BR 1-15 Amp 2 Pole and 1-20 Amp 2 Pole BQC (Common Trip) Quad Circuit Breaker

$3100
Apply Now
Pay $6.00 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Ideal for use in type BR load centers
  • Offers protection to wires from overheating and fault currents
  • Features rejection tab and a common trip for convenience
Store
0 in stock
Text to Me
caret

Product Details

Circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). The Eaton Cutler-Hammer Quadplex or Quad type Circuit Breaker is designed to create (4) circuits in (2) spaces. This allows for 240-Volt circuits. The BQC style breaker has a common trip as well as a rejection tab feature. These breakers are designed for use in BR type load centers and should be installed only in panel positions that have notched bus stabs that accommodate the rejection clip. Also, BQC circuit breakers are UL approved genuine replacement breakers for load centers made by Westinghouse, Challenger, and Bryant.
  • Primary function of a circuit breaker is to protect the wire from overheating (overload) and fault currents (short circuit)
  • Amperage - (2) 2 pole 15 Amp and (2) 1 pole 20 Amp
  • Number of poles - 4
  • Trip type - common
  • For use in type BR load centers
  • Interrupt rating - 10 kAIC
  • Voltage rating is 120/240V
  • Wire size - #14-4 AWG Cu/Al at 60°C or 75°C
  • Carry listing for HACR applications
  • Breaker has a rejection tab feature



  • Return Policy

Additional Resources

From the Manufacturer

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.
caret

Specifications

caret

Questions & Answers

2Questions
caret
Q:The April 2019 Eaton catalog page V1-T1-89 says BQC215220 has 1 2 pole common trip 15 amp and 1 2...
by|Feb 5, 2020
1 Answer
Answer This Question

A:  Hello Kea, the BQC215220 is a 4 circuit breaker that fits in a 2-pole breaker. The outer two circuits are a 15 amp common trip and the center two circuits are a 20 amp common trip. If you have any further questions we recommend calling into our technical support team at 877-386-2273, Opt 2, Opt 2. Regards, Eaton

by|Apr 19, 2020
    1 found this answer helpful
    caret
    Q:why doesn't the breaker in the image correspond to the description. the image shows a breaker wi...
    by|Sep 7, 2017
    1 Answer
    Answer This Question

    A:  Hello Kevin, Thank you for your question. The image is correct. The quad contains (2) Single-Pole 20A, (2) Two-Pole 15A. Regards, Eaton

    by|Feb 21, 2021
      Showing 1-2 of 2
      caret

      Customer Reviews

      3 out of 5
      (2)
      • 3
        out of 2 reviews
      • 0%recommend this product
      Filter by:
      Showing 1-2 of 2 reviews
      by
      • Verified Purchase
      Tried 2 different breakers and both had exactly the same...
      Tried 2 different breakers and both had exactly the same problem; 15A switches (outside) do not stay in On position I just gave up and bought and installed regular 20A double. Fortunately I didn’t have to use a separate breaker for surge protection device in electric panel.
      by
      • Verified Purchase
      Showing 1-2 of 2 reviews
