PowerMark Gold 125 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker

  • Indoor NEMA 1 enclosure
  • Main breaker is factory installed
  • Includes 8 circuit breakers
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

This value kit includes six 20 Amp Single-Pole, one 30 Amp Double-Pole, one 50 Amp Double-Pole THQP 1/2 in. Circuit Breakers. The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Indoor NEMA 1 enclosure with combination surface/flush front. This load center is UL listed and ANSI Certified.
  • For use as an indoor main breaker load center
  • Galvanized box for rust resistance with a self-adjusting dead-front cover
  • Copper buss for excellent conductivity
  • Single-phase, 3-wire, 120/240 VAC, 22,000 AIC rating
  • Compatible with GFCI, AFCI, Dual Function, standard GE THQL and GE 1/2 THQP circuit breakers
  • Can be used for surface or flush installations
  • ANSI certified and UL listed
  • Includes six 20 Amp single-pole (THQLP-120) circuit breakers, one 30 Amp double-pole (THQP-230) circuit breaker, and one 50 Amp double-pole (THQP-250) circuit breaker
  • Learn More About Electrical Panels Here in our Buying Guide.






  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Main Breaker Box Kits

current product
PowerMark Gold 125 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
200 Amp 32-Space 40-Circuit Indoor Main Breaker Load Center Value KitTop RatedPowerMark Gold 100 Amp 20-Space 20-Circuit Indoor Main Breaker Value Kit Includes Select Circuit BreakersTop RatedPowerMark Gold 150 Amp 32-Space 32-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
BrandGEGEGEGE
NamePowerMark Gold 125 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker200 Amp 32-Space 40-Circuit Indoor Main Breaker Load Center Value KitPowerMark Gold 100 Amp 20-Space 20-Circuit Indoor Main Breaker Value Kit Includes Select Circuit BreakersPowerMark Gold 150 Amp 32-Space 32-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
Price
Ratings
(82)
(7)
(82)
(82)
Number of Spaces12322032
Load center height (in.)16.1133.3223.1333.32
Number of Circuits22402032
Indoor/OutdoorIndoorIndoorIndoorIndoor
Load center width (in.)14.3814.3814.3814.38
Mounting TypePlug-OnPlug-OnPlug-OnPlug-On
Maximum Amperage (amps)125200100150
Electrical Product TypeLoad Center and Breaker KitLoad Center and Breaker KitLoad Center and Breaker KitLoad Center and Breaker Kit
Load center depth (in.)3.313.753.753.75
View ProductView ProductView ProductView Product

Specifications

Dimensions

Load center depth (in.)
3.31
Load center height (in.)
16.11
Load center width (in.)
14.38

Details

Electrical Product Type
Load Center and Breaker Kit
Indoor/Outdoor
Indoor
Load Center Mounting Type
Flush,Surface
Load Center Type
Main Breaker
Maximum Amperage (amps)
125
Mounting Type
Plug-On
Number of Circuits
22
Number of Spaces
12
Phase Type
1 Phase
Product Weight (lb.)
20.083
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
One year warranty from first use.

Questions & Answers

54Questions12Answers

Will the bus bar fit in a 200 amp GE challenger panel?

Asked by Bill December 18, 2019
1
Answer

It is not recommended to remove the bus bar(s) and put into other enclosures. This unit is UL tested and approved in the configuration it is sold. Great question and thanks for considering GE products!

what are the amperage's of the 8 branch circuit breakers included?

Asked by Stu March 27, 2019
2
Answers

This value kit includes 6 20 Amp Single-Pole, 1 30 Amp Double-Pole, 1 50 Amp Double-Pole THQL 1 in. Circuit Breakers.

Im attempting to use this panel as a sub-panel and No Home Depot near me has the TGK24CP ground b...

Asked by Joel February 4, 2019
2
Answers

you can use any ground bar if you dont mind drilling one hole. ground bare mounting holes and threads are fairly universal so if the ground bar you choose doesn't match up with two holes in the panel at least you can use one.

Does this panel have seperate ground and neutral bars?

Asked by DV January 17, 2019
1
Answer

Thank you for your question. The TM2010CCUPL4 does include full length neutrals on each side that is connected by a tie bar. The tie bar may be removed for to split neutral/ground. A TGK24CP can also be purchased separately and installed for an isolated ground bar.

Does this panel have copper bus?

Asked by Garry August 9, 2018
3
Answers

Yes all GE load centers have copper bus. That is what makes them such a value when comparing to other brands using aluminum bus.

Can you use this panel in a mobile home? I don't see a neutral lug. It's got ground lug but it do...

Asked by Smitty November 9, 2017
0
Answers

What gouge i use coming from the service out side to the break nox

Asked by Gilbert September 19, 2017
0
Answers

Does this include the panel cover? Does this not use twin tandem breakers? It is only 40 spaces 4...

Asked by sdowney717 June 30, 2017
1
Answer

Good question. Yes the cover is include. Some manufacturers do not covers. This panel is for a flush wall that would not stick out if installed properly.

What is meant by plug in mounting type?

Asked by Rey May 18, 2017
1
Answer

The breakers mount by plugging them in.

Can i ues for outside

Asked by Darrell February 28, 2017
1
Answer

No.

PowerMark Gold 125 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker - page 2

Customer Reviews

  • 4.5
    out of 82 reviews
  • 90% recommend this product
Filter by:
Showing 1-10 of 82 reviews
Needed a new 100A sub panel for one of my shops. Installation was a snap, electrician recommende...
Needed a new 100A sub panel for one of my shops. Installation was a snap, electrician recommended it for ease of getting breakers. Very happy. Was delivered faster than expected. Packed securely no damage.
by Dizzy
great
Easy to install and use and great value overall. Update from an old panel box with only ten breakers and a maximum of 40 amps.. added more circuits and replaced some circuits for new ones..included many breakers so i had more than enough to expand
by abhamz
Great product fit well and hooked up easy. You will need to buy a separate ground bar but those ...
Great product fit well and hooked up easy. You will need to buy a separate ground bar but those are cheap and easy to put in the box.
by Larryman
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
by HomeDepotCustomer
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
by HomeDepotCustomer
Works well, good quality....
Works well, good quality.
by STACEY
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
by HomeDepotCustomer
20 Circuits and 14 breakers was a steal!...
20 Circuits and 14 breakers was a steal!
by bernynhel
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
by HomeDepotCustomer
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
by HomeDepotCustomer
