A: No this valve was not designed to install in a vertical orientation. If you install this valve in a vertical orientation the water will not drain out when you shut it off. That retentive water could freeze and destroy the valve. For vertical orientation you would want a different type of valve such as a yard or roof hydrant which can be seen on Priers web site. This valves are designed with a drain to empty the water column then they are shut off.
A: No this valve is not designed, manufactured or approved for potable water. I am not aware of any frost free hydrants that that are. Valves that dispense potable water are deemed to be “faucets” under US standards and must comply with a specific set of ridged standards. Valves such as this frost free hydrant, which are also referred to as hose bibs or silcocks, are deemed to be for irrigation and not for potable water. Therefore they are regulated by a different set of standards.
A: Prier’s methodology for stating depth on frost free hydrants works on “bury death”. It is not the overall dimension of the hydrant. Let us use this 14” hydrant for an example. The measurement from the back of the flange that would mount against the house, to the tip of the incoming water connection would be 15”. The washer that shuts off the flow of water is 1” in from that. So the measurement from the back of the mounting flange to the point where the water is stopped is 14”.
|Brand||Arrowhead Brass||Prier Products||Prier Products||Prier Products|
|Name||4 in. Lead Free Anti-Siphon Frost Free Hydrant with Built-In Vacuum Breaker||14 in. Full turn frost proof wall hydrant, 1/2 in. MIP x 1/2 in. SWT||1/2 in. x 8 in. Brass MPT x SWT Self-Draining Heavy Duty Frost Free Anti-Siphon Wall Hydrant||10 in. Self-Draining Anti-Siphon Freezeless Hydrant with 1/2 in. PEX Adapter|
|Connection||Male Pipe Thread||MIP x Sweat||MIP x Sweat||PEX Barb x Comp|
|Inlet Diameter (In.)||1/2||1/2||1/2||1/2|
|Valve Type||Hose Bibb||Sillcock||Sillcock||Sillcock|
|Outlet Diameter (In.)||3/4||1/2||1/2||1/2|
|Compatible Pipe Material||Copper||Copper||Copper||Copper|
|Application||Non-Potable Water,Potable Water||Non-Potable Water||Non-Potable Water||Non-Potable Water|
|Maximum Working Temperature (F)||140||120||120||120|
