Electrical Test Kit with 600V AC/DC Multimeter, Non Contact Volt Tester, and Receptacle Tester
- Multimeter measures DC current, AC/DC voltage and resistance
- Non-Contact Voltage Tester detects voltage 50 to 1000V AC
- Receptacle tester with LED lights indicates wiring problems
- View More Details
Free & Easy Returns In Store
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
Klein Tools Multimeter Test Kit contains Cat. No. MM300 (Manual-Ranging Digital Multimeter), Cat. No. NCVT1P (Non-Contact Voltage Tester) and Cat. No. RT105 (Receptacle Tester). The MM300 measures DC current, AC/DC voltage and resistance. The NCVT1P automatically detects standard voltage in cables, cords, circuit breakers, lighting fixtures, switches, outlets, and wires. The RT105 detects the most common wiring problems in standard receptacles.
Highlights
- Multimeter measures up to 600V AC/DC voltage, 10A DC current and 2MOhms resistance
- Non-Contact Voltage Tester Cat. No. NCVT1P has a bright green LED to indicate the tester is working; it changes to red and audible tones sound when voltage is detected
- NCVT1P has a high intensity, bright red LED that illuminates and an audible tone when voltage is detected from 50 to 1000 VAC power operating range
- Receptacle tester Cat. No. RT105 detects wiring configurations and indicates correct wiring, and identifies common wiring faults
- Identifies open ground, open hot, open neutral, hot/ground reversed; it does not indicate quality of ground, multiple hot wires, or a combination of defects
- MM300 multimeter tests continuity with visual and audible continuity indicators
- Test leads included for Cat. No. MM300; batteries included for Cat. Nos. NCVT1P and MM300
- Click here for more Klein Tool products
- Click here for more information on Electronic Recycling Programs
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Additional Resources
Shop All Klein ToolsSpecifications
Dimensions
Product Depth (in.) | 3.50 in |
|---|---|
Product Width (in.) | 0.90 in |
Details
Features | Audible Alert, Data Logging, Interchangeable Leads |
|---|---|
Functions Measured | Amperage, Continuity, Resistance, Voltage |
Included | Batteries |
Number of Pieces | 3 |
Power Source | Battery Operated |
Returnable | 90-Day |
Test Meter Type | Multimeter, Non-Contact Voltage Tester, Receptacle and GFCI Tester |
Warranty / Certifications
Certifications and Listings | No Certifications or Listings |
|---|---|
Manufacturer Warranty | Please refer to the attached warranty document in the Product Overview section above under Info & Guides |
Questions & Answers
Operation of a Klein multimeter model mm100
The Klein Tools Cat. No. MM300, Digital Multimeter, Manual-Ranging, 600V includes an instruction manual with detailed operating instructions for measuring voltage, current, resistance, continuity, diodes, and batteries. Please refer to the instruction manual that was included with the meter for complete operating instructions. If you no longer have the manual or need additional assistance, please contact Klein Tools Customer Service at customerservice@kleintools.com and we will be happy to help.
Can you use this to check for car battery 12V?
Yes, the multimeter can be used on a car battery.
What can be done if ohm test function does not work ?
Please contact Klein Tools Customer Service 1-800-553-4676 for assistance with your meter.
Does it come with calibration certification
For information on calibration certification please contact Klein Tools Customer Service 1-800-553-4676
For information on calibration certificates please contact Klein Tools Customer Service 1-800-553-4676
does it have a wire toner to find whats downstream?
This set does not include a toner
I just opened an account. I am not receiving the 25% off on my chechout
Contact Home Depot for assistance with this issue
The kit has two products that require batteries, and includes batteries for each -- a set of heavy duty batteries, and a set of alkalines. Which is for which?
You can use either battery in either tester. When purchased separately, the non-contact tester includes alkaline batteries, the multimeter includes the carbon zinc batteries.
Does that voltage meter come with the batteries
Yes, batteries are included.
