Internet #206109781

Model # GFTCB120CS

Store SKU #301545

Eaton BR 20 Amp Single Pole Self Test Ground Fault Circuit Breaker
Share
save to favorites Save to Favorites
print Print
0786680134128

Eaton

BR 20 Amp Single Pole Self Test Ground Fault Circuit Breaker

$ 38 23
Loading Options
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

+
+

Product Overview

Eaton's BR ground fault current interrupters (GFCIs) are 1 in. wide and provide superior safety over a standard electrical outlet in areas where electricity may come into contact with water. GFCIs are required in any application near water such as kitchen countertops, bathrooms, swimming pools, hot tubs, and outdoor receptacles. They immediately break the circuit when electrical current leakage is detected, reducing the risk of shock and electrocution. This circuit breaker periodically runs a self-test diagnostic and complies UL 943, Fourth Edition.

Product Overview

Model #: GFTCB120CS
Sku #: 301545
Internet #: 206109781

Eaton's BR ground fault current interrupters (GFCIs) are 1 in. wide and provide superior safety over a standard electrical outlet in areas where electricity may come into contact with water. GFCIs are required in any application near water such as kitchen countertops, bathrooms, swimming pools, hot tubs, and outdoor receptacles. They immediately break the circuit when electrical current leakage is detected, reducing the risk of shock and electrocution. This circuit breaker periodically runs a self-test diagnostic and complies UL 943, Fourth Edition.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Info & Guides

Compare Similar

Compare Similar Products
Brand Eaton Eaton Eaton Eaton
Name BR 20 Amp Single Pole Self Test Ground Fault Circuit Breaker BR 20 Amp Single-Pole Combination Arc Fault Circuit Breaker BR 15 Amp Single-Pole Combination Arc Fault Circuit Breaker CH 20 Amp 1-Pole Self Test Ground Fault Circuit Breaker with Trip Flag
Price
$38.23
$44.97
$44.97
$53.95
Ratings (17) (24) (19) (6)
Interruption Type GFCI CAFCI AFCI GFCI
Product Width (in.) 7.3 4.0 4.0 3.25
Mounting type Plug In Plug In Plug In Plug In
Maximum Amperage (amps) 20 20 15 20
Power Distribution Features Trip Indicator No Additional Features No Additional Features Trip Indicator
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
.6
Product Height (in.)
9.3
Product Width (in.)
7.3

Details

Breaker Type
Single Pole
Electrical Product Type
Breaker
Interruption Type
GFCI
Maximum Amperage (amps)
20
Mounting type
Plug In
Number of Poles
1
Pack Size
1
Power Distribution Features
Trip Indicator
Product Weight (lb.)
1lb
Returnable
90-Day
Voltage (volts)
120/240

Warranty / Certifications

Certifications and Listings
1-UL Listed,ANSI Certified,CSA Listed
Manufacturer Warranty
10 Years

Specifications

Dimensions

Product Depth (in.)
.6
Product Height (in.)
9.3
Product Width (in.)
7.3

Details

Breaker Type
Single Pole
Electrical Product Type
Breaker
Interruption Type
GFCI
Maximum Amperage (amps)
20
Mounting type
Plug In
Number of Poles
1
Pack Size
1
Power Distribution Features
Trip Indicator
Product Weight (lb.)
1lb
Returnable
90-Day
Voltage (volts)
120/240

Warranty / Certifications

Certifications and Listings
1-UL Listed,ANSI Certified,CSA Listed
Manufacturer Warranty
10 Years

Questions & Answers

Will these breakers fit in a cutler hammer load center

Asked by: Scott
EATON bought Cutler-Hammer. There are same breakers.
Answered by: LITCO
Date published: 2018-10-04

Is there a way to determine whether a trip on this breaker is due to a ground-fault or over-curre...

Is there a way to determine whether a trip on this breaker is due to a ground-fault or over-current condition?
Asked by: dewhite04
Answering my own question here. As others have said, there is no way to tell a ground-fault from an over-current trip. In either case the charging handle snaps to center to indicate a fault. In my case, I replaced with a standard 20a breaker and installed a GFCI outlet into the circuit upstream from all connected loads. I figured this would sort out which was causing my nuisance trips. Instead, it has eliminated the nuisance trips. Not a good look for the reliability of this breaker which was installed only several months ago...
Answered by: dewhite04
Date published: 2018-10-25

will this breaker fit into a cutler hammer panel ?

Asked by: rich
It depends...if your panel requires CH breakers then no. If your panel requires BR breakers then yes. Both are Cuttler & Hammer panels but are different styles. Just look at the breakers currently installed in your panel and they will either indicate CH or BR on them. Also, typical CH breakers are only 3/4" wide for a single pole breaker and BR breakers are 1" wide for a single pole breaker. Of course, 240V two pole breakers require two slots and are twice the width of the single pole breaker of either configuration (CH or BR). Hope that helps someone along the way...
Answered by: jasanford
Date published: 2019-02-20

Does this accept a 12 gauge wire? The other Eaton non-GFCI outlets @20amps all specify 14 gauge w...

Does this accept a 12 gauge wire? The other Eaton non-GFCI outlets @20amps all specify 14 gauge wire only. I would prefer to use 12 gauge for a 20 amp circuit.
Asked by: Joe
Per Eaton's Residential and Light Commercial Products Catalog (Vol. 1) - this breaker is listed for use with between #14 and #4 wire. Without knowing the exact other breaker you are referring to, I imagine that what you saw was the minimum size listed (#14) for use with that breaker, not the only size listed.
Answered by: dewhite04
Date published: 2018-10-25
  • y_2019, m_6, d_17, h_18CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_6
  • loc_, sid_206109781, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 48ms
  • QUESTIONS, PRODUCT

Customer Reviews

BR 20 Amp Single Pole Self Test Ground Fault Circuit Breaker is rated 4.6 out of 5 by 17.
Rated 5 out of 5 by from Just what I needed. The Eaton GFCI breaker fit the panel perfectly. (Apparently Eaton bought Brya... Just what I needed. The Eaton GFCI breaker fit the panel perfectly. (Apparently Eaton bought Bryant & Square D and continue to manufacture.)
Date published: 2019-06-11
Rated 5 out of 5 by from Performed very well, completes the job it was designed to... Performed very well, completes the job it was designed to do.
Date published: 2019-06-05
Rated 4 out of 5 by from Fit and worked great.... Fit and worked great.
Date published: 2019-03-19
Rated 4 out of 5 by from It was able to fix the electrical issue... It was able to fix the electrical issue
Date published: 2019-02-26
Rated 4 out of 5 by from 4 Star Review Rating provided by a verified purchaser
Date published: 2019-02-27
Rated 5 out of 5 by from Did the job, fit right.... Did the job, fit right.
Date published: 2019-02-21
Rated 3 out of 5 by from This breaker was installed at my home last year to protect a circuit with several outdoor applian... This breaker was installed at my home last year to protect a circuit with several outdoor appliances (irrigation controller, outdoor lighting transformer, and sump pump). Over the past few weeks I started to get nuisance trips every 1-3 days. As it turns out, there is no way to tell a ground-fault from an over-current trip. In either case the charging handle snaps to center to indicate a fault. In order to troubleshoot this problem, I replaced with a standard 20a breaker and installed a GFCI outlet into the circuit upstream from all connected loads. I figured this would sort out which was causing my nuisance trips. Instead, it has eliminated the nuisance trips completely. Not a good look for the reliability of this breaker which was installed only several months ago...
Date published: 2018-10-25
Rated 5 out of 5 by from Bought to replace the same breaker damaged by rain that... Bought to replace the same breaker damaged by rain that found its way inside the panel. Very easy to install. A little overpriced but all GFCI breakers are overpriced.
Date published: 2018-10-31
