Metered RV Panel with 50 Amp and 30 Amp RV Receptacles and 20 Amp GFCI Receptacle

$329.62
Apply Now
Pay $279.62 after $50 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • 100A Metered Power Panel for recreational vehicle park power
  • 5-Space 5-Circuit includes circuit breakers
  • Stay open position on door
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

The Ring-Type Metered Surface Mount is factory-assembled and factory-tested. It comes to the construction job site ready to use with no need to assemble individual parts, saving installation time. The single, heavy-gauge NEMA 3R rainproof enclosure protects against weather, vandalism and nuisance tripping. It is lockable and is engineered for maximum protection of receptacles, cords, plugs, breakers. The unit complies with National Electrical Code and OSHA requirements.

Highlights

  • All-in-one construction for factory assured terminations
  • Rolled edge door for cord protection
  • Heavy galvanized zinc coated steel, with highest quality electro-deposition finish - resists corrosion and fading
  • Welded flange NEMA 3R construction for lasting service in outdoor installations
  • UL listed for RV use, not suitable for service entrance
  • Padlock provision can prevent unauthorized entry
  • Dead front construction prevents accidental contact with live parts
  • All components are factory wired and assembled, reducing installation time
  • Power outlet door has stay-open position for user convenience
  • All terminals accept copper or aluminum wire for added installation flexibility
  • Broad range of concentric knock-outs to accommodate wiring needs
  • All units with 12-2 Cu/Al equipment ground lug
  • Line 6-1/0CU; 6-1/0AL; load 14-10CU; neutral (large hole) 12-1/0CU; 10-1/0AL; neutral (small hole) 14-4CU; 12-4AL
  • Closure caps included, hubs ordered separately
  • Lockable
  • Single, heavy-gauge NEMA 3R rainproof enclosure
  • Only the 20a receptacle is GFCI protected
  • Ring type non-utility meter socket used for sub-metering (Electric meter not included)
  • Click here for more information on Electronic Recycling Programs
  • Return Policy

Product Information

Internet # 203393695

Model # GE1LM532SS

Store SKU # 1000051326

Additional Resources

Shop All GE

Specifications

Dimensions

Load center depth (in.)

3.9

Load center height (in.)

29.5

Load center width (in.)

9.5

Details

Electrical Product Type

Load Center

Load Center Type

Temporary Power

Maximum Amperage (A)

100

Number of Circuits

5

Number of Spaces

5

Phase Type

1 Phase

Product Weight (lb.)

22.5 lb

Returnable

90-Day

Voltage (V)

240

Warranty / Certifications

Certifications and Listings

UL Listed

Manufacturer Warranty

One year warranty from first use

Questions & Answers

30Questions
caret
Q:are the outlets wired together? ie will a 50a load plus a 20 amp load trip the breakers? or will it allow 100 amps to go through if all outlets are simultaneously fully loaded?
by|Dec 3, 2023
0 Answer
Answer This Question
caret
Q:i see it is "not suitable for service entrance".........but it is metered and for an RV. or can this only be used for sub metering at a park??? or can it be used for metered service entrance for an RV not in a park?
by|Aug 18, 2023
1 Answer
Answer This Question

A:  It is suitable for a private individual or company to monitor metered service (e.g. for individual billing purposes at an RV park by park owner) but not for a Utility's use. Thanks for the question.

by|Aug 21, 2023
    caret
    Q:does the panel have 240 volt breakers and 120 breakers ?
    by|Apr 13, 2023
    1 Answer
    Answer This Question

    A:  The GE1LM532SS does include a THQL2150 (240 volt 50a circuit breaker for the 50a receptacle), a THQL1130 (120 volt circuit breaker for the 30a receptacle), and a THQL1120 (120 volt circuit breaker for the 20a GFCI receptacle). Thank you for your question.

    by|Apr 13, 2023
      caret
      Q:Is this suitable for overhead hookup
      by|Mar 14, 2023
      2 Answers
      Answer This Question

      A:  yes it is

      by|Mar 18, 2023

        A:  Thanks for the question. Yes this unit has an opening on top that accepts available hubs for top feed applications. An example would be TC200P for 2" application.

        by|May 29, 2023
          Showing 1-4 of 30

          Customer Reviews

          4 out of 5

          • 4 out of 65 reviews
          • 72% recommend this product
          Filter by:
          Showing 1-10 of 65 reviews
          A great piece of equipment to buy for your rv install. Easy to mount, wire and a solidly made. I ...
          A great piece of equipment to buy for your rv install. Easy to mount, wire and a solidly made. I highly recommend this item.
          by
          • Verified Purchase
          • Recommended
          1 found this review helpful
          Ordered meter base already set up for rv,put on pole got inspected, power hooked up next day,awes...
          Ordered meter base already set up for rv,put on pole got inspected, power hooked up next day,awesome !!!!
          by
          • Verified Purchase
          • Recommended
          1 found this review helpful
          This was my fault, but the meter socket did not have a 5th jaw with a side lever. Which was needed by my utility, Xcel. It's a fine unit, but wasn't right for my temporary service installation in Colorado.
          by
            by
            • Verified Purchase
            It was fine but I couldn't use it because the...
            It was fine but I couldn't use it because the power company required something different.
            by
            • Verified Purchase
            by
            • Verified Purchase
            It has not passed in spection yet but grounding is...
            It has not passed in spection yet but grounding is completed. price is a little high and there is no room to add another breaker if something cam up
            by
            • Verified Purchase
            by
            • Verified Purchase
            Metered panel
            Worked perfectly and delivered on time.
            by
            • Verified Purchase
            • Recommended
            by
            • Verified Purchase
            Showing 1-10 of 65 reviews
