Internet #301157584

Model #TM2020RCUBK1

Store SKU #1002340450

200 Amp 20-Space 40-Circuit Main Breaker Outdoor Load Center Contractor Kit

  • Outdoor NEMA 3R Enclosure
  • Main Breaker is Factory Installed
  • Includes 4 select Circuit Breakers
  • See More Details

Frequently Bought Together

+
+
Price:
$12617

Product Overview

The GE 200 Amp 20-Space 40-Circuit Main Breaker Outdoor Load Center Contractor Kit is pre-packaged with a selection of circuit breakers. The UL-listed load center has holes rated 100% split neutral on each side that are compatible with #14-4 wire. The breaker box is a single-phase, 3-wire unit with a factory-installed main breaker. The center is designed and built for faster installation and a more dependable performance. This unit is compatible with DFs, GFCIs, AFCIs and standard circuit breakers.
  • Features a copper bus for increased conductivity
  • Galvanized box for rust resistance with a self-adjusting dead-front cover
  • Features full-length neutral bars for faster and easier wiring
  • Kit includes 3 THQP120 20 Amp single-pole circuit breakers and 1 THQP230 30 Amp double-pole circuit breaker
  • Closure caps included, hubs ordered separately
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Main Breaker Box Kits

200 Amp 20-Space 40-Circuit Main Breaker Indoor Load Center Contractor Kit
current product
200 Amp 20-Space 40-Circuit Main Breaker Outdoor Load Center Contractor Kit
PowerMark Gold 200 Amp 20-Space 20-Circuit Indoor Main Breaker Value Kit Includes Select Circuit BreakerHomeline 200 Amp 40-Space 80-Circuit Indoor Main Breaker Qwik-Grip Plug-On Neutral Load Center with Cover - Value Pack
BrandGEGEGESquare D
Name200 Amp 20-Space 40-Circuit Main Breaker Indoor Load Center Contractor Kit200 Amp 20-Space 40-Circuit Main Breaker Outdoor Load Center Contractor KitPowerMark Gold 200 Amp 20-Space 20-Circuit Indoor Main Breaker Value Kit Includes Select Circuit BreakerHomeline 200 Amp 40-Space 80-Circuit Indoor Main Breaker Qwik-Grip Plug-On Neutral Load Center with Cover - Value Pack
Price
$10853
$12617
$14512
$15121
Ratings
(147)
(67)
(82)
(202)
Indoor/OutdoorIndoorOutdoorIndoorIndoor
Number of Spaces20202040
Number of Circuits40404080
Maximum Amperage (amps)200200200200
Mounting TypePlug-OnPlug-OnPlug-OnPlug-On Neutral
Load center height (in.)26.563326.5639.37
Load center depth (in.)3.7553.753.75
Load center width (in.)14.381314.3814.25
Electrical Product TypeLoad Center and Breaker KitLoad Center and Breaker KitLoad Center and Breaker KitLoad Center and Breaker Kit
View ProductView ProductView ProductView Product

Specifications

Dimensions

Load center depth (in.)
5
Load center height (in.)
33
Load center width (in.)
13

Details

Electrical Product Type
Load Center and Breaker Kit
Indoor/Outdoor
Outdoor
Load Center Mounting Type
Surface
Load Center Type
Main Breaker
Maximum Amperage (amps)
200
Mounting Type
Plug-On
Number of Circuits
40
Number of Spaces
20
Phase Type
1 Phase
Product Weight (lb.)
32
Returnable
180-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

19Questions14Answers

Does this kit come with the 4 breakers shown?

Asked by Troll February 18, 2019
4
Answers

Yes but 3 of the 4 circuit breakers did not function. I had to replace them.

WILL a GE Q-Line 40 Amp 1 in. Double Pole Circuit Breaker Model# THQP240 FUNCTION PROPERLY IN THE...

Asked by ED1 August 8, 2020
2
Answers

Absolutely

is this a feed though panel?

Asked by joe June 18, 2020
1
Answer

Thank you for your question. The TM1212RCUBK1 is not a feed through panel.

Does it have feed through lugs

Asked by Kenny August 20, 2019
1
Answer

Thank you for your question. The TM3220R64K does not include feed through lugs. Please consider the TM820RCUFLP which does include feed through lugs.

How many 2 pole breakers can you install in this box?

Asked by Bk January 7, 2019
1
Answer

This load center will hold 8 of the THQL style 2-pole breakers. It will hold up to 18 of the THQP style 2-pole breakers. Or a combination of the two. Thank you for your question.

what is the layout of the bottom knockouts?

Asked by John September 22, 2020
1
Answer

Thank you for your question. The drawing was added to the specifications section on the website. Since it may take some time to be visible, below is a description of the bottom knockouts. One large knockout on the left that ranges from 1/2" to 2 1/2" is located 2.22 inches to the center of the knockout from the back side and 10.92 inches to the center from the right side. One knockout on the right that ranges from 1" to 2" is located 1.71 inches to the center of the knockout from the back side and 2.95 inches to the center from the right side. There is one knockout that ranges from 3/4" to 1 1/4" left of center located to the rear. There are six knockouts that are 1/2" x 3/4" in various positions across the bottom. There are eight knockouts that are 1/2" in various positions across the bottom. The drawing will also include knockouts on the side and back.

what is the best meter box for this breaker box

Asked by remods September 8, 2020
1
Answer

That depends on your local code requirements. You can check with a certified electrician in your area or your local Utility company.

Are the bus bars copper or aluminum?

Asked by Consumer September 17, 2017
1
Answer

Copper bus with tin plating for corrosion protection.

is there a 2" ko on the bottom

Asked by chris April 29, 2019
1
Answer

Thank you for your question. Yes, there are two large concentric knockout on the bottom with at least two inches. Dimension of one is 1/2" x 3/4" x 1" x 1 1/2" x 2" x 2 1/2" Dimension on the other is 1" X 1 1/2" X 2" X 2 1/2"

does this box have feed-thru lugs?

Asked by Dave August 20, 2020
1
Answer

Thank you for your question. The TM3215R64K does not have feed thru lugs.
