Internet #100197801

Model #TLM1212CCUPL8

Store SKU #444532

PowerMark Gold 125 Amp 14-Space 24-Circuit Indoor Main Lug Value Kit Includes Select Circuit Breaker

  • Indoor NEMA 1 enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Includes 8 circuit breakers and equipment ground kit
  • See More Details

Frequently Bought Together

+
+
Price:
$8961

Product Overview

This value kit includes 6 20 Amp Single-Pole, 1 30 Amp Double-Pole, 1 50 Amp Double-Pole THQP 1/2 in. Circuit Breakers. The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Indoor NEMA 1 enclosure with combination surface/flush front. This load center is UL listed and ANSI Certified.
  • Rust-resistant galvanized box
  • Highly conductive copper buss bar
  • Factory-installed main breaker, full-length neutral bars, top or bottom feed and self-adjusting, dead-front cover
  • 100% rated split neutral on each side
  • Single-phase, 3-wire, 120/240-Volt
  • All neutral holes rated for 14 - 4 wire
  • Compatible with GE THQL, THQP, GFCI, DFCI and AFCI circuit breakers
  • Convertible to main breaker
  • Includes 6 THQP120 single-pole 20 Amp circuit breakers, 1 THQP230 double-pole 30 Amp circuit breaker and 1 THQP250 double-pole 50 Amp circuit breaker
  • UL listed and ANSI certified
  • Learn More About Electrical Panels Here in our Buying Guide.









  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Subpanel Kits

current product
PowerMark Gold 125 Amp 14-Space 24-Circuit Indoor Main Lug Value Kit Includes Select Circuit Breaker
PowerMark Gold 200 Amp 20-Space 40-Circuit Indoor Main Lug Value Kit Includes Select Circuit BreakerPowerMark Gold 200-Amp 32-Space 40-Circuit Indoor Main Lug Value Kit Includes Select Circuit BreakerQO 125 Amp 24-Space 24-Circuit Indoor Main Lug Qwik-Grip Plug-On Neutral Load Center - Ground Bar, Surge SPD Value Pack
BrandGEGEGESquare D
NamePowerMark Gold 125 Amp 14-Space 24-Circuit Indoor Main Lug Value Kit Includes Select Circuit BreakerPowerMark Gold 200 Amp 20-Space 40-Circuit Indoor Main Lug Value Kit Includes Select Circuit BreakerPowerMark Gold 200-Amp 32-Space 40-Circuit Indoor Main Lug Value Kit Includes Select Circuit BreakerQO 125 Amp 24-Space 24-Circuit Indoor Main Lug Qwik-Grip Plug-On Neutral Load Center - Ground Bar, Surge SPD Value Pack
Price
$8961
$11291
$12685
$18800
Ratings
(9)
(53)
(53)
(0)
Number of Spaces14203224
Maximum Amperage (amps)125200200125
Mounting TypePlug-OnPlug-OnPlug-OnPlug-On Neutral
Voltage (volts)240240240120/240
Number of Circuits24404036
Indoor/OutdoorIndoorIndoorIndoorIndoor
Load center width (in.)14.3814.3814.3814.25
Electrical Product TypeMain Lug/ Main Lug KitMain Lug/ Main Lug KitMain Lug/ Main Lug KitMain Lug/ Main Lug Kit
Load center depth (in.)3.313.753.753.75
View ProductView ProductView ProductView Product

Specifications

Dimensions

Load center depth (in.)
3.31
Load center height (in.)
16.11
Load center width (in.)
14.38

Details

Electrical Product Type
Main Lug/ Main Lug Kit
Indoor/Outdoor
Indoor
Load Center Mounting Type
Flush,Surface
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting Type
Plug-On
Number of Circuits
24
Number of Spaces
14
Phase Type
1 Phase
Returnable
180-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
ANSI Certified,UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

6Questions13Answers

Copper buss bar ( can U please send pic of it). Want to see if’s cooper.

Asked by Rick December 23, 2019
1
Answer

All GE load centers have copper bus that is tinned plated for corrosion protection. This ensures copper to copper connections between the bus and our breakers.

can i use the breaker Siemens QA115AF in this panel ? thanks.

Asked by eryt March 3, 2018
0
Answers

Why is there two different covers pictured here?

Asked by Jason January 3, 2018
2
Answers

One cover is for surface mounting and the other is for flush mounting. Depending on your use, if the look is not important you can use either.

I plan on running 4-4-4-2 SER cable. Do I need to buy lug nuts for the panel?

Asked by bob December 7, 2017
0
Answers

in the product description it says a factory installed main breaker, does it come with a main breaker or not?

Asked by mmmmmm March 14, 2015
5
Answers

No. This is a Main Lug panel as it is delivered. It can be converted to a Main Breaker panel with an optional kit.

Does the GE PowerMark Gold 125 Amp 12-Space 24-Circuit Main Lug Load Center Contractor Kit internally bond the ground bar to the can (PANEL ENCLOSURE)

Asked by Z December 20, 2011
5
Answers

Yes, the ground bar is permanently bonded to the can. The neutral bar can be left floating or can be grounded to the can

Customer Reviews

  • 4.7
    out of 9 reviews
  • 100% recommend this product
5star-icon6
4star-icon3
3star-icon0
2star-icon0
1star-icon0
Filter by:
Showing 1-9 of 9 reviews
Excellent choice - Excellent Purchase !...
Excellent choice - Excellent Purchase !
by RD
1 person found this helpful
5 Star Review
Rating provided by a verified purchaser
by HomeDepotCustomer
1 person found this helpful
One 20amp breaker that came with it was defective...
One 20amp breaker that came with it was defective
by DHsurvey
1 person found this helpful
Worked well for my application ...
Worked well for my application
by Jonathan
1 person found this helpful
5 Star Review
Rating provided by a verified purchaser
by Dennis
1 person found this helpful
I bought the panel to replace an older smaller GE panel. The new one was much easier to connect ...
I bought the panel to replace an older smaller GE panel. The new one was much easier to connect and had good options for wiring on all four sides and the back. Everything fit as it should have. I carried over my old GE breakers and added new ones for added circuits. The circuit breakers provided in the kit was very helpful. I needed to add new ones and I saved money by not needing to buy new ones. My only problem was that one of the door hinge clips was broken when I removed it from the carton. This was a minor issue for me. I was able to make a new clip.
by HRogers
1 person found this helpful
works as designed, no surprises, easy to install......
works as designed, no surprises, easy to install...
by paulg
1 person found this helpful
The image associated with this panel isn't correct. I just finished my installation. Very nice p...
The image associated with this panel isn't correct. I just finished my installation. Very nice panel for the money; good value with the included breakers.
by Dave
1 person found this helpful
Good product
It is a very good quality product very nice to have all those Tandem circuit breakers as a value pack! a plus I must say, the only thing I didn't like is that the picture of the front panel is not accurate it does actually not have the punch hole for the main breaker you have to remove the complete front panel to access the main breaker, as well you need to buy the kit for make it main breaker unit that is a cost of at least $80 more. bottom line good product have to update the front cover photo!
by JerrySD
Showing 1-9 of 9 reviews
