- Makes a 45° turn in 4 in. S&D pipeline
- Connects 4 in. S&D pipe to select drain products to convey water
- Made of PVC for Hub X Hub solvent-weld connections
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Product Details
About This Product
The 4 in. PVC Elbow makes a 45° turn in 4 in. sewer and drain (S&D) pipe runs. The 45° Ell also connects to select drainage products compatible with 4 in. S&D connections such as channel drain outlets, Flo-Well Dry Well System, drainage grates, and pop-up emitters. The drain fitting is made of polyvinyl chloride (PVC) for Hub X Hub solvent-weld connections. Meets applicable ASTM standards. For use in non-pressurized underground sewer and drainage applications; maximum working pressure of 5 psi. This elbow is used to make a change in direction in the pipeline and connects two pipes of the same type and diameter size. Hassle-free limited lifetime warranty guarantees the NDS product is free from defects-or we'll replace it. NDS offers free tools such as the Home Drainage Center, Calculators, and NDS Stormwater Drainage mobile app to help make your project a success. Founded in 1972, NDS is the preferred choice of professionals and the leader in stormwater management solutions with proven products, tools, and support to help you get the job done right.
Highlights
- Adds a 45-degree turn from 4 in. Sewer & Drain (S&D) pipe to 4 in. S&D pipe in non-pressurized drainage and sewer piping systems
- Adds a 45-degree turn from select drainage products such as channel drain outlets, Flo-Well Dry Well System, drainage grates, and pop-up emitters to 4 in. S&D pipe
- Meets applicable ASTM standards
- Comes with one PVC Elbow
- As part of a complete drainage system, the PVC elbow adds a 45-degree turn to the pipeline as it connects two pipes of the same type and diameter size together; it can also add a 45-degree turn from drainage product to drain pipe
- Attach 4 in. S&D pipe to each end of 45-degree elbow; also connects 4 in. S&D pipe to select drainage products that accommodate 4 in. S&D connections; can be solvent-welded to PVC components for a watertight connection
- Elbow made of polyvinyl chloride (PVC) using a combination of virgin and recycled content treated with UV inhibitors to prevent fading and cracking.
- Use with the Flo-Well Dry Well System and select Channel Drain Outlets, Low-Profile Adapter Drains, Square Grates, Round Grates, and Atrium Grates to collect and convey water to drain pipe
- Use with Pop-Up Drainage Emitters to discharge water at a point of release
- Use sewer and drain fittings when you need to transition between different pipe types and sizes, or to change direction and make connections in the pipeline
- Onsite stormwater management protects the watershed downstream, and limits excess runoff which can lead to negative impacts such as erosion, pollution, and flooding
- Founded in 1972, NDS is the preferred brand trusted by professionals with proven products, tools, and support for any size project.
- NDS offers free tools such as the Home Drainage Center, Calculators, and NDS Stormwater Drainage mobile app to help make your project a success
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions: H 6.38 in, W 4.5 in, D 5 in
Dimensions
Double Fitting Size | 4" x 4" | Fitting 1 size | 4" |
|---|---|---|---|
Fitting 2 size | 4" | Fitting Size Dimensions | 4" x 4" |
Product Depth (in.) | 5 in | Product Height (in.) | 6.38 in |
Product Width (in.) | 4.5 in | Single Fitting Size | 4" |
Details
Application | Non-Potable Water | Bend Degree | 45 Degree |
|---|---|---|---|
Color Family | White | Color/Finish | White/Matte |
Compatible Pipe Material | PVC | Connection 1 | Hub |
Connection 2 | Hub | Connectivity | Hub |
DWV | DWV | Features | Corrosion Resistant |
Fitting or Connector Type | Elbow | Fitting/ Connector Collection | Sewer & Drain |
Material | PVC | Maximum working pressure (psi) | 5 |
Maximum Working Temperature (F) | 140 | Pack Size | 1 |
Pipe or Fitting Product Type | Fittings & Connectors | Product Weight (lb.) | .63 lb |
Reducing Fitting | No | Returnable | 90-Day |
Schedule Type | Schedule SDR35 |
Warranty / Certifications
Manufacturer Warranty | Limited Lifetime |
|---|
Questions & Answers
what is the inside diameter of the fitting
The inside diameter is 4.24".
Whats the item number
Internet #100111278 Model # 4P03 Store SKU #225567
Will this work with 4 inch triple wall drain pipe sold at homedepot? If so, what type of adhesive should be used? The project will be used for rain drainage.
Is it sch 40
5 PSI Sewer & Drain
This fits SDR 35 pipe which has thinner walls compared to Sch 40.
This DWV fitting will not fit on Schedule 40 pipe. DWV pipe is thinner wall than Schedule 40 pipe, has a smaller diameter, and is good for only a few psi.
What is the actual ID dimension? I want to put it on a green outlet pipe in my pond that has a 6.250” OD.
The ID is 6.25 inches, the same as the OD of green sewer pipe.
What glue is needed
Use standard solvent cement for PVC pipe.
PVC glue will work with our PVC fittings including this 45 degree elbow.
How many come in a case?
A case of these from the manufacturer comes with 30, however from the store they are sold 1 at a time.
What is the exact OD (outside dimension) of either side of this elbow? I really need the EXACT (or within 1/32") if possible. Thank you
This product is 6.63 inches in diameter.
The outside diameter of this part is 6.67".
