BR 2-15 Amp Single Pole Tandem Non-CTL Circuit Breaker

  • Allows two circuit to be fed from a single space in a loadcenter
  • All 15 and 20 Amp single poles are switch-duty rated
  • Fits notched and non-notched stabs on circuit-limiting panels
$ 16 94
Buy 5 or more  $15.25
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Allows two circuit to be fed from a single space in a loadcenter
  • All 15 and 20 Amp single poles are switch-duty rated
  • Fits notched and non-notched stabs on circuit-limiting panels
Circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). The Eaton Cutler-Hammer 15/15 Amp 1 in. Duplex Type BR Circuit Breaker is also known as tandem breaker. Tandem breakers are convenient for adding circuits to a full load center and are sometimes used to reduce the physical size of the load center. This a non-circuit limiting breaker. The BR tandem line of breakers is intended for replacement purposes on load centers made prior to 1968.
  • Primary function of a circuit breaker is to protect the wire from overheating (overload) and fault currents (short circuit)
  • Amperage - (2) 15 Amp
  • 1 in. plug-on circuit breaker
  • Trips to center position - must turn off then turn back on
  • For use in type BR load centers
  • Interrupt rating - 10 kAIC
  • Voltage rating is 120/240-Volt
  • Wire size - #14-4 AWG Cu/Al at 60°C or 75°C
  • BR duplex circuit breakers are a replacement breaker for enclosures manufactured prior to 1968 with un-notched stabs
  • Learn More About Circuit Breakers Here in our Buying Guide.



Product Overview

  • Allows two circuit to be fed from a single space in a loadcenter
  • All 15 and 20 Amp single poles are switch-duty rated
  • Fits notched and non-notched stabs on circuit-limiting panels
Model #: BR1515
Sku #: 296666
Internet #: 100121768

Circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). The Eaton Cutler-Hammer 15/15 Amp 1 in. Duplex Type BR Circuit Breaker is also known as tandem breaker. Tandem breakers are convenient for adding circuits to a full load center and are sometimes used to reduce the physical size of the load center. This a non-circuit limiting breaker. The BR tandem line of breakers is intended for replacement purposes on load centers made prior to 1968.

  • Primary function of a circuit breaker is to protect the wire from overheating (overload) and fault currents (short circuit)
  • Amperage - (2) 15 Amp
  • 1 in. plug-on circuit breaker
  • Trips to center position - must turn off then turn back on
  • For use in type BR load centers
  • Interrupt rating - 10 kAIC
  • Voltage rating is 120/240-Volt
  • Wire size - #14-4 AWG Cu/Al at 60°C or 75°C
  • BR duplex circuit breakers are a replacement breaker for enclosures manufactured prior to 1968 with un-notched stabs
  • Learn More About Circuit Breakers Here in our Buying Guide.



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
  • Allows two circuit to be fed from a single space in a loadcenter
  • All 15 and 20 Amp single poles are switch-duty rated
  • Fits notched and non-notched stabs on circuit-limiting panels
Circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). The Eaton Cutler-Hammer 15/15 Amp 1 in. Duplex Type BR Circuit Breaker is also known as tandem breaker. Tandem breakers are convenient for adding circuits to a full load center and are sometimes used to reduce the physical size of the load center. This a non-circuit limiting breaker. The BR tandem line of breakers is intended for replacement purposes on load centers made prior to 1968.
  • Primary function of a circuit breaker is to protect the wire from overheating (overload) and fault currents (short circuit)
  • Amperage - (2) 15 Amp
  • 1 in. plug-on circuit breaker
  • Trips to center position - must turn off then turn back on
  • For use in type BR load centers
  • Interrupt rating - 10 kAIC
  • Voltage rating is 120/240-Volt
  • Wire size - #14-4 AWG Cu/Al at 60°C or 75°C
  • BR duplex circuit breakers are a replacement breaker for enclosures manufactured prior to 1968 with un-notched stabs
  • Learn More About Circuit Breakers Here in our Buying Guide.



Product Overview

  • Allows two circuit to be fed from a single space in a loadcenter
  • All 15 and 20 Amp single poles are switch-duty rated
  • Fits notched and non-notched stabs on circuit-limiting panels
Model #: BR1515
Sku #: 296666
Internet #: 100121768

Circuit breakers protect the wires in your home from overheating (referred to as an overload) and fault currents (referred to as short circuits). The Eaton Cutler-Hammer 15/15 Amp 1 in. Duplex Type BR Circuit Breaker is also known as tandem breaker. Tandem breakers are convenient for adding circuits to a full load center and are sometimes used to reduce the physical size of the load center. This a non-circuit limiting breaker. The BR tandem line of breakers is intended for replacement purposes on load centers made prior to 1968.

  • Primary function of a circuit breaker is to protect the wire from overheating (overload) and fault currents (short circuit)
  • Amperage - (2) 15 Amp
  • 1 in. plug-on circuit breaker
  • Trips to center position - must turn off then turn back on
  • For use in type BR load centers
  • Interrupt rating - 10 kAIC
  • Voltage rating is 120/240-Volt
  • Wire size - #14-4 AWG Cu/Al at 60°C or 75°C
  • BR duplex circuit breakers are a replacement breaker for enclosures manufactured prior to 1968 with un-notched stabs
  • Learn More About Circuit Breakers Here in our Buying Guide.



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand Eaton Eaton Eaton Eaton
Name BD 2-20 Amp Single Pole Tandem CTL Circuit Breaker BR 1-15 Amp Single Pole and 1-20 Amp Single Pole Tandem Non-CTL Circuit Breaker BR 2-15 Amp Single Pole Tandem Non-CTL Circuit Breaker CH 2-15 Amp 1-Pole Tandem Circuit Breaker
Price
$9.98
$15.02
$16.94
$19.98
Ratings (38) (9) (22) (13)
Product Width (in.) 0.98 0.98 0.98 0.73
Maximum Amperage (amps) 20 20 15 15
Power Distribution Features No Additional Features No Additional Features No Additional Features No Additional Features
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
2.89
Product Height (in.)
3.1
Product Width (in.)
0.98

Details

Breaker Type
Tandem
Electrical Product Type
Breaker
Interruption Type
Standard Trip
Maximum Amperage (amps)
15
Mounting type
Plug In
Number of Poles
2
Power Distribution Features
No Additional Features
Product Weight (lb.)
0.37lb
Returnable
90-Day
Voltage (volts)
120/240

Warranty / Certifications

Certifications and Listings
1-UL Listed,ANSI Certified,CSA Certified
Manufacturer Warranty
10 Years

Specifications

Dimensions

Product Depth (in.)
2.89
Product Height (in.)
3.1
Product Width (in.)
0.98

Details

Breaker Type
Tandem
Electrical Product Type
Breaker
Interruption Type
Standard Trip
Maximum Amperage (amps)
15
Mounting type
Plug In
Number of Poles
2
Power Distribution Features
No Additional Features
Product Weight (lb.)
0.37lb
Returnable
90-Day
Voltage (volts)
120/240

Warranty / Certifications

Certifications and Listings
1-UL Listed,ANSI Certified,CSA Certified
Manufacturer Warranty
10 Years
