- For pressure systems where temperatures will not exceed 140°F
- Made of high-tensile and high-impact strength
- Boasts excellent sound deadening qualities
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
PVC schedule 40-pipe and pressure fittings are used in irrigation, underground sprinkler systems, swimming pools, outdoor applications and cold water supply lines. These fittings are highly resilient, with high-tensile and high-impact strength. Intended for pressure use where systems will not exceed 140° F. Conforms to meet Standards: ASTM D 1784, ASTM D 2466, NSF 14 and 61PVC Schedule 40. Has better sound deadening qualities than PVC Schedule 40-DWV Foam Core and ABS Foam Core. Installation requires the use of primer and solvent cement. All Charlotte Pipe products are manufactured in the USA.
Highlights
- White pipe and fittings with red print
- Intended for pressure use
- For use where systems will not exceed 140° F
- PVC schedule 40-pipe and pressure fittings are used in irrigation, underground sprinkler systems, swimming pools, outdoor applications and cold water supply lines
- Conforms to meet Standards: ASTM D 1784, ASTM D 2466, NSF 14 and 61
- Require no special tools for cutting and to be installed with solvent cement
- +/-2.06" ID and 2.37" OD
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions: H 2.625 in, W 2.75 in, L 2.750 in
Dimensions
Double Fitting Size | 2" x 2" |
|---|---|
Fitting 1 size | 2" |
Fitting 2 size | 2" |
Fitting Size Dimensions | 2" x 2" |
Product Height (in.) | 2.625 in |
Product Length (ft.) | 2.75 ft |
Product Length (in.) | 2.750 in |
Product Width (in.) | 2.75 in |
Single Fitting Size | 2" |
Details
Application | Non-Potable Water |
|---|---|
Color Family | White |
Compatible Pipe Material | PVC |
Connection | Hub x Socket |
Connection 1 | Hub |
Connection 2 | Socket |
Connectivity | Solvent Cemented |
DWV | Pressure |
Features | Underground Rated |
Fitting or Connector Type | Adapter |
Fitting/ Connector Collection | PVC |
Material | PVC |
Maximum working pressure (psi) | 280 |
Maximum Working Temperature (F) | 140 |
Pack Size | 1 |
Pipe or Fitting Product Type | Fittings & Connectors |
Product Weight (lb.) | 0.228 lb |
Returnable | 90-Day |
Schedule Type | Schedule 40 |
Warranty / Certifications
Manufacturer Warranty | Charlotte Pipe and Foundry Company (Charlotte Pipe) Products are warranted to be free from manufacturing defects and to conform to currently applicable ASTM standards for a period of five (5) years from date of delivery |
|---|
Questions & Answers
Will it work with intex pool hoses
Intex Pool hoses are a flexible piping system and our products are not designed to be used with them so we can not guarantee our PVC adapters will function properly. Thank you!
Will this work on a sewage injector pump with a 2 in discharge
PVC products are commonly used for discharge lines, but the answer to your question will depend on the specifics of the sewage injector pump’s 2” threaded connection and operating pressure. PVC 02109 1600HD, Store SKU # 610364, pressure rating is 140 PSI. Recommend contacting the sewage pump manufacturer to ensure the appropriate connection. For additional information and/or a recommendation, please contact our Technical Services Department at 800-438-6091.
Can the MPT connect to a 1/2" FIP supply line?
It would not be recommended to directly connect this PVC fitting to a Female Iron Pipe supply line without a transition. For a better explanation and/or a recommendation on your specific project, please contact our Technical Services Department at 800-438-6091.
2 in. PVC Schedule 40 MPT x S Male Adapter. Connection 1 Hub ( is this MPT?) Connection 2 Socket ( is this S Mail?) MPT is a male threaded, S means what?
For PVC 02109 1600HD, SKU # 610364, one connection is a Male NPT thread, and the other is a Socket. For additional information and/or a recommendation, please contact our Technical Services Department at 800-438-6091.
Can this be used for potable water
PVC SCH 40 and 80 pressure systems manufactured by Charlotte Pipe meet the requirements of NSF61 for drinking water. However, PVC cannot be used within the walls of a building for potable water distribution. It can be used from the city main or well to the building, but must transition to PEX, Copper, or CPVC.
Will this connect to a garden hose on the 3/4in FPT side? & slide over the 1 in pipe side? Why is it so hard to get a straight / clear answer? Thnx. I've cut out my sprinkler back flow but want to posb use with garden hose to supply water to system. Thnx.
Charlotte Pipe does not offer a "hose adapter" fitting. Please check with your local store, someone in the plumbing aisle should be able to direct you to a "Lasco" fitting that will work. For more information or a recommendation from Charlotte Pipe please contact our Technical Services Department at 800-438-6091.
No, this will not connect to garden hose. Hose is 3/4 but the threads are different from NPT. Don't ask me why but they are.
Will this thread fit a sump pump?
This fitting is designed to be used in a plumbing application. There is a good chance that this fitting will work with your system but you've not provided enough information for us to give a qualified answer. For a recommendation from Charlotte Pipe please contact our Technical Services Department at 800-438-6091.
Yes it will, As long as your sump pump has a 2" discharge.
Why is this fitting grouped with slip fittings? In the web site, clicking on the various sizes shows all MPT x slip, except for this one! Why would an MPT x FPT be grouped with MPT x slip? Shouldn't the product Internet #203811636 Model # PVC021090600HD Store SKU #188123 UPC 611942038336 show up when I click the "1/2" size button?
we will bring this to Home Depot's attention. Thank you for alerting us to this issue.
