60 Amp Non Automatic AC Disconnect

  • Air Conditioner Disconnect in Outdoor NEMA 3R Steel enclosure
  • Multiple rear, bottom and side knockouts
  • Non-fusible
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

GE's 60 Amp AC Disconnect is used to cut off the power when servicing an Air Conditioning unit. Non-Automatic Disconnect.
