View More Details
Store
0 in stock
caret

Product Details

The Bosch 11264EVS SDS-max 1-5/8- In. Combination Hammer features a powerful 13.0 Amp motor and has a dual-mode selector for combination versatility - rotary hammer or hammer-only mode. Providing 6.5 Ft.-Lbs. of impact energy, the tool weighs only 15.2 Lbs., for a top performance-to-weight ratio. The hammer has integral clutch that helps to minimize torque reaction. Concrete contractors will appreciate the production in drilling and chiseling applications. The hammer's 12-position Vario-Lock helps to optimize chiseling angles. Bosch's Vibration Control in the hammer mechanism and grip area provide improved user comfort. And with Constant Response circuitry, users benefit from smooth starts and constant load under pressure.
  • Powerful 13.0 Amp motor drives 6.5 Ft.-Lbs. of impact energy for professional results
  • Vibration Control for all day jobs, tool allows for maximum user comfort
  • Constant Response circuitry provides soft-start and maintains constant speed under load
  • Turbo Power - delivers 20 percent more power in hammer-only mode
  • Electro-pneumatic impact system maximizes impact force and minimizes vibration
  • SDS-max bit system tool-free bit changes with automatic bit-locking and maximum impact energy transfer rate
  • Dual-mode selector - Two modes of operation, rotary hammer and hammer only mode
  • Variable-speed dial for accurate bit starting and controlled chipping applications
  • Vario-Lock positioning rotates and locks chisel into 12 different positions to optimize working angle
  • Integral clutch helps minimize torque reaction
  • Includes: (1) SDS-max 1-5/8 In. Combination Hammer, (1) Auxiliary Handle, (1) Grease Tube, (1) Carrying Case






  • Click here to shop for more Bosch Tools
  • Warranty - Limited 1 year
  • Click here for more information on Electronic Recycling Programs
  • Return Policy

Additional Resources

From the Manufacturer

caret

Specifications

caret

Questions & Answers

20Questions
caret
Q:Can this be used yo dig hole for planting trees?
by|May 28, 2023
1 Answer
Answer This Question

A:  The 11264EVS will work in digging, it is the bit that will vary. You may use a clay spade for your application. For further assistance, contact us at 1-877-BOSCH99 (1-877-267-2499) from Mon-Fri 7A-7P CST.

by|May 31, 2023
    caret
    Q:How many hits per minute does this gun do?
    by|Jul 23, 2022
    1 Answer
    Answer This Question

    A:  This 11264EVS Combination Hammer has No Load BPM is 1,700 - 2,900. For further assistance, contact us at 1-877-BOSCH99 (1-877-267-2499) from Mon-Fri 7A-7P CST.

    by|Jul 25, 2022
      caret
      Q:Can this core a 4 inch hole in concrete?
      by|Aug 3, 2021
      1 Answer
      Answer This Question

      A:  This 11264EVS Combination Hammer can use Core Bits. Yes, it accepts 4" bit. Kindly check https://www.boschtools.com/us/en/boschtools-ocs/rotary-hammer-core-bits-2-pc--22581-c/ For further assistance, contact us at 1-877-BOSCH99 (1-877-267-2499) from Mon-Fri 7A-7P CST.

      by|Aug 4, 2021
        caret
        Q:This is good for DIY home projects ??
        by|May 26, 2020
        2 Answers
        Answer This Question

        A:  The 11264EVS Rotary Hammer is designed for concrete or masonry drilling. If your DIY project is based on wood material, I suggest to use a drill/driver instead. For further assistance, contact us at 1-877-BOSCH99 (1-877-267-2499) from Mon-Fri 7A-7P CST.

        by|Oct 17, 2022

          A:  Yes it is very good for home or site projects.

          by|May 17, 2021
          Showing 1-4 of 20
          caret

          Customer Reviews

          4.8 out of 5
          (101)
          • 4.8
            out of 101 reviews
          • 96% recommend this product
          Filter by:
          Showing 1-10 of 101 reviews
          No reverse
          No reverse, so when you get an auger style bit stuck in a hole, you lose a 60 dollar bit. They always get stuck, because a stone in the concrete locks it in. 600 dollar drill is crap. They designed it so you have to keep buying expensive bits.
          by
          Response from BoschToolsJun 30, 2022
          Hi there! The 11264EVS SDS-max Combination Hammer has 2 modes only, which are rotary hammer and hammer-only modes. While there is no reverse you would run the tool when removing bit from the hole. We appreciate your feedback and will pass this along to our product team. If you need additional assistance please contact us to discuss this further at 1-877-267-2499. Thank you.
            I needed to drill a couple of 3 1/2" holes through brick and this coupled with the 3 5/8" core b...
            I needed to drill a couple of 3 1/2" holes through brick and this coupled with the 3 5/8" core bit from Bosch was the perfect duo. I loved the variable speed to soften the blow at the beginning and end to prevent cracks and blow out. I think the drill will be adequate for most every job I will do in the future. I can't wait to pound ground rods and see how it digs holes! Thanks Bosch/ Home Depot
            by
            • Verified Purchase
            • Recommended
            Operates right out of the box .... strong power and last the whole day .... I used mine I a crawl...
            Operates right out of the box .... strong power and last the whole day .... I used mine I a crawl space for 7 hours ... it's well worth it
            by
            • Verified Purchase
            • Recommended
            Used it to remove hardened asphalt from my dump truck....
            Used it to remove hardened asphalt from my dump truck. Absolutely no problem. The thing I noticed the most is I didn't feel any numbness or tingling that I normally get from the vibration from a tool like this.
            by
            • Verified Purchase
            Bad can recommend anyone to buy, use or rent one
            Was the first customer to rent this from my local hardware store. Needed to drill twelve holes 3/4 diameter into 5 inch cement poured 2 weeks prior. Marked rebar when poured. I got through 8 of them before the tool malfunctioned in the worst way. I now own this tool as its new spline bit is stuck in the chuck and the bit is stuck in the hole also. I rented the tool for 8 hours. After 3 days the store reported it stolen. Cops came, showed them the situation they agreed theft did not apply. The suggested i pay for replacment tool so thats what i had to do. Its been stuck there for a year now. So many "experts" have came out saying they can get it out by disassembly of tool but less than 5 minutes in they all say nope cant do it as the chuck is now against floor in a manor mot conducive to bit release. Oh ya and within 1 minute of initially getting stuck i tried reverse and in all speeds but no dice. Tried hammer only and thats how the chuck got down to the cement. We've tried slide hammers pulling back on bit release but again no dice.
            by
            Response from Bosch Customer SupportApr 13, 2023
            We are sorry to hear about the experience you had with the 11264EVS Rotary Hammer. This is not a normal issue. We would recommend that you contact us so that we may further troubleshoot and discus available options. Please call 1-877-BOSCH99 (1-877-267-2499) from 7 a.m. to 7 p.m. CST, Monday through Friday. We hope to hear from you soon. Thank you for your time.
              by
              • Verified Purchase
              by
              • Verified Purchase
              Great power and easy to use....
              Great power and easy to use.
              by
              • Verified Purchase
              Automatic switch
              The worst part of this Hammer is the automatic switch. The automatic switch is by default and very hard to switch back to manually. When digging underground, the automatic function caused the chsel easily stuck into the dirt and took me an hour to remove the chisel out of the dirt is a nightmare.
              by
                • Recommended
                by
                • Verified Purchase
                Showing 1-10 of 101 reviews

                Frequently Bought Together

                Top Rated
                +
                +
                Price:
                $54900
                $599.00
                Save $50.00 (8%)

                Compare Similar Rotary Hammers

                current product
                Top Rated13 Amp Corded 1-5/8 in. SDS-max Variable Speed Rotary Hammer Drill with Auxiliary Side Handle and Carrying Case
                1-3/4 in. SDS MAX Combination Rotary Hammer Kit with Case and Side Handle13.5 Amp 1-3/4 in. Corded Variable Speed SDS-Max Concrete/Masonry Rotary Hammer Drill with Carrying Case15 Amp 2 in. Corded Variable Speed SDS-Max Concrete/Masonry Rotary Hammer Drill with Carrying Case
                BrandBoschDEWALTBoschBosch
                Name13 Amp Corded 1-5/8 in. SDS-max Variable Speed Rotary Hammer Drill with Auxiliary Side Handle and Carrying Case1-3/4 in. SDS MAX Combination Rotary Hammer Kit with Case and Side Handle13.5 Amp 1-3/4 in. Corded Variable Speed SDS-Max Concrete/Masonry Rotary Hammer Drill with Carrying Case15 Amp 2 in. Corded Variable Speed SDS-Max Concrete/Masonry Rotary Hammer Drill with Carrying Case
                Price
                $54900
                $599.00
                Save $50.00 (8%)
                $59900
                $74900
                $112900
                Ratings
                (101)
                (2)
                (38)
                (12)
                Cordless/CordedCordedCordedCordedCorded
                Chuck TypeSDS-MaxSDS-MaxSDS-MaxSDS-Max
                Chuck Size (In.)1-5/8 In.1-3/4 In.3/4 In.2 In.
                IncludedSecond Handle,Tool CaseSecond Handle,Tool CaseTool CaseTool Case
                Power Tool FeaturesVariable SpeedVariable SpeedKeyless Chuck,Variable SpeedVariable Speed
