Internet #304736110

Model #TLM1212CCUGK

Store SKU #1003102331

Store SO SKU #1003066617

125 Amp 14-Space 24-Circuit Main Lug Indoor Load Center Contractor Kit

  • Indoor NEMA 1 enclosure (combination surface/flush)
  • Main lugs are factory installed; convertible to main breaker
  • Includes 4 select circuit breakers
  • See More Details

Frequently Bought Together

+
+
Price:
$5060

Product Overview

The GE 125 Amp 14-Space 24-Circuit Main Lug Indoor Load Center Contractor Kit is pre-packaged with a selection of circuit breakers and ground bar. The UL-listed load center has holes rated 100% split neutral on each side that are compatible with #14-4 wire. The breaker box is a single-phase, 3-wire unit with a factory-installed main breaker. The center is designed and built for faster installation and a more dependable performance. This unit is compatible with GFCIs, AFCIs, Dual Function and standard circuit breakers.
  • Features a copper bus for increased conductivity
  • Galvanized box for rust resistance with a self-adjusting dead-front cover
  • Features full-length neutral bars for faster and easier wiring
  • Kit includes 3 THQP120 20 Amp single-pole circuit breakers, 1 THQP230 30 Amp double-pole circuit breaker and ground bar

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Subpanel Kits

current product
125 Amp 14-Space 24-Circuit Main Lug Indoor Load Center Contractor Kit
PowerMark Gold 125 Amp 24-Space 24-Circuit Indoor Main Lug Value Kit Includes Select Circuit BreakerHomeline 225 Amp 30-Space 60-Circuit Indoor Main Lug Plug-On Neutral Load Center with Cover, Ground Bar - Value PackPowerMark Gold 125 Amp 14-Space 24-Circuit Indoor Main Lug Value Kit Includes Select Circuit Breaker
BrandGEGESquare DGE
Name125 Amp 14-Space 24-Circuit Main Lug Indoor Load Center Contractor KitPowerMark Gold 125 Amp 24-Space 24-Circuit Indoor Main Lug Value Kit Includes Select Circuit BreakerHomeline 225 Amp 30-Space 60-Circuit Indoor Main Lug Plug-On Neutral Load Center with Cover, Ground Bar - Value PackPowerMark Gold 125 Amp 14-Space 24-Circuit Indoor Main Lug Value Kit Includes Select Circuit Breaker
Price
$5060
$6893
$8597
$8961
Ratings
(49)
(53)
(86)
(9)
Number of Spaces14243014
Maximum Amperage (amps)125125225125
Mounting TypePlug-OnPlug-OnPlug-On NeutralPlug-On
Voltage (volts)240240120/240240
Number of Circuits24246024
Load center width (in.)14.3814.3814.2514.38
Indoor/OutdoorIndoorIndoorIndoorIndoor
Electrical Product TypeMain Lug/ Main Lug KitMain Lug/ Main Lug KitMain Lug/ Main Lug KitMain Lug/ Main Lug Kit
View ProductView ProductView ProductView Product

Specifications

Dimensions

Load center depth (in.)
3.31
Load center height (in.)
16.11
Load center width (in.)
14.38

Details

Electrical Product Type
Main Lug/ Main Lug Kit
Indoor/Outdoor
Indoor
Load Center Mounting Type
Flush,Surface
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting Type
Plug-On
Number of Circuits
24
Number of Spaces
14
Phase Type
1 Phase
Returnable
180-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

12Questions13Answers

Can this load center be rotated and installed with an underground feed?

Asked by WMR February 16, 2021
1
Answer

Thank you for your question. The TLM2020CCUGK can be rotated and allow bottom feed.

How çan I order this product? Neither the 23 or 59th Street store has it in stock. What can we do?

Asked by LW July 31, 2020
1
Answer

This item can be purchased via homedepot.com and shipped to either a store near you or directly to your home.

Can this be used as a subpanel?

Asked by Denversharp October 31, 2019
1
Answer

Absolutely it can. This panel is rated up to 200 amps.

Will this panel take single pole 1 inch breakers? And double pole 1 inch breakers?

Asked by thomas September 24, 2019
1
Answer

Thomas, Yes this panel takes either. It will take up to 14 single space 1" 1 pole breakers (Type THQL eg THQL1120). You would just deduct 1 space per 1" double pole breaker (Type THQP eg THQP250 max 12) or 2 spaces per full size double pole breakers (type THQL eg THQL2150). Thanks JE

Is there a hold-down kit so I can use a breaker as a back-fed main?

Asked by Nick August 31, 2019
1
Answer

Pete, Absolutely there is. The Home Depot sku is 585416 ( GE part # THQLRK3CP). Thanks JE

What's the maximum size wire the main lugs accept?

Asked by Nick August 30, 2019
1
Answer

Thank you for your question. The wire range for the TLM4020C80K lugs is 6awg - 250kcmil.

Can a 125 amp main breaker be installed, it appears to be a convertible panel.

Asked by Wahoo April 9, 2019
2
Answers

Yes

Does this have Main lug or main breaker?

Asked by Sparky March 6, 2019
1
Answer

Thank you for your question. The TLM4020C80GK is a main lug. It is convertible to a main breaker with the THQMV200DP kit. We will correct the mistake in the product overview. Thank you for informing us.

Can i install this box upside down?

Asked by Cuper January 17, 2019
2
Answers

Yes you could

Can this be used as a sub panel because I don’t need a breaker?

Asked by Bobo December 25, 2018
2
Answers

Yes
