RV Pad Mount Pedestal with 50 Amp and 30 Amp RV Receptacles, 20 Amp GFCI Receptacle, and Photocell Light

$324.29
Apply Now
Pay $274.29 after $50 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • 100A Unmetered Power Pedestal for recreational vehicle park power
  • 5-Space 5-Circuit includes circuit breakers
  • Stay open position on door
  • View More Details
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

This pad mount RV pedestal is lockable and engineered for maximum protection of receptacles, cords, plugs, breakers. It comes to the construction job site ready to install with no need to assemble individual parts, saving installation time. The dual, heavy-gauge NEMA 3R rainproof enclosures protect against weather, vandalism and nuisance tripping. The unit complies with National Electrical Code and OSHA requirements.

Highlights

  • Single 100 Amp power head on a pad mount pedestal
  • All-in-one construction for factory assured terminations
  • Installed receptacles: 1-50 Amp 240-Volt, 1-30 Amp 120-Volt and 1-20 Amp GFCI
  • Installed breakers: 1-THQL2150 240-Volt breaker, 1-THQL1130 120-Volt breaker, 1-THQL1120 120-Volt
  • Rolled edge door for cord protection
  • Heavy galvanized zinc coated steel, with highest quality electro-deposition finish - resists corrosion and fading
  • Welded flange NEMA 3R construction for lasting service in outdoor installations
  • UL listed for RV use, not suitable for service entrance
  • Padlock provision can prevent unauthorized entry
  • Dead front construction prevents accidental contact with live parts
  • Power outlet door has stay-open position for user convenience
  • All components are factory wired and assembled, reducing installation time
  • All terminals accept copper or aluminum wire for added installation flexibility
  • Underground feed
  • 5 spaces/5 circuit capability and 1 open space available
  • Unit features a light and photocell
  • Lockable
  • Single, heavy-gauge NEMA 3R rainproof enclosure
  • Only the 20a receptacle is GFCI protected
  • Click here for more information on Electronic Recycling Programs
  • Return Policy

Product Information

Internet # 300325159

Model # GE1LU532PSL

Specifications

Dimensions

Load center depth (in.)

3.9

Load center height (in.)

41.1

Load center width (in.)

9.5

Details

Electrical Product Type

Distribution Load Center / Breaker Accessory

Load Center Type

Temporary Power

Maximum Amperage (A)

100

Number of Circuits

5

Number of Spaces

5

Phase Type

1 Phase

Product Weight (lb.)

35

Returnable

90-Day

Voltage (V)

240

Warranty / Certifications

Certifications and Listings

UL Listed, cUL Listed

Manufacturer Warranty

One year warranty from first use

Questions & Answers

5Questions
caret
Q:Can I plug in both a 50 and 30 amp plug for different rv’s at the same time on my property with just one of these?
by|Mar 1, 2021
1 Answer
Answer This Question

A:  Thank you for your question. Yes, the GE1LU532PSL RV pedestal will allow electrical distribution at the same time from any of the receptacles. Up to a total of 100 amps. The supply cable to the RV pedestal will need to be able to accommodate the total amperage.

by|Mar 1, 2021
    caret
    Q:Grounding wire connection?
    by|Aug 7, 2018
    0 Answer
    Answer This Question
    caret
    Q:Can I use #4 to the post connectors?
    by|Jul 9, 2018
    2 Answers
    Answer This Question

    A:  Yes, I used 2/0 from pedestal to pedestal.

    by|May 5, 2023

      A:  Yes, it can be used.

      by|May 5, 2023
        caret
        Q:I'm looking to buy 50 units.903-816-2070
        by|Oct 1, 2017
        0 Answer
        Answer This Question
        Showing 1-4 of 5

        Customer Reviews

        4.4 out of 5

        • 4.4 out of 10 reviews
        • 100% recommend this product
        Filter by:
        Showing 1-10 of 10 reviews
        Rating provided by a verified purchaser...
        Rating provided by a verified purchaser
        by
        • Verified Purchase
        had to buy new gfi for one of the panels...
        had to buy new gfi for one of the panels
        by
        • Verified Purchase
        Rating provided by a verified purchaser...
        Rating provided by a verified purchaser
        by
        • Verified Purchase
        Rating provided by a verified purchaser...
        Rating provided by a verified purchaser
        by
        • Verified Purchase
        Rating provided by a verified purchaser...
        Rating provided by a verified purchaser
        by
        • Verified Purchase
        Very easy to install! Great for campgrounds....
        Very easy to install! Great for campgrounds.
        by
        • Verified Purchase
        5 Star Review
        Rating provided by a verified purchaser
        by
        • Verified Purchase
        4 Star Review
        Rating provided by a verified purchaser
        by
        • Verified Purchase
        The box arrived damaged, one of the nuts appeared to be missing but showed up when the pedestal w...
        The box arrived damaged, one of the nuts appeared to be missing but showed up when the pedestal was raised into proper orientation. I installed anchor bolts before pouring the concrete using the installation drawings to build a template to hold the bolts in place. The pedestal is sturdy and has enough adjustment to allow for setting everything plumb and level. The photocell light hasn't ever come on, but I wasn't concerned enough about the light to diagnose whether it is a bad bulb or something else. Unlike some of the pedestals at RV parks, the cover bumps out to allow for a handle on your 50A or 30A plug.
        by
        • Verified Purchase
        • Recommended
        I purchased 3 of the pedestals, installed them a week ago and am very pleased with the product. ...
        I purchased 3 of the pedestals, installed them a week ago and am very pleased with the product. Installation was fairly quick and easy. Only thing is, there is 1 unit out of the 3, that the photocell light does not work... am still checking it to find the problem... I would recommend them !
        by
        • Verified Purchase
        • Recommended
