Model # TLM612SCUDP

Internet #100191244

Store SKU #198439

GE PowerMark Gold 125 Amp 6-Space 12-Circuit Indoor Main Lug Circuit Breaker Panel
0783164396645

GE

PowerMark Gold 125 Amp 6-Space 12-Circuit Indoor Main Lug Circuit Breaker Panel

  • Indoor NEMA 1 enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGL2 (order separately)
$ 24 77
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Indoor NEMA 1 enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGL2 (order separately)
The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Indoor NEMA 1 enclosure with combination surface/flush front. This load center is UL listed and ANSI Certified.
  • Maintenance-free, rust-resistant galvanized box
  • Copper buss bar for excellent conductivity
  • All neutral holes are rated for 14-4 wire
  • 100% rated split neutral on each side
  • Convertible to a main breaker
  • Full-length neutral bars for fast and easy wiring
  • Surface mountable
  • Single-phase, 3-wire, 125 Amp, 120/240 VAC, 22,000 AIC rating
  • Accommodates top or bottom feed applications
  • Accepts GE standard, GFCI and AFCI circuit breakers, including 1/2 in. THQP
  • Meets UL and ANSI safety requirements
  • Includes a factory-installed main lug and a self-adjusting dead-front cover
  • Learn More About Electrical Panels Here in our Buying Guide.









  • Click here for more information on Electronic Recycling Programs

Product Overview

  • Indoor NEMA 1 enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGL2 (order separately)
Model #: TLM612SCUDP
Sku #: 198439
Internet #: 100191244

The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Indoor NEMA 1 enclosure with combination surface/flush front. This load center is UL listed and ANSI Certified.

  • Maintenance-free, rust-resistant galvanized box
  • Copper buss bar for excellent conductivity
  • All neutral holes are rated for 14-4 wire
  • 100% rated split neutral on each side
  • Convertible to a main breaker
  • Full-length neutral bars for fast and easy wiring
  • Surface mountable
  • Single-phase, 3-wire, 125 Amp, 120/240 VAC, 22,000 AIC rating
  • Accommodates top or bottom feed applications
  • Accepts GE standard, GFCI and AFCI circuit breakers, including 1/2 in. THQP
  • Meets UL and ANSI safety requirements
  • Includes a factory-installed main lug and a self-adjusting dead-front cover
  • Learn More About Electrical Panels Here in our Buying Guide.









  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Price
$16.77
$24.77
$24.77
$33.00
Name PowerMark Gold 125 Amp 4-Space 8-Circuit Indoor Main Lug Circuit Breaker Panel PowerMark Gold 125 Amp 6-Space 12-Circuit Indoor Main Lug Circuit Breaker Panel PowerMark Gold 125 Amp 6-Space 12-Circuit Indoor Main Lug Circuit Breaker Panel PowerMark Gold 125 Amp 8-Space 16-Circuit Indoor Main Lug Circuit Breaker Panel
Brand GE GE GE GE
Ratings (4) (2) (2) (8)
View Product View Product View Product View Product

Specifications

Dimensions

Load center depth (in.)
3.375
Load center height (in.)
11.375
Load center width (in.)
11.5625

Details

Electrical Product Type
Main Lug/ Main Lug Kit
Indoor/Outdoor
Indoor
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting type
Plug In
Number of Phases
1
Number of Spaces
6
Product Weight (lb.)
9lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
Lifetime Warranty

Specifications

Dimensions

Load center depth (in.)
3.375
Load center height (in.)
11.375
Load center width (in.)
11.5625

Details

Electrical Product Type
Main Lug/ Main Lug Kit
Indoor/Outdoor
Indoor
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting type
Plug In
Number of Phases
1
Number of Spaces
6
Product Weight (lb.)
9lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
Lifetime Warranty

Questions & Answers

I read that thid is convertable to a main breaker. What is the item size that would make this a main breaker box?

This is for a tiny house
Asked by: Susan
125 amp 2pole breaker
Answered by: CVS
Date published: 2018-10-10

what is difference

sku 530543 and 198439 seem to be identical in appearance and specifications. so what is different?
Asked by: PaulM
  • y_2019, m_1, d_17, h_18CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.9
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_2
  • loc_, sid_100191244, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 97ms
  • QUESTIONS, PRODUCT

Customer Reviews

PowerMark Gold 125 Amp 6-Space 12-Circuit Indoor Main Lug Circuit Breaker Panel is rated 5.0 out of 5 by 2.
Rated 5 out of 5 by from works great... works great
Date published: 2019-01-08
Rated 5 out of 5 by from Great sub-panel. Second one I have used. The first to add circuits for an added bath and laundry ... Great sub-panel. Second one I have used. The first to add circuits for an added bath and laundry rooms. This one to upgrade the wiring to new appliances and take some of the load off an over-loaded fuse box.
Date published: 2018-12-27
