RV Panel with 50 Amp and 30 AMP RV Receptacles and a 20 Amp GFCI Receptacle

  • 100A Unmetered Power Panel for recreational vehicle park powe
  • 5-Space 5-Circuit includes circuit breakers
  • Stay open position on door
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

The Unmetered Surface Mount is factory-assembled and factory-tested. It comes to the construction job site ready to use with no need to assemble individual parts, saving installation time. The single, heavy-gauge NEMA 3R rainproof enclosure protects against weather, vandalism and nuisance tripping. It is lockable and is engineered for maximum protection of receptacles, cords, plugs, breakers. The unit complies with National Electrical Code and OSHA requirements.
  • All-in-1 construction for factory assured terminations
  • Rolled edge door for cord protection
  • Heavy galvanized zinc coated steel, with highest quality electro-deposition finish - resists corrosion and fading
  • Welded flange NEMA 3R construction for lasting service in outdoor installations
  • UL listed
  • Padlock provision can prevent unauthorized entry
  • Dead front construction prevents accidental contact with live parts
  • All components are factory wired and assembled, reducing installation time
  • Power outlet door has stay-open position for user convenience
  • All terminals accept copper or aluminum wire for added installation flexibility
  • Broad range of concentric knock-outs to accommodate wiring needs
  • All units with 12-2 Cu/Al equipment ground lug
  • Closure caps included, hubs ordered separately
  • Rugged 16-Gauge Zinc coated G-90 steel
  • Only the 20a receptacle is GFCI protected
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar RV Electrical Panels

60 Amp RV Panel Outlet with 50 Amp Receptacle, Breakers and GFCI Duplex
current product
Best SellerRV Panel with 50 Amp and 30 AMP RV Receptacles and a 20 Amp GFCI Receptacle
Metered RV Panel with 30 Amp RV Receptacle and 20 Amp GFCI ReceptacleMetered RV Panel with 50 Amp RV Receptacle and 20 Amp GFCI Receptacle
BrandConnecticut ElectricGEGEGE
Name60 Amp RV Panel Outlet with 50 Amp Receptacle, Breakers and GFCI DuplexRV Panel with 50 Amp and 30 AMP RV Receptacles and a 20 Amp GFCI ReceptacleMetered RV Panel with 30 Amp RV Receptacle and 20 Amp GFCI ReceptacleMetered RV Panel with 50 Amp RV Receptacle and 20 Amp GFCI Receptacle
Price
Ratings
(74)
(190)
(17)
(14)
Number of Circuits2522
Electrical Product TypeOutletLoad CenterLoad CenterLoad Center
Maximum Amperage (amps)6010010070
Voltage (volts)240240240240
View ProductView ProductView ProductView Product

Specifications

Dimensions

Load center depth (in.)
5.2
Load center height (in.)
17
Load center width (in.)
9.5

Details

Electrical Product Type
Load Center
Load Center Type
Temporary Power
Maximum Amperage (amps)
100
Number of Circuits
5
Number of Spaces
5
Phase Type
1 Phase
Product Weight (lb.)
15.15
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

74Questions18Answers

Does this have knockouts on both the sides? Picture shows on on right, but left is not shown

Asked by Dean May 17, 2021
4
Answers

Yes. The left side has a knock out on the bottom left side.

Does this come with the hub hole cover and gasket ?

Asked by dangtruck April 9, 2021
2
Answers

Yes it comes with a blank cover so if you’re going to come out of the top you need to buy a hub that size to your conduit

When will this item be available again?

Asked by Foxtrottertrader March 19, 2021
1
Answer

Hello, thank you for your recent inquiry with The Home Depot. As of right now, I am seeing this product is in-stock online and available to ship directly to home or Store. Pricing and availability may change depending on your area. Please localize by your zip code for the most accurate stock information, and if needed you can add your email to be notified as soon as the product is back in-stock! We appreciate your business and look forward to serving you in the future.

is this item in stock in any store near southeast ohio

Asked by thomas January 27, 2021
1
Answer

Thank you for your recent inquiry with The Home Depot regarding RV Panel with 50 Amp and 30 AMP RV Receptacles and a 20 Amp GFCI Receptacle. Please call 1-800-430-3376 so we may assist checking your local area for availability. We appreciate your business and look forward to serving you in the future.

What is difference this model 1LU532SS vs 1LU532SSP?

Asked by DK October 31, 2020
3
Answers

Apparently the 1LU532SS is the currently sold model as the 1LU532SSP seems to be discontinued.

Can the panel be wired from the rear. Want to use mounted on the side of a house.

Asked by RBA September 24, 2020
2
Answers

Yes! There are two knockouts on the back for various sized wires and conduit.

I have this box and need to wire it up. I am consevative with electricity and size wire on the large side.

Asked by John September 16, 2020
1
Answer

#2 for that length at 100 amps.

Where can I find the instructions for the wiring? There was no paper work in the box.

Asked by Tim September 11, 2020
1
Answer

Internally the box is prewired, it only needs supply lines and ground connected and this should be done by an experienced electrician.

Should i install a disconnect? If so what amps and can i use a AC disconnect?

Asked by Kamiela200 August 20, 2020
2
Answers

This panel is a maximum of 50 amps total load. The three recepticles, 50, 30 and 20, cannot be all on, and fully loaded, at the same time. Therefore the panel should be fed from a 50 amp breaker and treated as a subpanel (i.e. needs its on ground post near the panel location (typically 3 feet or so) depends on local code. Using a 50 amp AC disconnect is ok but should not be used to open the circuit. The disconnect should only be used to isolate the power from the panel after loads are off.

What is the difference between model GE1LU532SSP and model GE1LU532SS

Asked by Anthony July 28, 2020
1
Answer

The P simply designates a retail label on the package. Eventually the non P version will be removed. The both are identical items. Thanks for the question.

RV Panel with 50 Amp and 30 AMP RV Receptacles and a 20 Amp GFCI Receptacle - page 2

Customer Reviews

  • 4.8
    out of 190 reviews
  • 99% recommend this product
Filter by:
Showing 1-10 of 190 reviews
Absolutely needed this product in large carport. It is working perfectly!
Absolutely needed this product in large carport. It is working perfectly!
by Trpt53
We built our new house with an attached garage for our Class A motor home. Our contractor install...
We built our new house with an attached garage for our Class A motor home. Our contractor installed a 50 amp single outlet power box along with water and sewer hookups, and it served it's purpose for awhile. However, it was inconvenient because the breaker box was all the way across the the bay in the two car garage side. I wanted a full hookup box with 50/30 amp outlets and breakers and this fit the bill exactly. The fact that it comes pre-wired really saves time in the installation process, and the addition of a 120 volt GFI outlet with it's own breaker is a nice touch. Another benefit of having it's own dedicated breakers is that it allowed me to transfer the L1 and L2 leads in the main breaker panel straight into the buss bars and freed up two additional panel breaker spaces for future additions in the house.
by RCM
2 people found this helpful
its a great unit- easy to install - it could be a little cheaper though- also GE could do away wi...
its a great unit- easy to install - it could be a little cheaper though- also GE could do away with the gfi receptacle - they corrode an most campers abuse them away- but will still continue to use- cause their the only show in town- thanks Home Depot
by HomeDepotCustomer
Exactly what I was looking for, at a good price
not fancy, but meets the requirements as per my project
by Jozilla
2 people found this helpful
I am happy with my RV panel order.
This product is exactly what I wanted. It shipped and arrived very quickly and in good condition via UPS. Installed easy. I used a 6x8 treated wood post. A 4x4 won't have space for the screws. This panel has all 3 plugs. 50/30/20 - It's worth spending the extra $40 and having all 3 just in case. ALSO there is one Extra slot for an added circut as you can see with the extra smaller conduit going up the tree I added a Yard light.
by JoeDFW
10 people found this helpful
RV Power Panel
Very easy panel. All needed was to run you power feed. I used 6/3 w/G. Connect the three wires to the Lugs. The internal wiring to the receptacles was already done by GE. Has an extra slot for an additional circuit breaker which I used to power my shed.
by Mack
8 people found this helpful
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
by HomeDepotCustomer
The ground terminal block did not have adequate connection ports...
The ground terminal block did not have adequate connection ports and the port available was too small.
by JEFF
Pre-wired and simple install straight out of the box....
Pre-wired and simple install straight out of the box.
by TDC
Great panel. Fully assembled and wired is a great value....
Great panel. Fully assembled and wired is a great value.
by HomeDepotCustomer
