Internet #204326754

Model # TSMR820CSFLFMG

Store SKU #1000018643

0783164415162

GE

200 Amp 8 Space 16 Circuit Outdoor Combination Main Breaker Ringless Meter Socket Load Center

  • Outdoor NEMA 3R Enclosure
  • Main Lugs are Factory Installed; convertible to Main Breaker
  • Ringless meter
$ 146 24
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

+
+

Product Overview

  • Outdoor NEMA 3R Enclosure
  • Main Lugs are Factory Installed; convertible to Main Breaker
  • Ringless meter
Whether a building is powered by overhead lines or underground feeder cable, you can use this GE PowerMark Gold 200 Amp 8-Space 16-Circuit Ring less Meter Socket Combination Load Center. It is approved for use in Florida Meter Group areas. This unit is built to withstand the toughest environments.

Product Overview

  • Outdoor NEMA 3R Enclosure
  • Main Lugs are Factory Installed; convertible to Main Breaker
  • Ringless meter
Model #: TSMR820CSFLFMG
Sku #: 1000018643
Internet #: 204326754

Whether a building is powered by overhead lines or underground feeder cable, you can use this GE PowerMark Gold 200 Amp 8-Space 16-Circuit Ring less Meter Socket Combination Load Center. It is approved for use in Florida Meter Group areas. This unit is built to withstand the toughest environments.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
  • Outdoor NEMA 3R Enclosure
  • Main Lugs are Factory Installed; convertible to Main Breaker
  • Ringless meter
Whether a building is powered by overhead lines or underground feeder cable, you can use this GE PowerMark Gold 200 Amp 8-Space 16-Circuit Ring less Meter Socket Combination Load Center. It is approved for use in Florida Meter Group areas. This unit is built to withstand the toughest environments.

Product Overview

  • Outdoor NEMA 3R Enclosure
  • Main Lugs are Factory Installed; convertible to Main Breaker
  • Ringless meter
Model #: TSMR820CSFLFMG
Sku #: 1000018643
Internet #: 204326754

Whether a building is powered by overhead lines or underground feeder cable, you can use this GE PowerMark Gold 200 Amp 8-Space 16-Circuit Ring less Meter Socket Combination Load Center. It is approved for use in Florida Meter Group areas. This unit is built to withstand the toughest environments.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand GE GE Square D GE
Name Power Mark Gold 200 Amp 4-Space 8-Circuit Meter Socket Load Center 200 Amp 8 Space 16 Circuit Outdoor Combination Main Breaker Ringless Meter Socket Load Center Homeline 200 Amp 8-Space 16-Circuit Outdoor Ringless Overhead/Underground Main Breaker CSED 200 Amp 20 Space 40 Circuit Outdoor Combination Main Breaker/Ringless Meter Socket Load Center
Price
$123.16
$146.24
$149.00
$167.00
Ratings (12) (8) (39) (6)
Mounting type Surface Plug In Surface Plug In
Maximum Amperage (amps) 200 200 200 200
Number of Spaces 4 8 8 20
Voltage (volts) 240 240 120/240 240
View Product View Product View Product View Product

Specifications

Dimensions

Load center depth (in.)
5.1
Load center height (in.)
31.8
Load center width (in.)
14.1

Details

Electrical Product Type
Load Center
Indoor/Outdoor
Outdoor
Load Center Type
Combination
Maximum Amperage (amps)
200
Mounting type
Plug In
Number of Phases
1
Number of Spaces
8
Product Weight (lb.)
39lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
One year warranty from first use

Specifications

Dimensions

Load center depth (in.)
5.1
Load center height (in.)
31.8
Load center width (in.)
14.1

Details

Electrical Product Type
Load Center
Indoor/Outdoor
Outdoor
Load Center Type
Combination
Maximum Amperage (amps)
200
Mounting type
Plug In
Number of Phases
1
Number of Spaces
8
Product Weight (lb.)
39lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

Is this a feed thru breaker box?

Is this a feed thru breaker box?
Asked by: Roy
No, it is not a feed thru breaker box.
Answered by: CommunityAnswer
Date published: 2019-05-16

Thanks for the answer on my bus bar rating question. To follow up, is the bus bar on this unit up...

Thanks for the answer on my bus bar rating question. To follow up, is the bus bar on this unit upgradable? I need a 225 amp bus bar for adding solar and meeting the 120% rule.
Asked by: bill
Thanks again for your question and patience. Our product manager for this category was able to provide more information concerning your question. “The buss is 225amp in the TSMR820CSFLFMG and that ampacity can be used for the solar 120% rule but, it depends on the AHJ. This would allow the customer to back feed up to 70amps of solar (225*.2 = 45 amps extra allowed ..or total incoming to 225+45 or 270amps) Again it depends on the AHJ.” Please contact us again if we can provide more information.
Answered by: M Coffman GE Industrial
Date published: 2019-04-27

What is the bus bar rating of this unit? I know the main breaker is 200 amps. I want to know the ...

What is the bus bar rating of this unit? I know the main breaker is 200 amps. I want to know the bus bar. Lots of times the bus bar will be rated higher than the breaker (i.e. 225 amps). Thanks!
Asked by: bill
Thank you for your question. The TSMR820CSFLFMG buss is rated for 200 amps.
Answered by: M Coffman GE Industrial
Date published: 2019-04-29

Does this item come in green metal?

Asked by: JJ
Thank you for your question. Unfortunately, it is only available in the standard grey color.
Answered by: M Coffman GE Industrial
Date published: 2018-09-24
  • y_2019, m_8, d_22, h_23CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_9
  • loc_, sid_204326754, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 54ms
  • QUESTIONS, PRODUCT

Customer Reviews

200 Amp 8 Space 16 Circuit Outdoor Combination Main Breaker Ringless Meter Socket Load Center is rated 4.9 out of 5 by 8.
Rated 5 out of 5 by from Worked great while upgrading my electric service from 100 to... Worked great while upgrading my electric service from 100 to 200. Nice feature is that the box has room for additional branch circuits, so down the road when you want to add a circuit outside you don’t have to come from the inside electric panel.
Date published: 2019-03-20
Rated 5 out of 5 by from Good and huse all hausign... Good and huse all hausign
Date published: 2019-03-06
Rated 5 out of 5 by from I use these panels often and I love them. ... I use these panels often and I love them.
Date published: 2018-06-12
Rated 5 out of 5 by from Very good service in the electrical department... Very good service in the electrical department
Date published: 2018-12-26
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-02-21
Rated 5 out of 5 by from this is perfect for the Job this is perfect for the Job
Date published: 2018-08-21
Rated 4 out of 5 by from I have been using GE products for years and in... I have been using GE products for years and in some of the areas I work in require a tingles meter can. This combo worked out perfect for my jobs.
Date published: 2018-03-27
Rated 5 out of 5 by from Just what I needed... Just what I needed
Date published: 2017-12-19
