Internet #304813803

Model #HUI50351UC

Store SKU #1004369736

Store SO SKU #1003282768

500 Series 30 in. Pull-Out Range Hood with Lights in Stainless Steel

  • 300 CFM integrated blower included
  • 3 speed slider control & 2 halogen lights
  • Dishwasher Safe Aluminum Mesh Filters
  • See More Details

Product Overview

Bosch’s inventive ventilation systems keep mealtime fresh by quietly purifying the air while you cook. They’re beautifully designed to seamlessly integrate into any kitchen with under-the cabinet, chimney, island, pull-out and downdraft styles. You’ll breathe easier knowing that smoke, steam, grease and odors are quietly and effectively taken care of.
  • California residents
  • Sleek, integrated pull-out hood allows the user to close the hood when not in use, which provides a flush-look with the surrounding cabinetry
  • Front stainless steel visor panel can be replaced with the user's own custom strip to match surrounding cabinetry (Custom Strip Not Provided)
  • 300 CFM Integrated Blower Included
  • 3 Speed Slider Control
  • 2 Halogen Lights - 12-Volt, 20-Watt Max., G-4 Base
  • Please call your local store with your Order # to schedule installation for this item
  • 6 in. round duct at discharge



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Product Depth (in.)
11
Product Height (in.)
11.56
Product Width (in.)
30
Range Hood Size (Width)
30 in.

Details

Amperage (amps)
15 A
Appliance Type
Range Hood
Color/Finish
Stainless Steel
Color/Finish Family
Stainless Steel
Commercial/Residential
Residential
Control Type
Slide
Features
Dishwasher Safe Metal Mesh Filter,Lighted,Removable Grease Filter(s)
Included
Bulb(s),Damper,Filter(s),Hardware
Light Type
Halogen
Maximum Air Flow Capacity (CFM)
300 CFM
Minimum Air Flow Capacity (CFM)
100
Mounting Type
Insert
Number of Fan Speeds
3
Number of Light Bulbs
2
Product Weight (lb.)
26
Returnable
Non-Returnable
Vent Install Type
Convertible
Vent Material
Other
Voltage (volts)
120
Wattage (watts)
198 W

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
1 Year Limited

Compare Similar Under Cabinet Range Hoods

30 in. Smart Insert Range Hood with Light in Stainless Steel
current product
500 Series 30 in. Pull-Out Range Hood with Lights in Stainless Steel
800 Series 30 in. Undercabinet Range Hood with Lights in Stainless Steel30 in. Convertible Under Cabinet Range Hood in Stainless Steel
BrandGEBoschBoschKitchenAid
Name30 in. Smart Insert Range Hood with Light in Stainless Steel500 Series 30 in. Pull-Out Range Hood with Lights in Stainless Steel800 Series 30 in. Undercabinet Range Hood with Lights in Stainless Steel30 in. Convertible Under Cabinet Range Hood in Stainless Steel
Price
$69200
$769.00
Save $77.00 (10%)
$79900
$99900
$104900
Ratings
(56)
(10)
(8)
(79)
Maximum Air Flow Capacity (CFM)600 CFM300 CFM500 CFM600 CFM
Amperage (amps)2.9 A15 A15 A15
Product Weight (lb.)40263440
Range Hood Size (Width)30 in.30 in.30 in.30 in.
Vent Install TypeDuctedConvertibleConvertibleConvertible
Product Width (in.)28.375303029.88
View ProductView ProductView ProductView Product

Questions & Answers

16Questions12Answers

Will this unit work with a 24” cabinet ?

Asked by Becca March 31, 2019
2
Answers

Hi Becca. Thank you for your question. Here are the dimensions of the 500 Series 24 inch Pull-Oout Range Hood: Overall appliance dimensions (width of canopy included) 11 13/16" H x 23 9/16" W x 11 13/16" D. Required distance above cooktop/range cooking surface: 24" Electric / 30" Gas.

Is the top portion centered to the full width? What is the horizontal distance between the edge o...

Asked by Mel May 6, 2020
2
Answers

You should check the official specifications on Bosch's website (https://www.bosch-home.com/us/productslist/cooking-baking/ventilation/pull-out-hoods/HUI50351UC#/Togglebox=-1637863879/Togglebox=-836809633/Tabs=tab-3324792/). If it's incorrect (which it should not), you can call them out on it.

will both the fan and lights function without having the front fully extend? (I want to run the v...

Asked by Thanh August 12, 2020
1
Answer

Thanh, Thank you for your question and interest in Bosch ventilation. The fan is controlled by slider which is accessible on right under side with front closed. To access the light switch you will have to pull front forward slightly to access the light switch. Turn on the fan - Switching on -Set the slide control to position 1, 2 or 3. / Switching off - Set the slide control to position 0. / Turn on the Lighting - The lighting can be switched on and off independently of the ventilation. - Set the slide control to position 1. Please refer to User Guide which can be found at https://media3.bosch-home.com/Documents/9001096017_E.pdf

Is the pullout portion of the hood glass?

Asked by Sunshine September 22, 2019
1
Answer

Hi Sunshine. Thank you for your question. The pullout portion of the hood is stainless steel.

What is the depth when the hood is pulled out? Does it only turn on when it is pulled out?

Asked by Pru January 10, 2019
1
Answer

Hi Pru. Thank you for your question. The depth of the pull out is 6.89". The visor hood allows the user to close the hood when not in use.

Can i use it under a cabinet thats 18” on top of the stove top

Asked by Hen February 13, 2019
1
Answer

Hi Hen. Thank you for your question. The clearance between the shelf on the cooktop and the bottom of the extractor hood may not be less than 24" in the case of electric cooktops and 25 3/5" in the case of gas or combined ranges. If the installation instructions for the gas cooking appliance specify a larger distance, that distance must be observed.

Is the duct opening from the top or the back ?

Asked by Becca April 22, 2019
1
Answer

Hi Becca. Thank you for your question. The duct opening on the 500 Series Pull-Out Range Hood is on the top.

Is the slide out feature supposed to be smooth? Mine feels like it sticks a little when opening ...

Asked by Nel December 12, 2019
1
Answer

Hi Nel. Thank you for your question. Please contact our Customer Support Team at 1-800-944-2904 regarding your question about your Pull-Out Range Hood, Model #HUI56551UC.

Can the lights be turned on when the hood is not extended? Or do they only come on when the hood ...

Asked by fanfan February 21, 2019
1
Answer

Hi fanfan. Thank you for your question. Per the Use and Care Guide for this model, HUI56551UC: The lighting can be switched on and off independently of the ventilation. Set the slide control to position 1.

How many sones is the unit when run on its highest fan setting?

Asked by SP January 14, 2019
1
Answer

Hi SP. Thank you for your question. At this time Bosch does not have data on sones for this model.

500 Series 30 in. Pull-Out Range Hood with Lights in Stainless Steel - page 2

Customer Reviews

  • 10 Customer Reviews
  • 4.2 out of 5 stars overall
100% of customers recommended.
Overall Ratings
5star-icon(7)
4star-icon(1)
3star-icon(0)
2star-icon(1)
1star-icon(1)
Sort By:
I bought this as a replacement for the discontinued GE...
I bought this as a replacement for the discontinued GE 36" profile (JV960SCBR). One of the only models on the market that is cabinet insert and convertible. The cut-out had to expanded and some additional small modifications was needed during installation, but nothing too difficult for a professional contractor. If you need a cabinet insert replacement, especially if your previous model was discontinued, this is definitely worth checking out. It was the perfect replacement and fit for my situation.
Was this helpful?
1
0
500 Series Pull-Out-Hood
Customer review from bosch-home.com logo
Well designed. [This review was collected as part of a promotion.]
Was this helpful?
0
0
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
Was this helpful?
0
0
bad product...
bad product
Was this helpful?
0
0
It fit well and operates well. The mounting brackets had...
It fit well and operates well. The mounting brackets had to be relocated higher, but the procedure was not in the instruction book. Luckily, there were already holes in the hood for this. The switch that activates the fan and lights when the hood is pulled forward was sluggish at first and did not work some times. I worked with the tension on the mounting brackets and that fixed the issue - needed to tightened more. The fan is slightly noisier than I expected, but on high, it really moves the air. The fitting on top of the hood for the air duct would not stay in place with the duct system attached so I glued it in place with silicon sealant and taped it with aluminum tape. Despite the few installation headaches, we are pleased with the range hood.
Was this helpful?
2
0
Very happy with product. Home Depot intallation damaged cabinet but...
Very happy with product. Home Depot intallation damaged cabinet but product itself is great. Recommend.
Was this helpful?
0
0
Love it!...
Love it!
Was this helpful?
0
0
I installed this Bosch hood myself, and the installation was...
I installed this Bosch hood myself, and the installation was pretty straightforward. My kitchen had 10" rectangular HVAC vent pipe; it was easy to get the transition piece to fit the 6" exhaust for the Bosch. The one glitch I noticed was that the measurements given for cutting out the hole were not correct...to be sure, confirm the actual measurements of the unit before cutting the hole in your cabinetry. Once installed it runs great. We all love the automatic feature where it turns on the fan and lights up when you pull out the extension. The higher powered fan settings capture everything our gas cooktop can throw at it.
Was this helpful?
2
0
Elegant
Customer review from bosch-home.com logo
We have had this style of ventilation hood in our last two homes, and loved them. They perform adequately, are out of the way when not in use, and we love the appearance. They are long-lasting as well. Since acquiring our ceramic cooktop from Bosch, we find our food does not generate as much steam as with our previous cooktop.
Was this helpful?
0
0
CFM
Customer review from bosch-home.com logo
I am a General contractor and more and more of my Clients want more than 300 CFM, I like the idea of the pull out and flush to cabinets [This review was collected as part of a promotion.]
Was this helpful?
0
0
Review this Product
Share your thoughts with other customers
