- Use with air conditioner units; heat pumps; spas; hot tubs
- Non-fused pullout indicates on/off position
- Padlockable
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The Halex 60 Amp 240-Volt Non-Fuse Metallic AC Disconnect is designed to stop the power going to an air conditioning unit to allow for safe working conditions. The disconnect is a non-fuse, puller type and is UL listed with an enclosed pull-out switch. Compatible with copper or aluminum lug wire range 14-3.
Highlights
- Used to disconnect power from an air conditioning unit
- Features a metallic enclosure for outdoor use
- Puller type with no fuse
- ANSI certified and UL listed
- Return Policy
Product Information
Specifications
Dimensions
Product Depth (in.) | 2.77 in |
|---|---|
Product Width (in.) | 5.14 in |
Details
Disconnect Type | Air Conditioner |
|---|---|
Fused | Non-Fused |
Indoor/Outdoor | Outdoor |
Maximum Amperage (A) | 60 A |
Maximum Wattage (W) | 14000.000 W |
NEMA Configuration | NEMA 3R |
Phase Type | 1 Phase |
Product Weight (lb.) | 2.7 lb |
Returnable | 90-Day |
Voltage (V) | 240 V |
Warranty / Certifications
Certifications and Listings | ANSI Certified, UL Listed, cUL Listed |
|---|---|
Manufacturer Warranty | The Halex Company warrants its products to be free from defects in material and workmanship for one year from the date of purchase. |
Questions & Answers
Can I use this for 120 volt.
Yes, it can, just be sure to follow all applicable electrical code.
Does it have a L1 and L2
Hello, thank you for the question. Our 60 Amp Non-Fusible Metallic AC Disconnect is a double pole disconnect, meaning it handles two live (L1 and L2) lines. It is rated for 240V single phase. Our ACD is designed to work with one or two power wires.
Where does the Neutral and\or Ground wires Connect?
Hello, you can access the document with that information in the 'Additional Resources' section on the right under 'Product Details'. Or if you'd like to email us at cs@halexco.com, we can send it to you that way.
Does the helix 60 amp 240 V actual fuse compatible or can I buy it by itself? I have the unit connected but I am missing the actual fuse that goes into it. The actual fuse number is.E469364
Hello, we do not sell a replacement by itself.
How does this product meet UL (Underwriter Labs) code? The deadfront barrier can be removed without a tool exposing people to voltages exceeding what is considered safe. Is the box certified and if so, to what standard and by what laboratory?
UL Listing # E469364.
What size knockouts does this take
1/2", 3/4" and 1".
We have one of these connected to a 100 amp breaker through 5 feet of #8 TW then to a subpanel also through #8 TW. The subpanel has a 20 and two 15 amp breakers. Is there a chance of overloading the wire between the subpanel and the HNF60R?
Yes. Your 100A breaker won't trip until the current gets to 100A. So, your #8 TW could experience 100A even though it is rated at only 40A. Further, this box is only rated at 60A, so again, it should be fed by nothing that can exceed 60A.
How to remove inner plate to wire the disconnect?
The inner plate of the disconnect can be removed by loosening the screws located on the sides or corners of the enclosure. Once the screws are removed, the plate can be carefully pulled out, giving you access to the wiring compartment. Refer to the provided instructions manual for specific diagrams and steps for your model.
